Apollo 4Fp Series Backflow Preventers

Apollo Lead Free Bronze Dual Check Backflow Preventer (2 x FNPT)

Scraped SKU: 4FPLF3A00A 2026-06-05 04:31:06

Attributes

Group Code4FPLF3A00A
Product Typebackflow-preventer
Brand Seriesapollo-4fp-series-backflow-preventers
Applicationspotable water
ApprovalsCSA B356, NSF
Solutionsutility

Description

The Apollo® DUC4FP Series Dual Check Backflow Preventer for Residential Fire Sprinkler Systems prevents backflow by either backpressure or backsiphonage from a cross-connection between potable water lines and substances that are objectionable, but not health-hazards.
  • Low pressure loss
  • Corrosion resistant
  • Replaceable check valves
  • Pressure drop at 30gpm is less than 6psi
  • Complies with NFPA Standard 13D
  • MADE IN THE USA



Variations (2)

4FPLF3A55A

size1"
dimensions-
weight2.98 lb
packagingCarton (1 pce)

4FPLF3A66A

size1-1/4"
dimensions-
weight2.66 lb
packagingCarton (1 pce)

Specifications

articleApollo Lead Free Bronze Dual Check Backflow Preventer (2 x FNPT)
article number with gtin4FPLF3A00A
manufacturerAalberts integrated piping systems Americas, Inc. (Apollo)
weight2.66 lb
materialsbronze
finishingnone
connection typeFPT - female thread conical (NPT)
product groupvalves (backflow preventers)
ETIM classEC011469 Check valve
country of originUnited States
brandApollo
series4FP Series Backflow Preventers
product type4FPLF3A00A
ETIM
{"etim-class":"EC011469 Check valve","Housing material":"Bronze","Surface protection":"Untreated","Connections":"Internal thread conical (NPT)","Height":"","Height (imperial)":"","FM quality mark":"No","UL quality mark":"No","ULC quality mark":"No","LPCB quality mark":"No","Suitable for central heating water":"No","Certified according to SVGW for water":"No","Certified according to SVGW for gas":"No","VdS quality mark":"No","DVGW quality mark for gas":"No","DVGW quality mark for water":"No","KIWA certified":"No"}

PDF Documents

[Datasheet] 4FPLF-300 Submittal Sheet Open PDF
