Attributes
| Group Code | 36C9PX00 |
|---|---|
| Product Type | pressure-reducing-valve |
| Brand Series | apollo-36-series-pressure-reducing-valves |
| Applications | heating, cooling |
| Approvals | ASSE 1003, Build America Buy America (BABA) Act, Buy American Act (BAA), CSA B356, Made in USA |
| Solutions | utility, industry |
Description
Apollo 36C Series Pressure Reducing Valves are designed to protect non-potable water distribution systems by automatically controlling excessive pressure changes. The valves integral thermoplastic cage provides maximum corrosion resistance. Designed for easy in-line servicing with bottom cleanout access to seat disc and strainer.
- Balanced Piston Design
- Sealed Spring Cage Vault
- SS Adjusting Screw & Nut
- Built-in Thermal Expansion By-Pass
- Easy Access to Seat Disc and SS Strainer
- Factory Preset to 50 psi (-01)
- Control Pressure Ranges:
- 10-35 psi, 25-75 psi (standard), 75-125 psi
- 100% Manufactured in USA
Variations (1)
36C904P1
| size | 3/4" |
|---|---|
| dimensions | - |
| weight | 2.8 lb |
| packaging | - |
Specifications
| article | Apollo Compact Water Pressure Reducing Valves with Gauge Port Plugged (2 x Union PEX) |
|---|---|
| article number with gtin | 36C9PX00 (00670750379284) |
| manufacturer | Aalberts integrated piping systems Americas, Inc. (Apollo) |
| size | 3/4" |
| weight | 2.8 lb |
| color | bronze, yellow |
| materials | bronze (ASTM B584-C84400) |
| finishing | none |
| min. medium temperature | 33 °F |
| peak medium temperature | 180 °F |
| product group | valves (pressure reducing valves) |
| ETIM class | EC010122 Pressure reducing valve |
| brand | Apollo |
| series | 36 Series Pressure Reducing Valves |
| product type | 36C9PX00 |
| unsps | 40141652 |
| ETIM | {"etim-class":"EC010122 Pressure reducing valve","Housing material":"Bronze","Surface protection":"Untreated","Suitable for liquids":"Yes","Suitable for steam":"No","Suitable for gases":"No","Height":"","Height (imperial)":""} |
