Apollo 36 Series Pressure Reducing Valves

Apollo High Capacity Pressure Reducing Valves with Y-Strainer (2 x FNPT)

Scraped SKU: 36H21X00 2026-06-05 04:31:47

Attributes

Group Code36H21X00
Product Typepressure-reducing-valve
Brand Seriesapollo-36-series-pressure-reducing-valves
Applicationsheating, cooling
ApprovalsASSE 1003, Build America Buy America (BABA) Act, Buy American Act (BAA), CSA B356, Made in USA
Solutionsutility, industry

Description

The Apollo 36H Pressure Reducing Valves are designed for commercial, industrial, and institutional applications to reduce incoming water pressure for protection of plumbing system components and to reduce water consumption. The valves are made with proven ASTM grade bronze and stainless steel materials. The PRH provides high capacity flow with low pressure drop. It is designed with an integral by-pass relief to protect against thermal expansion downstream. The bottom access enables easy in-line cleaning or seat replacement. Not for use with potable water systems.

  • Sealed Spring Cage for Vault Installation
  • Ultra-High Flow Capacity
  • Internal Thermal Expansion Bypass
  • Local Code Approvals
  • Standard Factory Setting: 50 psi
  • Three spring ranges cover 10-125 psi
  • Stainless Steel Bolts and Spring
  • Inline Y-Strainer
  • 100% Made in the USA

Variations (20)

36H21301

size1/2"
dimensions8.37x4.00x9.25 "
weight9 lb
packagingCarton (1 pce)
d10.84
DN1-
d20.84
DN2-

36H21302

size1/2"
dimensions8.37x4.00x9.25 "
weight9 lb
packagingCarton (1 pce)
d10.84
DN1-
d20.84
DN2-

36H21303

size1/2"
dimensions8.37x4.00x9.25 "
weight9 lb
packagingCarton (1 pce)
d10.84
DN1-
d20.84
DN2-

36H21401

size3/4"
dimensions9.00x4.00x9.44 "
weight9 lb
packagingCarton (1 pce)
d11.05
DN1-
d21.05
DN2-

36H21402

size3/4"
dimensions9.00x4.00x9.44 "
weight9 lb
packagingCarton (1 pce)
d11.05
DN1-
d21.05
DN2-

36H21403

size3/4"
dimensions9.00x4.00x9.44 "
weight9 lb
packagingCarton (1 pce)
d11.05
DN1-
d21.05
DN2-

36H21502

size1"
dimensions10.25x4.70x11.50 "
weight12 lb
packagingCarton (1 pce)
d11.32
DN1-
d21.32
DN2-

36H21503

size1"
dimensions10.25x4.70x11.50 "
weight12 lb
packagingCarton (1 pce)
d11.32
DN1-
d21.32
DN2-

36H21602

size1-1/4"
dimensions12.50x6.50x13.38 "
weight29 lb
packagingCarton (1 pce)
d11.66
DN1-
d21.66
DN2-

36H21603

size1-1/4"
dimensions12.50x6.50x13.38 "
weight29 lb
packagingCarton (1 pce)
d11.66
DN1-
d21.66
DN2-

36H21701

size1-1/2"
dimensions13.13x6.50x13.88 "
weight29 lb
packagingCarton (1 pce)
d11.90
DN1-
d21.90
DN2-

36H21702

size1-1/2"
dimensions13.13x6.50x13.88 "
weight29 lb
packagingCarton (1 pce)
d11.90
DN1-
d21.90
DN2-

36H21801

size2"
dimensions16.00x7.63x17.13 "
weight47 lb
packagingCarton (1 pce)
d12.38
DN1-
d22.38
DN2-

36H21803

size2"
dimensions16.00x7.63x17.13 "
weight47 lb
packagingCarton (1 pce)
d12.38
DN1-
d22.38
DN2-

36H21901

size2-1/2"
dimensions17.70x7.63x18.50 "
weight49 lb
packagingCarton (1 pce)
d12.88
DN1-
d22.88
DN2-

36H21902

size2-1/2"
dimensions17.70x7.63x18.50 "
weight49 lb
packagingCarton (1 pce)
d12.88
DN1-
d22.88
DN2-

36H21903

size2-1/2"
dimensions17.70x7.63x18.50 "
weight49 lb
packagingCarton (1 pce)
d12.88
DN1-
d22.88
DN2-

36H21001

size3"
dimensions20.50x9.75x22.12 "
weight99 lb
packagingCarton (1 pce)
d13.50
DN1-
d23.50
DN2-

36H21002

size3"
dimensions20.50x9.75x22.12 "
weight99 lb
packagingCarton (1 pce)
d13.50
DN1-
d23.50
DN2-

36H21003

size3"
dimensions20.50x9.75x22.12 "
weight99 lb
packagingCarton (1 pce)
d13.50
DN1-
d23.50
DN2-

Specifications

articleApollo High Capacity Pressure Reducing Valves with Y-Strainer (2 x FNPT)
article number with gtin36H21X00
manufacturerAalberts integrated piping systems Americas, Inc. (Apollo)
weight99 lb
dimensions20.50x9.75x22.12 "
colorbronze, yellow
materialsbronze (ASTM B584-C84400)
finishingnone
shapestraight
connection typeFPT - female thread conical (NPT)
max operating pressure liquid400 psi
min. medium temperature33 °F
max medium temperature180 °F
peak medium temperature180 °F
product groupvalves (pressure reducing valves)
ETIM classEC010122 Pressure reducing valve
country of originUnited States
brandApollo
series36 Series Pressure Reducing Valves
product type36H21X00
unsps40141652
ETIM
{"etim-class":"EC010122 Pressure reducing valve","Housing material":"Bronze","Surface protection":"Untreated","Connection 1":"Internal thread conical (NPT)","Connection 2":"Internal thread conical (NPT)","Max. inlet pressure":"27.56bar","Max. inlet pressure (imperial)":"400psi","With pressure gauge":"No","Suitable for liquids":"Yes","Suitable for steam":"No","Suitable for gases":"No"}

PDF Documents

[Datasheet] 36H_36HLF Submittal Sheet Open PDF
[Certificate] Conbraco_Certification_CSA Open PDF
