| ETIM | {"etim-class":"EC003025 Fitting with 3 connections","Material connection 1":"Brass","Material quality connection 1":"CuZn38As (CW511L)","Surface protection connection 1":"Untreated","Surface treatment connection 1":"Untreated","Material connection 2":"Brass","Material quality connection 2":"CuZn38As (CW511L)","Surface protection connection 2":"Untreated","Surface treatment connection 2":"Untreated","Material connection 3":"Brass","Material quality connection 3":"CuZn38As (CW511L)","Surface protection connection 3":"Untreated","Surface treatment connection 3":"Untreated","Model":"T-piece","Angle":"90°","Reducing":"No","Multi-part":"No","System specific":"No","Connection 1":"Insert (push-fitting)","Nominal diameter connection 2":"1/2 inch (15)","Outer pipe diameter connection 2":"21.3mm","Outer pipe diameter connection 2 (imperial)":"0.84\"","Connection 2":"Insert (push-fitting)","Connection 3":"Insert (push-fitting)","Flange compression class":"PN 16","Material sealing":"Ethylene-propylene diene monomer rubber (EPDM)","Main colour fitting":"Brass","Max. operating pressure at 20 °C":"16bar","Max. operating pressure at 20 °C (imperial)":"232.06psi","Medium temperature (continuous)":"-24°C - 95°C","Medium temperature (continuous) (imperial)":"-11.2°F - 203°F","With sealing rings/gaskets":"No","With drain valve":"No","With de-aerator":"No","With buffer stud":"No","Capped":"No","FM quality mark":"No","LPCB quality mark":"No","ULC quality mark":"No","UL quality mark":"No","VdS quality mark":"No","DVGW quality mark for gas":"No","DVGW quality mark for water":"No","KIWA certified":"No","Gastec QA mark":"No","KOMO certified":"No","Gastec QA - AR 214 (H2)":"No"} |
|---|
