Attributes
| Group Code | 6170X01 |
|---|---|
| Product Type | check-valve |
| Brand Series | apollo-61-series-check-valves |
| Applications | cooling, compressed air |
| Approvals | Build America Buy America (BABA) Act, Buy American Act (BAA), CRN, Made in USA |
| Solutions | utility |
Description
The Apollo 61-700 check valve is ideally suited for cold water, and air applications for prevention of reverse flow. The modular check cartridge provides superior leak-tight performance with low pressure loss. It is rated at 230 PSIG with a maximum temperature of 200°F.
- Sizes: 1/4" - 1"
- Acetyl Check Valve Body
- Nitrile (Buna-N) Check Seals
- ASTM B16 Brass Housing
- Check Opening Pressure: .5 psi
Variations (6)
6170101
| size | 1/4" |
|---|---|
| dimensions | - |
| weight | 0.38 lb |
| packaging | Carton (1 pce) |
6170201
| size | 3/8" |
|---|---|
| dimensions | - |
| weight | 0.38 lb |
| packaging | Carton (1 pce) |
6170301
| size | 1/2" |
|---|---|
| dimensions | - |
| weight | 0.38 lb |
| packaging | Carton (1 pce) |
6170302
| size | 1/2" |
|---|---|
| dimensions | - |
| weight | 0.16 lb |
| packaging | Carton (1 pce) |
6170401
| size | 3/4" |
|---|---|
| dimensions | - |
| weight | 0.75 lb |
| packaging | Carton (1 pce) |
6170501
| size | 1" |
|---|---|
| dimensions | - |
| weight | 1.45 lb |
| packaging | Carton (1 pce) |
Specifications
| article | Apollo Brass Mini Check Valve with Standard Configuration (2 x FNPT) |
|---|---|
| article number with gtin | 6170X01 |
| manufacturer | Aalberts integrated piping systems Americas, Inc. (Apollo) |
| weight | 1.45 lb |
| color | bronze |
| materials | brass |
| finishing | none |
| connection type | FPT - female thread conical (NPT) |
| product group | valves (check valves) |
| ETIM class | EC011469 Check valve |
| country of origin | United States |
| brand | Apollo |
| series | 61 Series Check Valves |
| product type | 6170X01 |
| unsps | 40141622 |
| ETIM | {"etim-class":"EC011469 Check valve","Housing material":"Brass","Surface protection":"Untreated","Connections":"Internal thread conical (NPT)","Height":"","Height (imperial)":"","FM quality mark":"No","UL quality mark":"No","ULC quality mark":"No","LPCB quality mark":"No","Suitable for central heating water":"No","Certified according to SVGW for water":"No","Certified according to SVGW for gas":"No","VdS quality mark":"No","DVGW quality mark for gas":"No","DVGW quality mark for water":"No","KIWA certified":"No"} |
