Attributes
| Group Code | 6250X57 |
|---|---|
| Product Type | check-valve |
| Brand Series | apollo-62-series-check-valves |
| Applications | steam, compressed air |
| Approvals | CRN |
| Solutions | industry |
Description
The Apollo® 62-500 Series Check Valves are ideally suited for lower flow applications in tough industrial environments, since seat and soft seat are less prone to vibration. The stainless steel body and check provide lasting protection against reverse flow.
- No Radial Alignment Needed
- Bubble-Tight Shut-Off, Ideally Suited for Gaseous Service
- Fluorocarbon (Rubber) Soft Seat for Reduced Noise and Vibration
- Spring Loaded for Fast Seating Action
- Straight Through Flow Minimizes Velocity Change
- Spring is Fully Protected from Flow Steam
- Made in the USA
Variations (5)
6250157
| size | 1/4" |
|---|---|
| dimensions | - |
| weight | 0.38 lb |
| packaging | Carton (1 pce) |
| DN1 | - |
| DN2 | - |
6250257
| size | 3/8" |
|---|---|
| dimensions | - |
| weight | 0.37 lb |
| packaging | Carton (1 pce) |
| DN1 | - |
| DN2 | - |
6250357
| size | 1/2" |
|---|---|
| dimensions | - |
| weight | 3.63 lb |
| packaging | Carton (1 pce) |
| DN1 | - |
| DN2 | - |
6250457
| size | 3/4" |
|---|---|
| dimensions | - |
| weight | 7.66 lb |
| packaging | Carton (1 pce) |
| DN1 | - |
| DN2 | - |
6250557
| size | 1" |
|---|---|
| dimensions | - |
| weight | 1.5 lb |
| packaging | Carton (1 pce) |
| DN1 | - |
| DN2 | - |
Specifications
| article | Apollo Stainless Steel Soft Seat Check Valve with .5 psig Cracking Pressure, Oxygen Cleaned (2 x FNPT) |
|---|---|
| article number with gtin | 6250X57 |
| manufacturer | Aalberts integrated piping systems Americas, Inc. (Apollo) |
| weight | 1.5 lb |
| color | silver |
| materials | stainless steel (ASTM A351 CF8M) |
| finishing | none |
| connection type | FPT - female thread conical (NPT) |
| product group | valves (check valves) |
| ETIM class | EC011469 Check valve |
| country of origin | United States |
| brand | Apollo |
| series | 62 Series Check Valves |
| product type | 6250X57 |
| unsps | 40141622 |
| ETIM | {"etim-class":"EC011469 Check valve","Housing material":"Stainless steel","Surface protection":"Untreated","Connections":"Internal thread conical (NPT)","Height":"","Height (imperial)":"","FM quality mark":"No","UL quality mark":"No","ULC quality mark":"No","LPCB quality mark":"No","Suitable for central heating water":"No","Certified according to SVGW for water":"No","Certified according to SVGW for gas":"No","VdS quality mark":"No","DVGW quality mark for gas":"No","DVGW quality mark for water":"No","KIWA certified":"No"} |
