ApolloPress coupling – no stop (P x P)

Scraped SKU: 801 2026-06-05 04:33:14

Attributes

Group Code801
Product Typeaccessories-fittings
Brand Seriesapollo-apollopress
Applicationspotable water, heating, cooling, steam, compressed air, sprinkler, vacuum
ApprovalsCRN, FM, IAPMO/ANSI/CAN Z1117, ICC LC1002, NSF/ANSI 372, NSF/ANSI 61, UL, ULc
Solutionsfire protection, utility, industry

Description

The ApolloPress® 801 Small Diameter Press Coupling features a lead free dezincification resistant copper body and an EPDM o-ring. ApolloPress® products are manufactured utilizing proven ASTM materials and standards.
  • Lead Free Construction
  • Leak Before Press® Technology

Variations (6)

10075513

size1/2"
dimensions0.95x1.72x0.95 "
weight0.08 lb
packaging-
d10.62
DN1-
l10.81
d20.62
DN2-
l20.81

10075515

size3/4"
dimensions1.24x1.89x1.24 "
weight0.13 lb
packaging-
d10.88
DN1-
l10.97
d20.88
DN2-
l20.97

10075517

size1"
dimensions1.49x2.07x1.49 "
weight0.19 lb
packaging-
d11.12
DN1-
l10.97
d21.12
DN2-
l20.97

10077695

size1 1/4"
dimensions1.75x2.33x1.75 "
weight0.25 lb
packaging-
d11.38
DN1-
l11.09
d21.38
DN2-
l21.09

10077696

size1 1/2"
dimensions2.09x3.10x2.09 "
weight0.5 lb
packaging-
d11.62
DN1-
l11.50
d21.62
DN2-
l21.50

10077697

size2"
dimensions2.56x3.41x2.56 "
weight0.64 lb
packaging-
d12.12
DN1-
l11.66
d22.12
DN2-
l21.66

Specifications

articleApolloPress coupling – no stop (P x P)
article number with gtin801
manufacturerAalberts integrated piping systems Americas, Inc. (Apollo)
weight0.64 lb
dimensions2.56x3.41x2.56 "
colorcopper
materialscopper (CW024A (UNS C12200))
finishingnone
shapestraight
connection typepress (V)
sealingEPDM
max operating pressure liquid300 psi
min. medium temperature32 °F
max medium temperature250 °F
product groupfittings (accessories (fittings))
ETIM classEC003024 Fitting with 2 connections
country of originUnited States
brandApollo
seriesApolloPress
product type801
unsps40172612
ETIM
{"etim-class":"EC003024 Fitting with 2 connections","Material connection 1":"Copper","Material quality connection 1":"Cu-DHP (CW024A)","Surface protection connection 1":"Untreated","Surface treatment connection 1":"Untreated","Material connection 2":"Copper","Surface protection connection 2":"Untreated","Surface treatment connection 2":"Untreated","Shape":"Straight","Model":"1-part","Reducing":"No","Eccentric":"No","System specific":"No","Connection 1":"Press sleeve","Contour code connection 1":"V","Connection 2":"Press sleeve","Contour code connection 2":"V","Main colour fitting":"Copper","Material sealing":"Ethylene-propylene diene monomer rubber (EPDM)","With buffer stud":"No","Medium temperature (continuous)":"121.11°C","Medium temperature (continuous) (imperial)":"32°F - 250°F","Max. operating pressure at 20 °C":"20.67bar","Max. operating pressure at 20 °C (imperial)":"300psi","With thermal insulation":"No","With sealing rings/gaskets":"No","Capped":"No","With connection indicator":"No","With drain valve":"No","With de-aerator":"No","FM quality mark":"Yes","LPCB quality mark":"No","ULC quality mark":"Yes","UL quality mark":"Yes","VdS quality mark":"No","DVGW quality mark for gas":"No","DVGW quality mark for water":"No","Certified according to NF 545":"No","KIWA certified":"No","Gastec QA mark":"No","KOMO certified":"No","Gastec QA - AR 214 (H2)":"No"}
