Apollo Apollopress

ApolloPress adapter – female (P x FPT)

Scraped SKU: 803 2026-06-05 04:33:14

Attributes

Group Code803
Product Typeaccessories-fittings
Brand Seriesapollo-apollopress
Applicationspotable water, heating, cooling, steam, compressed air, sprinkler, vacuum
ApprovalsCRN, FM, IAPMO/ANSI/CAN Z1117, ICC LC1002, NSF/ANSI 372, NSF/ANSI 61, UL, ULc
Solutionsfire protection, utility, industry

Description

The ApolloPress® 803 Small Diameter Press Female Adapter features a lead free dezincification resistant brass body and an EPDM o-ring. ApolloPress® products are manufactured utilizing proven ASTM materials and standards.
  • Lead Free Construction
  • Leak Before Press® Technology

Variations (17)

10075780

size1/2" x FPT3/8"
dimensions0.87x1.34x0.87 "
weight0.07 lb
packaging-
d10.62
DN1-
l10.93
z10.17
d20.68
DN2-
l20.41
z20.17
slw21

10075750

size1/2" x FPT1/2"
dimensions1.52x1.01x1.01 "
weight0.1 lb
packaging-
d10.62
DN1-
l11.04
z10.17
d20.84
DN2-
l20.47
z20.17
slw21.1

10075782

size1/2" x FPT3/4"
dimensions1.24x1.62x1.24 "
weight0.15 lb
packaging-
d10.62
DN1-
l11.01
z10.26
d21.05
DN2-
l20.60
z20.26
slw21.26

10075784

size3/4" x FPT1/2"
dimensions1.01x1.50x1.01 "
weight0.11 lb
packaging-
d10.88
DN1-
l11.05
z10.14
d20.84
DN2-
l20.45
z20.14
slw21.1

10075752

size3/4" x FPT3/4"
dimensions1.73x1.25x1.25 "
weight0.16 lb
packaging-
d10.88
DN1-
l11.19
z10.19
d21.05
DN2-
l20.54
z20.19
slw21.26

10075796

size1" x FPT1/2"
dimensions1.01x1.55x1.01 "
weight0.14 lb
packaging-
d11.12
DN1-
l11.08
z10.16
d20.84
DN2-
l20.47
z20.16
slw21.1

10075798

size1" x FPT3/4"
dimensions1.25x1.56x1.25 "
weight0.15 lb
packaging-
d11.12
DN1-
l11.06
z10.14
d21.05
DN2-
l20.49
z20.14
slw21.26

10075754

size1" x FPT1"
dimensions1.76x1.53x1.53 "
weight0.21 lb
packaging-
d11.12
DN1-
l11.15
z10.23
d21.31
DN2-
l20.61
z20.23
slw21.61

10075800

size1" x FPT1 1/4"
dimensions1.93x1.96x1.93 "
weight0.34 lb
packaging-
d11.12
DN1-
l11.23
z10.30
d21.66
DN2-
l20.73
z20.30
slw21.97

10075786

size1 1/4" x FPT1/2"
dimensions1.75x1.79x1.75 "
weight0.21 lb
packaging-
d11.38
DN1-
l11.17
z10.13
d20.84
DN2-
l20.48
z20.13
slw21.26

10075788

size1 1/4" x FPT1"
dimensions1.75x1.80x1.75 "
weight0.24 lb
packaging-
d11.38
DN1-
l11.23
z10.18
d21.31
DN2-
l20.57
z20.18
slw21.61

10075756

size1 1/4" x FPT1 1/4"
dimensions1.90x1.93x1.93 "
weight0.33 lb
packaging-
d11.38
DN1-
l11.30
z10.17
d21.66
DN2-
l20.60
z20.17
slw21.97

10075790

size1 1/4" x FPT1 1/2"
dimensions2.20x1.98x2.20 "
weight0.41 lb
packaging-
d11.38
DN1-
l11.31
z10.28
d21.90
DN2-
l20.67
z20.28
slw22.36

10075792

size1 1/2" x FPT3/4"
dimensions2.09x2.03x2.09 "
weight0.3 lb
packaging-
d11.62
DN1-
l11.55
z10.12
d21.05
DN2-
l20.47
z20.12
slw21.26

10075794

size1 1/2" x FPT1 1/4"
dimensions2.09x2.19x2.09 "
weight0.11 lb
packaging-
d11.62
DN1-
l11.59
z10.17
d21.66
DN2-
l20.59
z20.17
slw21.97

10075758

size1 1/2" x FPT1 1/2"
dimensions2.43x2.20x2.20 "
weight0.51 lb
packaging-
d11.62
DN1-
l11.74
z10.30
d21.90
DN2-
l20.69
z20.30
slw22.36

10075760

size2" x FPT2"
dimensions2.44x2.73x2.73 "
weight0.67 lb
packaging-
d12.12
DN1-
l11.90
z10.27
d22.38
DN2-
l20.71
z20.27
slw22.76

Specifications

articleApolloPress adapter – female (P x FPT)
article number with gtin803
manufacturerAalberts integrated piping systems Americas, Inc. (Apollo)
weight0.67 lb
dimensions2.44x2.73x2.73 "
colorbrass
materialsbrass (C27451 (lead-free))
finishingnone
shapestraight, reducer
connection typepress (V), FPT - female thread conical (NPT)
sealingEPDM
max operating pressure liquid300 psi
min. medium temperature32 °F
max medium temperature250 °F
product groupfittings (accessories (fittings))
ETIM classEC003024 Fitting with 2 connections
country of originUnited States
brandApollo
seriesApolloPress
product type803
unsps40172521
ETIM
{"etim-class":"EC003024 Fitting with 2 connections","Material connection 1":"Brass","Surface protection connection 1":"Untreated","Surface treatment connection 1":"Untreated","Material connection 2":"Brass","Surface protection connection 2":"Untreated","Surface treatment connection 2":"Untreated","Shape":"Straight","Model":"1-part","Eccentric":"No","System specific":"No","Connection 1":"Press sleeve","Contour code connection 1":"V","Connection 2":"Internal thread conical (NPT)","Main colour fitting":"Brass","Material sealing":"Ethylene-propylene diene monomer rubber (EPDM)","With buffer stud":"Yes","Medium temperature (continuous)":"121.11°C","Medium temperature (continuous) (imperial)":"32°F - 250°F","Max. operating pressure at 20 °C":"20.67bar","Max. operating pressure at 20 °C (imperial)":"300psi","With thermal insulation":"No","With sealing rings/gaskets":"No","Capped":"No","With connection indicator":"No","With drain valve":"No","With de-aerator":"No","LPCB quality mark":"No","VdS quality mark":"No","DVGW quality mark for gas":"No","DVGW quality mark for water":"No","Certified according to NF 545":"No","KIWA certified":"No","Gastec QA mark":"No","KOMO certified":"No","Gastec QA - AR 214 (H2)":"No"}

PDF Documents

[Certificate] Apollo SmartPress IAPMO NSF ANSI 372-2022 Open PDF
[Certificate] Apollo SmartPress IAPMO UPC Open PDF
[Certificate] ApolloPress ICC-ES Open PDF
[Certificate] CRN_0A15729 Open PDF
[Installation- & Maintenance Document] ApolloPress Installation Instructions Open PDF
[Other Document] ApolloPress Catalog Open PDF
[Other Document] ApolloPress Brochure Open PDF
