ApolloPress 45° street elbow (P x FTG)

Scraped SKU: 806-2 2026-06-05 04:33:14

Attributes

Group Code806-2
Product Typeaccessories-fittings
Brand Seriesapollo-apollopress
Applicationspotable water, heating, cooling, steam, compressed air, sprinkler, vacuum
ApprovalsCRN, FM, IAPMO/ANSI/CAN Z1117, ICC LC1002, NSF/ANSI 372, NSF/ANSI 61, UL, ULc
Solutionsfire protection, utility, industry

Description

The ApolloPress® 806-2 Small Diameter Press 45° Street Elbow features a lead free dezincification resistant copper body and an EPDM o-ring. ApolloPress® products are manufactured utilizing proven ASTM materials and standards.
  • Lead Free Construction
  • Leak Before Press® Technology

Variations (6)

10075054

size1/2"
dimensions1.89x2.60x0.95 "
weight0.09 lb
packaging-
d10.64
DN1-
l11.19
z10.43
d20.63
DN2-
l21.69
z20.69
radius0.75
angle-

10075056

size3/4"
dimensions2.25x2.96x1.24 "
weight0.15 lb
packaging-
d10.88
DN1-
l11.33
z10.41
d20.88
DN2-
l21.88
z2-
radius1.05
angle-

10075058

size1"
dimensions2.33x3.23x1.49 "
weight0.24 lb
packaging-
d11.14
DN1-
l11.37
z10.47
d21.25
DN2-
l21.49
z2-
radius1.35
angle-

10075084

size1 1/4"
dimensions2.55x3.61x1.75 "
weight0.37 lb
packaging-
d11.39
DN1-
l11.71
z10.68
d21.38
DN2-
l21.78
z2-
radius1.65
angle-

10075086

size1 1/2"
dimensions3.06x4.09x2.11 "
weight0.59 lb
packaging-
d11.64
DN1-
l12.31
z10.84
d21.63
DN2-
l22.71
z2-
radius1.95
angle-

10075088

size2"
dimensions3.95x5.29x2.55 "
weight1.05 lb
packaging-
d12.15
DN1-
l12.64
z11.06
d22.12
DN2-
l22.71
z2-
radius2.55
angle-

Specifications

articleApolloPress 45° street elbow (P x FTG)
article number with gtin806-2
manufacturerAalberts integrated piping systems Americas, Inc. (Apollo)
weight1.05 lb
dimensions3.95x5.29x2.55 "
colorcopper
materialscopper (CW024A (UNS C12200))
finishingnone
shapeElbow, 45º
connection typepress (V), tube end
sealingEPDM
max operating pressure liquid300 psi
min. medium temperature32 °F
max medium temperature250 °F
product groupfittings (accessories (fittings))
ETIM classEC003024 Fitting with 2 connections
country of originUnited States
brandApollo
seriesApolloPress
product type806-2
unsps40172812
ETIM
{"etim-class":"EC003024 Fitting with 2 connections","Material connection 1":"Copper","Material quality connection 1":"Cu-DHP (CW024A)","Surface protection connection 1":"Untreated","Surface treatment connection 1":"Untreated","Material connection 2":"Copper","Surface protection connection 2":"Untreated","Surface treatment connection 2":"Untreated","Shape":"Bend","Model":"1-part","Bend angle":"45°","Reducing":"No","Eccentric":"No","System specific":"No","Connection 1":"Press sleeve","Contour code connection 1":"V","Connection 2":"Soldered end","Main colour fitting":"Copper","Material sealing":"Ethylene-propylene diene monomer rubber (EPDM)","With buffer stud":"Yes","Medium temperature (continuous)":"121.11°C","Medium temperature (continuous) (imperial)":"32°F - 250°F","Max. operating pressure at 20 °C":"20.67bar","Max. operating pressure at 20 °C (imperial)":"300psi","With thermal insulation":"No","With sealing rings/gaskets":"No","Capped":"No","With connection indicator":"No","With drain valve":"No","With de-aerator":"No","FM quality mark":"Yes","LPCB quality mark":"No","ULC quality mark":"Yes","UL quality mark":"Yes","VdS quality mark":"No","DVGW quality mark for gas":"No","DVGW quality mark for water":"No","Certified according to NF 545":"No","KIWA certified":"No","Gastec QA mark":"No","KOMO certified":"No","Gastec QA - AR 214 (H2)":"No"}
