ApolloPress 90° street elbow (P x FTG)

Scraped SKU: 807-2 2026-06-05 04:33:14

Attributes

Group Code807-2
Product Typeaccessories-fittings
Brand Seriesapollo-apollopress
Applicationspotable water, heating, cooling, steam, compressed air, sprinkler, vacuum
ApprovalsCRN, FM, IAPMO/ANSI/CAN Z1117, ICC LC1002, NSF/ANSI 372, NSF/ANSI 61, UL, ULc
Solutionsfire protection, utility, industry

Description

The ApolloPress® 807-2 Small Diameter Press 90° Street Elbow features a lead free dezincification resistant copper body and an EPDM o-ring. ApolloPress® products are manufactured utilizing proven ASTM materials and standards.
  • Lead Free Construction
  • Leak Before Press® Technology

Variations (6)

10075566

size1/2"
dimensions2.38x1.80x0.95 "
weight0.11 lb
packaging-
d10.63
DN1-
l11.50
z10.75
d20.62
DN2-
l21.91
radius0.75
angle-

10075568

size3/4"
dimensions2.82x2.37x1.24 "
weight0.21 lb
packaging-
d10.89
DN1-
l11.96
z11.01
d20.87
DN2-
l22.20
radius1.05
angle-

10075046

size1"
dimensions3.56x2.87x1.49 "
weight0.29 lb
packaging-
d11.14
DN1-
l12.19
z11.28
d21.12
DN2-
l22.81
radius1.35
angle-

10075072

size1 1/4"
dimensions3.85x3.64x1.75 "
weight0.47 lb
packaging-
d11.39
DN1-
l12.68
z11.65
d21.38
DN2-
l22.75
radius1.65
angle-

10075074

size1 1/2"
dimensions4.40x4.14x2.11 "
weight0.81 lb
packaging-
d11.64
DN1-
l13.39
z11.96
d21.62
DN2-
l23.46
radius1.95
angle-

10075076

size2"
dimensions5.56x5.12x2.58 "
weight1.3 lb
packaging-
d12.12
DN1-
l14.11
z12.52
d22.12
DN2-
l24.21
radius2.55
angle-

Specifications

articleApolloPress 90° street elbow (P x FTG)
article number with gtin807-2
manufacturerAalberts integrated piping systems Americas, Inc. (Apollo)
weight1.3 lb
dimensions5.56x5.12x2.58 "
colorcopper
materialscopper (CW024A (UNS C12200))
finishingnone
shapeElbow, 90º
connection typepress (V), tube end
sealingEPDM
max operating pressure liquid300 psi
min. medium temperature32 °F
max medium temperature250 °F
product groupfittings (accessories (fittings))
ETIM classEC003024 Fitting with 2 connections
country of originUnited States
brandApollo
seriesApolloPress
product type807-2
unsps40172812
ETIM
{"etim-class":"EC003024 Fitting with 2 connections","Material connection 1":"Copper","Material quality connection 1":"Cu-DHP (CW024A)","Surface protection connection 1":"Untreated","Surface treatment connection 1":"Untreated","Material connection 2":"Copper","Surface protection connection 2":"Untreated","Surface treatment connection 2":"Untreated","Shape":"Bend","Model":"1-part","Bend angle":"90°","Reducing":"No","Eccentric":"No","System specific":"No","Connection 1":"Press sleeve","Contour code connection 1":"V","Connection 2":"Soldered end","Main colour fitting":"Copper","Material sealing":"Ethylene-propylene diene monomer rubber (EPDM)","With buffer stud":"Yes","Medium temperature (continuous)":"121.11°C","Medium temperature (continuous) (imperial)":"32°F - 250°F","Max. operating pressure at 20 °C":"20.67bar","Max. operating pressure at 20 °C (imperial)":"300psi","With thermal insulation":"No","With sealing rings/gaskets":"No","Capped":"No","With connection indicator":"No","With drain valve":"No","With de-aerator":"No","FM quality mark":"Yes","LPCB quality mark":"No","ULC quality mark":"Yes","UL quality mark":"Yes","VdS quality mark":"No","DVGW quality mark for gas":"No","DVGW quality mark for water":"No","Certified according to NF 545":"No","KIWA certified":"No","Gastec QA mark":"No","KOMO certified":"No","Gastec QA - AR 214 (H2)":"No"}
