Apollo Apollopress

ApolloPress cross-over (P x P)

Scraped SKU: 836 2026-06-05 04:33:14

Attributes

Group Code836
Product Typeaccessories-fittings
Brand Seriesapollo-apollopress
Applicationspotable water, heating, cooling, steam, compressed air, sprinkler, vacuum
ApprovalsCRN, FM, IAPMO/ANSI/CAN Z1117, ICC LC1002, NSF/ANSI 372, NSF/ANSI 61, UL, ULc
Solutionsfire protection, utility, industry

Description

The ApolloPress® 836 Small Diameter Press Crossover features a lead free dezincification resistant copper body and an EPDM o-ring. ApolloPress® products are manufactured utilizing proven ASTM materials and standards.
  • Lead Free Construction
  • Leak Before Press® Technology

Variations (1)

10075372

size3/4"
dimensions2.06x5.50x1.24 "
weight0.54 lb
packaging-
d10.88
DN1-
l11.75
z10.85
d20.88
DN2-
l21.75
z20.85

Specifications

articleApolloPress cross-over (P x P)
article number with gtin836 (00683264753723)
manufacturerAalberts integrated piping systems Americas, Inc. (Apollo)
size3/4"
weight0.54 lb
dimensions2.06x5.50x1.24 "
colorcopper
materialscopper (CW024A (UNS C12200))
finishingnone
shapeJump
connection typepress (V)
sealingEPDM
max operating pressure liquid300 psi
min. medium temperature32 °F
max medium temperature250 °F
product groupfittings (accessories (fittings))
ETIM classEC003024 Fitting with 2 connections
country of originUnited States
brandApollo
seriesApolloPress
product type836
unsps40172612
ETIM
{"etim-class":"EC003024 Fitting with 2 connections","Material connection 1":"Copper","Material quality connection 1":"Cu-DHP (CW024A)","Surface protection connection 1":"Untreated","Surface treatment connection 1":"Untreated","Material connection 2":"Copper","Surface protection connection 2":"Untreated","Surface treatment connection 2":"Untreated","Shape":"Offset","Model":"1-part","Reducing":"No","Eccentric":"No","System specific":"No","Nominal diameter connection 1":"3/4 inch (20)","Outer pipe diameter connection 1":"22.23mm","Outer pipe diameter connection 1 (imperial)":"0.88\"","Wall thickness, connection 1":"1.4mm","Wall thickness, connection 1 (imperial)":"0.06\"","Connection 1":"Press sleeve","Contour code connection 1":"V","Nominal diameter connection 2":"3/4 inch (20)","Outer pipe diameter connection 2":"22.35mm","Outer pipe diameter connection 2 (imperial)":"0.88\"","Wall thickness, connection 2":"1.4mm","Wall thickness, connection 2 (imperial)":"0.06\"","Connection 2":"Press sleeve","Contour code connection 2":"V","Main colour fitting":"Copper","Material sealing":"Ethylene-propylene diene monomer rubber (EPDM)","With buffer stud":"Yes","Length":"52.32mm","Length (imperial)":"2.06\"","Length of connection 1":"44.45mm","Length of connection 1 (imperial)":"1.75\"","Working length connection 1":"21.59mm","Working length connection 1 (imperial)":"0.85\"","Length of connection 2":"44.45mm","Length of connection 2 (imperial)":"1.75\"","Working length connection 2":"21.59mm","Working length connection 2 (imperial)":"0.85\"","Medium temperature (continuous)":"121.11°C","Medium temperature (continuous) (imperial)":"32°F - 250°F","Max. operating pressure at 20 °C":"20.67bar","Max. operating pressure at 20 °C (imperial)":"300psi","With thermal insulation":"No","With sealing rings/gaskets":"No","Capped":"No","With connection indicator":"No","With drain valve":"No","With de-aerator":"No","FM quality mark":"Yes","LPCB quality mark":"No","ULC quality mark":"Yes","UL quality mark":"Yes","VdS quality mark":"No","DVGW quality mark for gas":"No","DVGW quality mark for water":"No","Certified according to NF 545":"No","KIWA certified":"No","Gastec QA mark":"No","KOMO certified":"No","Gastec QA - AR 214 (H2)":"No"}

PDF Documents

[Certificate] Apollo SmartPress IAPMO NSF ANSI 372-2022 Open PDF
[Certificate] Apollo SmartPress IAPMO UPC Open PDF
[Certificate] ApolloPress ICC-ES Open PDF
[Certificate] CRN_0A15729 Open PDF
