Apollo Apollopress

ApolloPress union – male (P x MPT)

Scraped SKU: 8733-4 2026-06-05 04:33:14

Attributes

Group Code8733-4
Product Typeaccessories-fittings
Brand Seriesapollo-apollopress
Applicationspotable water, heating, cooling, steam, compressed air, sprinkler, vacuum
ApprovalsCRN, FM, IAPMO/ANSI/CAN Z1117, ICC LC1002, NSF/ANSI 372, NSF/ANSI 61
Solutionsfire protection, utility, industry

Description

The ApolloPress® 8733-4 Small Diameter Press Union with Male NPT features a lead free dezincification resistant brass body and an EPDM o-ring. ApolloPress® products are manufactured utilizing proven ASTM materials and standards.
  • Lead Free Construction
  • Leak Before Press® Technology

Variations (6)

10075884

size1/2" x MPT1/2"
dimensions1.26x2.90x1.26 "
weight0.3 lb
packaging-
d10.62
DN1-
l11.54
z10.78
slw11.61
d20.84
DN2-
l21.32
z20.78
slw21.1

10075886

size3/4" x MPT3/4"
dimensions1.52x3.42x1.52 "
weight0.51 lb
packaging-
d10.88
DN1-
l11.87
z10.96
slw11.81
d21.05
DN2-
l21.50
z20.96
slw21.42

10075888

size1" x MPT1"
dimensions1.94x3.74x1.94 "
weight0.84 lb
packaging-
d11.12
DN1-
l11.97
z11.05
slw12.17
d21.31
DN2-
l21.74
z21.05
slw21.61

10075890

size1 1/4" x MPT1 1/4"
dimensions2.19x3.78x2.19 "
weight1 lb
packaging-
d11.38
DN1-
l12.04
z10.99
slw12.76
d21.66
DN2-
l21.70
z20.99
slw21.97

10075892

size1 1/2" x MPT1 1/2"
dimensions2.45x3.73x2.45 "
weight1.39 lb
packaging-
d11.62
DN1-
l12.20
z10.77
slw12.95
d21.90
DN2-
l21.49
z20.77
slw22.36

10075894

size2" x MPT2"
dimensions3.12x4.24x3.12 "
weight2.04 lb
packaging-
d12.12
DN1-
l12.51
z10.93
slw13.66
d22.38
DN2-
l21.68
z20.93
slw22.91

Specifications

articleApolloPress union – male (P x MPT)
article number with gtin8733-4
manufacturerAalberts integrated piping systems Americas, Inc. (Apollo)
weight2.04 lb
dimensions3.12x4.24x3.12 "
colorbrass
materialsbrass (C27451 (lead-free))
finishingnone
shapestraight
connection typepress (V), MPT - male thread conical (NPT)
sealingEPDM
max operating pressure liquid300 psi
min. medium temperature32 °F
max medium temperature250 °F
product groupfittings (accessories (fittings))
ETIM classEC003024 Fitting with 2 connections
country of originUnited States
brandApollo
seriesApolloPress
product type8733-4
unsps40174912
ETIM
{"etim-class":"EC003024 Fitting with 2 connections","Material connection 1":"Brass","Surface protection connection 1":"Untreated","Surface treatment connection 1":"Untreated","Material connection 2":"Brass","Surface protection connection 2":"Untreated","Surface treatment connection 2":"Untreated","Shape":"Straight","Model":"3-part","Reducing":"No","Eccentric":"No","System specific":"No","Connection 1":"Press sleeve","Contour code connection 1":"V","Connection 2":"External thread conical (NPT)","Main colour fitting":"Brass","Material sealing":"Ethylene-propylene diene monomer rubber (EPDM)","With buffer stud":"Yes","Medium temperature (continuous)":"121.11111°C","Medium temperature (continuous) (imperial)":"32°F - 250°F","Max. operating pressure at 20 °C":"20.68bar","Max. operating pressure at 20 °C (imperial)":"300psi","With thermal insulation":"No","With sealing rings/gaskets":"Yes","Capped":"No","With connection indicator":"No","With drain valve":"No","With de-aerator":"No","FM quality mark":"Yes","LPCB quality mark":"No","ULC quality mark":"No","UL quality mark":"No","VdS quality mark":"No","DVGW quality mark for gas":"No","DVGW quality mark for water":"No","Certified according to NF 545":"No","KIWA certified":"No","Gastec QA mark":"No","KOMO certified":"No","Gastec QA - AR 214 (H2)":"No"}
