ApolloPress flange adapter – ANSI Class 125 (P x FLG)

Scraped SKU: 8741 2026-06-05 04:33:14

Attributes

Group Code8741
Product Typeaccessories-fittings
Brand Seriesapollo-apollopress
Applicationspotable water, heating, cooling, steam, compressed air, sprinkler, vacuum
ApprovalsCRN, FM, IAPMO/ANSI/CAN Z1117, ICC LC1002, NSF/ANSI 372, NSF/ANSI 61, UL, ULc
Solutionsfire protection, utility, industry

Description

The ApolloPress® 8741 Small Diameter Press 125lb Companion Flange features a lead free dezincification resistant copper body and an EPDM o-ring. The black powder coating provides separation of dissimilar metals preventing electrolysis. ApolloPress® products are manufactured utilizing proven ASTM materials and standards.
  • Black Powder-Coated Steel Flange Base
  • Lead Free Construction
  • Leak Before Press® Technology
  • Approved for underground installation (per local installation code)

Variations (1)

10075702

size2"
dimensions3.67x6.00x6.00 "
weight2.67 lb
packaging-
d12.12
DN1-
l12.62
z11.03
d22.12
DN2-
l20.75
n2-
k24.75
d2-20.75
D26

Specifications

articleApolloPress flange adapter – ANSI Class 125 (P x FLG)
article number with gtin8741 (00683264757028)
manufacturerAalberts integrated piping systems Americas, Inc. (Apollo)
size2"
weight2.67 lb
dimensions3.67x6.00x6.00 "
colorcopper
materialscopper (CW024A (UNS C12200))
finishingnone
shapestraight
connection typepress (V), flange
pressure rating (PN)Class 125
sealingEPDM
max operating pressure liquid300 psi
min. medium temperature32 °F
max medium temperature250 °F
product groupfittings (accessories (fittings))
ETIM classEC003024 Fitting with 2 connections
country of originUnited States
brandApollo
seriesApolloPress
product type8741
unsps40173409
ETIM
{"etim-class":"EC003024 Fitting with 2 connections","Material connection 1":"Copper","Material quality connection 1":"Cu-DHP (CW024A)","Surface protection connection 1":"Untreated","Surface treatment connection 1":"Untreated","Material connection 2":"Steel","Surface protection connection 2":"Coated","Shape":"Straight","Model":"2-part","Reducing":"No","Eccentric":"No","System specific":"No","Nominal diameter connection 1":"2 inch (50)","Outer pipe diameter connection 1":"53.85mm","Outer pipe diameter connection 1 (imperial)":"2.12\"","Wall thickness, connection 1":"1.88mm","Wall thickness, connection 1 (imperial)":"0.07\"","Connection 1":"Press sleeve","Contour code connection 1":"V","Nominal diameter connection 2":"2 inch (50)","Outer pipe diameter connection 2":"53.85mm","Outer pipe diameter connection 2 (imperial)":"2.12\"","Connection 2":"Flange","Main colour fitting":"Copper","Flange compression class (ANSI)":"ANSI 125","Material sealing":"Ethylene-propylene diene monomer rubber (EPDM)","With buffer stud":"Yes","Length":"93.22mm","Length (imperial)":"3.67\"","Length of connection 1":"66.55mm","Length of connection 1 (imperial)":"2.62\"","Working length connection 1":"26.16mm","Working length connection 1 (imperial)":"1.03\"","Length of connection 2":"19.05mm","Length of connection 2 (imperial)":"0.75\"","Medium temperature (continuous)":"121.11111°C","Medium temperature (continuous) (imperial)":"32°F - 250°F","Max. operating pressure at 20 °C":"20.68bar","Max. operating pressure at 20 °C (imperial)":"300psi","With thermal insulation":"No","With sealing rings/gaskets":"No","Capped":"No","With connection indicator":"No","With drain valve":"No","With de-aerator":"No","FM quality mark":"Yes","LPCB quality mark":"No","ULC quality mark":"Yes","UL quality mark":"Yes","VdS quality mark":"No","DVGW quality mark for gas":"No","DVGW quality mark for water":"No","Certified according to NF 545":"No","KIWA certified":"No","Gastec QA mark":"No","KOMO certified":"No","Gastec QA - AR 214 (H2)":"No"}
