Apollo PowerPress Gas reducing outlet/branch Tee (3 x press)

Scraped SKU: 411RG 2026-06-05 04:33:42

Attributes

Group Code411RG
Brand Seriesapollo-powerpress-gas
Applicationsnatural gas, compressed air
ApprovalsCRN, CSA LC-4, IAPMO LC-4, ICC LC4
Solutionsutility, industry

Description

Apollo PowerPress® 411RG is a T-piece for natural gas applications, designed for thick wall steel pipe. By using Apollo PowerPress® system installation times are reduced significantly and a clean working environment is assured. The range consists of DW-profile press fittings and valves in sizes 1/2" up to and including 2".

  • outstanding corrosion resistance due to ZnNi coating
  • clear identification of materials and dimensions
  • Visu-Control-ring and Leak Before Pressed-function

Variations (15)

PWR7481716

size3/4”x3/4”x1/2”
dimensions2.95x4.49x1.50 "
weight0.7 lb
packagingCarton (5 pce)
d11.05
DN1-
l12.24
z11.02
d20.84
DN2-
l22.19
z21.08
d31.05
DN3-
l32.24
z31.02

PWR7481727

size1”x1”x1/2”
dimensions3.27x5.20x1.81 "
weight1 lb
packagingCarton (5 pce)
d11.32
DN1-
l12.60
z11.18
d20.84
DN2-
l22.34
z21.24
d31.32
DN3-
l32.60
z31.18

PWR7481738

size1”x1”x3/4”
dimensions3.39x5.20x1.81 "
weight1.05 lb
packagingCarton (5 pce)
d11.32
DN1-
l12.60
z11.18
d21.05
DN2-
l22.46
z21.24
d31.32
DN3-
l32.60
z31.18

PWR7483124

size1 1/4"x1 1/4"x1/2"
dimensions3.94x6.46x2.20 "
weight1.24 lb
packagingBag (1 pce)
d11.67
DN1-
l13.22
z11.33
d20.84
DN2-
l22.50
z21.39
d31.67
DN3-
l33.22
z31.33

PWR7483135

size1 1/4"x1 1/4"x3/4"
dimensions3.94x6.46x2.20 "
weight1.51 lb
packaging-
d11.67
DN1-
l13.22
z11.33
d21.06
DN2-
l22.60
z21.38
d31.67
DN3-
l33.22
z31.33

PWR7481749

size1 1/4”x1 1/4”x1”
dimensions3.94x6.46x2.20 "
weight1.61 lb
packagingCarton (1 pce)
d11.66
DN1-
l13.23
z11.34
d21.32
DN2-
l22.82
z21.40
d31.66
DN3-
l33.23
z31.34

PWR7481751

size1 1/2”x1 1/2”x1/2”
dimensions3.82x7.01x2.44 "
weight1.91 lb
packagingCarton (1 pce)
d11.90
DN1-
l13.48
z11.56
d20.84
DN2-
l22.58
z21.48
d31.90
DN3-
l33.48
z31.56

PWR7481760

size1 1/2”x1 1/2”x3/4”
dimensions3.94x7.01x2.44 "
weight1.94 lb
packagingCarton (1 pce)
d11.90
DN1-
l13.48
z11.56
d21.05
DN2-
l22.69
z21.47
d31.90
DN3-
l33.48
z31.56

PWR7481771

size1 1/2”x1 1/2”x1”
dimensions4.13x7.01x2.44 "
weight2.05 lb
packagingCarton (1 pce)
d11.90
DN1-
l13.48
z11.56
d21.32
DN2-
l22.89
z21.48
d31.90
DN3-
l33.48
z31.56

PWR7481782

size1 1/2”x1 1/2”x1 1/4”
dimensions4.65x7.01x2.44 "
weight2.23 lb
packagingCarton (1 pce)
d11.90
DN1-
l13.48
z11.56
d21.66
DN2-
l23.43
z21.54
d31.90
DN3-
l33.48
z31.56

PWR7481793

size2”x2”x1/2”
dimensions4.33x7.56x2.91 "
weight2.56 lb
packagingCarton (1 pce)
d12.37
DN1-
l13.78
z11.69
d20.84
DN2-
l22.87
z21.77
d32.37
DN3-
l33.78
z31.69

PWR7481804

size2”x2”x3/4”
dimensions4.45x7.56x2.91 "
weight2.62 lb
packagingCarton (1 pce)
d12.37
DN1-
l13.78
z11.69
d21.05
DN2-
l22.99
z21.77
d32.37
DN3-
l33.78
z31.69

PWR7481815

size2”x2”x1”
dimensions4.65x7.56x2.91 "
weight2.72 lb
packagingCarton (1 pce)
d12.37
DN1-
l13.78
z11.69
d21.32
DN2-
l23.19
z21.77
d32.37
DN3-
l33.78
z31.69

PWR7481826

size2”x2”x1 1/4”
dimensions5.20x7.56x2.91 "
weight2.89 lb
packagingCarton (1 pce)
d12.37
DN1-
l13.78
z11.69
d21.66
DN2-
l23.72
z21.83
d32.37
DN3-
l33.78
z31.69

PWR7481837

size2”x2”x1 1/2”
dimensions5.28x7.56x2.91 "
weight3.02 lb
packagingCarton (1 pce)
d12.37
DN1-
l13.78
z11.69
d21.90
DN2-
l23.80
z21.87
d32.37
DN3-
l33.78
z31.69

Specifications

articleApollo PowerPress Gas reducing outlet/branch Tee (3 x press)
article number with gtin411RG
manufacturerAalberts integrated piping systems B.V. (VSH)
weight3.02 lb
dimensions5.28x7.56x2.91 "
colorgrey
materialssteel (St 35 (1.0308))
finishingzinc-nickel plated
shapeT-piece, reducer, 90º
connection typepress (DW)
pressure rating (PN)PN 5
sealingHNBR
min. medium temperature-40 °F
max medium temperature194 °F
product groupfittings
ETIM classEC003025 Fitting with 3 connections
intrastat code73079980
country of originNetherlands
brandApollo
seriesPowerPress Gas
product type411RG
unsps40174602
ETIM
{"etim-class":"EC003025 Fitting with 3 connections","Material connection 1":"Steel","Material quality connection 1":"St 35 (1.0308)","Surface protection connection 1":"Zinc/nickel","Material connection 2":"Steel","Material quality connection 2":"St 35 (1.0308)","Surface protection connection 2":"Zinc/nickel","Material connection 3":"Steel","Material quality connection 3":"St 35 (1.0308)","Surface protection connection 3":"Zinc/nickel","Model":"T-piece","Angle":"90°","Reducing":"Yes","Multi-part":"No","System specific":"Yes","Connection 1":"Press sleeve","Contour code connection 1":"DW","Connection 2":"Press sleeve","Contour code connection 2":"DW","Connection 3":"Press sleeve","Contour code connection 3":"DW","Material sealing":"Hydrogenated acrylonitrile butadiene rubber (HNBR)","Main colour fitting":"Grey","High tensile strength":"Yes","Medium temperature (continuous)":"-40°C - 90°C","Medium temperature (continuous) (imperial)":"-40°F - 194°F","With sealing rings/gaskets":"No","With drain valve":"No","With de-aerator":"No","With thermal insulation":"No","With buffer stud":"Yes","Capped":"Yes","With connection indicator":"Yes","FM quality mark":"No","LPCB quality mark":"No","ULC quality mark":"No","UL quality mark":"No","VdS quality mark":"No","DVGW quality mark for gas":"No","DVGW quality mark for water":"No","KIWA certified":"No","Gastec QA mark":"No","KOMO certified":"No","Gastec QA - AR 214 (H2)":"No"}
