Attributes
| Group Code | 417G |
|---|---|
| Brand Series | apollo-powerpress-gas |
| Applications | natural gas, compressed air |
| Approvals | CRN, CSA LC-4, IAPMO LC-4, ICC LC4 |
| Solutions | utility, industry |
Description
Apollo PowerPress® 417G is an end cap for gas applications, designed for thick wall steel pipe. By using Apollo PowerPress® system installation times are reduced significantly and a clean working environment is assured. The range consists of DW-profile press fittings and valves in sizes 1/2" up to and including 2".
- outstanding corrosion resistance due to ZnNi coating
- clear identification of materials and dimensions
- Visu-Control-ring and Leak Before Pressed-function
Variations (6)
PWR7482475
| size | 1/2" |
|---|---|
| dimensions | 1.38x1.26x1.30 " |
| weight | 0.17 lb |
| packaging | Carton (10 pce) |
| d1 | 0.84 |
| DN1 | - |
| l1 | 1.38 |
| z1 | 0.28 |
PWR7482486
| size | 3/4" |
|---|---|
| dimensions | 1.50x1.50x1.50 " |
| weight | 0.22 lb |
| packaging | Carton (10 pce) |
| d1 | 1.05 |
| DN1 | - |
| l1 | 1.48 |
| z1 | 0.26 |
PWR7482497
| size | 1" |
|---|---|
| dimensions | 1.69x1.81x1.81 " |
| weight | 0.48 lb |
| packaging | Carton (5 pce) |
| d1 | 1.32 |
| DN1 | - |
| l1 | 1.69 |
| z1 | 0.28 |
PWR7482508
| size | 1 1/4" |
|---|---|
| dimensions | 2.20x2.20x2.20 " |
| weight | 0.6 lb |
| packaging | Carton (1 pce) |
| d1 | 1.66 |
| DN1 | - |
| l1 | 2.21 |
| z1 | 0.32 |
PWR7482519
| size | 1 1/2" |
|---|---|
| dimensions | 2.24x2.44x2.44 " |
| weight | 0.75 lb |
| packaging | Carton (1 pce) |
| d1 | 1.90 |
| DN1 | - |
| l1 | 2.24 |
| z1 | 0.32 |
PWR7482521
| size | 2" |
|---|---|
| dimensions | 2.44x2.91x2.91 " |
| weight | 0.99 lb |
| packaging | Carton (1 pce) |
| d1 | 2.37 |
| DN1 | - |
| l1 | 2.44 |
| z1 | 0.35 |
Specifications
| article | Apollo PowerPress Gas cap (1 x press) |
|---|---|
| article number with gtin | 417G |
| manufacturer | Aalberts integrated piping systems B.V. (VSH) |
| weight | 0.99 lb |
| dimensions | 2.44x2.91x2.91 " |
| color | grey |
| materials | steel (St 35 (1.0308)) |
| finishing | zinc-nickel plated |
| shape | End coupling |
| connection type | press (DW) |
| pressure rating (PN) | PN 5 |
| sealing | HNBR |
| min. medium temperature | -40 °F |
| max medium temperature | 194 °F |
| product group | fittings |
| ETIM class | EC003023 Fitting with 1 connection |
| intrastat code | 73079980 |
| country of origin | Netherlands |
| brand | Apollo |
| series | PowerPress Gas |
| product type | 417G |
| unsps | 40172402 |
| scip | d30775b1-132f-4657-80d3-acc91bda76c2 |
| ETIM | {"etim-class":"EC003023 Fitting with 1 connection","Material connection 1":"Steel","Material quality connection 1":"St 35 (1.0308)","Surface protection connection 1":"Zinc/nickel","System specific":"Yes","Connection 1":"Press sleeve","Contour code":"DW","Material sealing":"Hydrogenated acrylonitrile butadiene rubber (HNBR)","Main colour fitting":"Grey","Medium temperature (continuous)":"-40°C - 90°C","Medium temperature (continuous) (imperial)":"-40°F - 194°F","With sealing rings/gaskets":"No","With drain valve":"No","With de-aerator":"No","Capped":"Yes","With connection indicator":"Yes","FM quality mark":"No","UL quality mark":"No","ULC quality mark":"No","LPCB quality mark":"No","DIN-CERTCO certificate":"No","VdS quality mark":"No","With approval for TÜV":"No","DVGW quality mark for gas":"No","DVGW quality mark for water":"No","KIWA certified":"No","Gastec QA mark":"No","KOMO certified":"No","Gastec QA - AR 214 (H2)":"No","Type approval according to BBR/EKS":"No"} |
