Apollo PowerPress female thread adapter (press x female thread)

Scraped SKU: 403 2026-06-05 04:33:46

Attributes

Group Code403
Brand Seriesapollo-powerpress
Applicationsheating, cooling, compressed air, sprinkler
ApprovalsCRN, FM, IAPMO/ANSI/CAN Z1117, ICC LC1002, TSSA, UL, ULc
Solutionsfire protection, utility, industry

Description

Apollo PowerPress® 403 is a female thread adapter designed for thick wall steel pipe. By using Apollo PowerPress® system installation times are reduced significantly and a clean working environment is assured. The range consists of DW-profile press fittings and valves in sizes 1/2" up to and including 2".

  • outstanding corrosion resistance due to ZnNi coating
  • clear identification of materials and dimensions
  • Visu-Control-ring and Leak Before Pressed-function

Variations (21)

PWR7480902

size1/2 x FPT1/2
dimensions1.83x1.85x1.30 "
weight0.22 lb
packagingCarton (10 pce)
d10.84
DN1-
l11.26
z10.16
d20.84
DN2-
l20.57
z20.00
slw01.102
h0.512

PWR7480913

size3/4” x FPT1/2
dimensions1.95x1.97x1.50 "
weight0.38 lb
packagingCarton (10 pce)
d11.05
DN1-
l11.32
z10.10
d20.84
DN2-
l20.63
z20.02
slw01.417
h0.591

PWR7480924

size3/4” x FPT3/4
dimensions1.93x1.93x1.50 "
weight0.33 lb
packagingCarton (10 pce)
d11.05
DN1-
l11.30
z10.08
d21.05
DN2-
l20.63
z20.00
slw01.417
h0.591

PWR7480935

size1” x FPT1/2
dimensions2.26x2.24x1.81 "
weight0.6 lb
packagingCarton (10 pce)
d11.32
DN1-
l11.52
z10.10
d20.84
DN2-
l20.71
z20.10
slw01.614
h0.669

PWR7480946

size1” x FPT3/4
dimensions2.26x2.20x1.81 "
weight0.53 lb
packagingCarton (5 pce)
d11.32
DN1-
l11.48
z10.06
d21.05
DN2-
l20.71
z20.08
slw01.614
h0.669

PWR7480957

size1” x FPT1
dimensions2.26x2.28x1.81 "
weight0.45 lb
packagingCarton (5 pce)
d11.32
DN1-
l11.56
z10.14
d21.32
DN2-
l20.71
z20.00
slw01.614
h0.669

PWR7480968

size1 1/4” x FPT1/2
dimensions2.83x2.83x2.20 "
weight1.07 lb
packagingCarton (1 pce)
d11.66
DN1-
l12.05
z10.16
d20.84
DN2-
l20.79
z20.16
slw01.969
h0.748

PWR7480979

size1 1/4” x FPT3/4
dimensions2.80x2.80x2.20 "
weight0.98 lb
packagingCarton (1 pce)
d11.66
DN1-
l12.11
z10.22
d21.05
DN2-
l20.69
z20.06
slw01.969
h0.748

PWR7480981

size1 1/4” x FPT1
dimensions2.85x2.87x2.20 "
weight0.93 lb
packagingCarton (1 pce)
d11.66
DN1-
l12.07
z10.18
d21.32
DN2-
l20.79
z20.04
slw01.969
h0.748

PWR7480990

size1 1/4” x FPT1 1/4
dimensions2.80x2.80x2.20 "
weight0.74 lb
packagingCarton (5 pce)
d11.66
DN1-
l11.97
z10.08
d21.66
DN2-
l20.83
z20.00
slw01.969
h0.748

PWR7481001

size1 1/2” x FPT1/2
dimensions2.93x2.95x2.44 "
weight1.44 lb
packagingCarton (1 pce)
d11.90
DN1-
l12.09
z10.16
d20.84
DN2-
l20.85
z20.22
slw02.244
h0.787

PWR7481012

size1 1/2” x FPT3/4
dimensions2.89x2.91x2.44 "
weight1.34 lb
packagingCarton (1 pce)
d11.90
DN1-
l12.11
z10.18
d21.05
DN2-
l20.79
z20.16
slw02.244
h0.787

PWR7481023

size1 1/2” x FPT1
dimensions2.95x2.95x2.44 "
weight1.3 lb
packagingCarton (1 pce)
d11.90
DN1-
l12.17
z10.24
d21.32
DN2-
l20.79
z20.04
slw02.244
h0.787

PWR7481034

size1 1/2” x FPT1 1/4
dimensions2.87x2.87x2.44 "
weight1.15 lb
packagingCarton (1 pce)
d11.90
DN1-
l12.09
z10.16
d21.66
DN2-
l20.79
z20.02
slw02.244
h0.787

PWR7481045

size1 1/2” x FPT1 1/2
dimensions2.81x2.83x2.44 "
weight0.9 lb
packagingCarton (1 pce)
d11.90
DN1-
l12.01
z10.08
d21.90
DN2-
l20.81
z20.04
slw02.244
h0.787

PWR7481056

size2” x FPT1/2
dimensions3.25x3.27x2.91 "
weight2.01 lb
packagingCarton (1 pce)
d12.37
DN1-
l12.46
z10.37
d20.84
DN2-
l20.79
z20.18
slw02.756
h1.024

PWR7481067

size2” x FPT3/4
dimensions3.25x3.27x2.91 "
weight1.95 lb
packagingCarton (1 pce)
d12.37
DN1-
l12.46
z10.37
d21.05
DN2-
l20.79
z20.16
slw02.756
h1.024

PWR7481078

size2” x FPT1
dimensions3.25x3.27x2.91 "
weight1.86 lb
packagingCarton (1 pce)
d12.37
DN1-
l12.46
z10.37
d21.32
DN2-
l20.79
z20.04
slw02.756
h1.024

PWR7481089

size2” x FPT1 1/4
dimensions3.25x3.27x2.91 "
weight1.69 lb
packagingCarton (1 pce)
d12.37
DN1-
l12.46
z10.37
d21.66
DN2-
l20.79
z20.02
slw02.756
h1.024

PWR7481091

size2” x FPT1 1/2
dimensions3.11x3.11x2.91 "
weight1.64 lb
packagingCarton (1 pce)
d12.37
DN1-
l12.32
z10.24
d21.90
DN2-
l20.79
z20.02
slw02.756
h1.024

PWR7481100

size2” x FPT2
dimensions3.01x3.03x2.91 "
weight1.21 lb
packagingCarton (1 pce)
d12.37
DN1-
l12.22
z10.14
d22.37
DN2-
l20.79
z20.00
slw02.756
h1.024

Specifications

articleApollo PowerPress female thread adapter (press x female thread)
article number with gtin403
manufacturerAalberts integrated piping systems B.V. (VSH)
weight1.21 lb
dimensions3.01x3.03x2.91 "
colorgrey
materialssteel (St 35 (1.0308))
finishingzinc-nickel plated
shapestraight, reducer
connection typepress (DW), FPT - female thread conical (NPT)
pressure rating (PN)PN 16
sealingEPDM
max operating pressure liquid232 psi
min. medium temperature-40 °F
max medium temperature275 °F
peak medium temperature302 °F
product groupfittings
ETIM classEC003024 Fitting with 2 connections
intrastat code73079980
country of originNetherlands
brandApollo
seriesPowerPress
product type403
unsps40172502
scipd30775b1-132f-4657-80d3-acc91bda76c2
ETIM
{"etim-class":"EC003024 Fitting with 2 connections","Material connection 1":"Steel","Material quality connection 1":"St 35 (1.0308)","Surface protection connection 1":"Zinc/nickel","Material connection 2":"Steel","Material quality connection 2":"St 35 (1.0308)","Surface protection connection 2":"Zinc/nickel","Shape":"Straight","Model":"1-part","Eccentric":"No","System specific":"Yes","Connection 1":"Press sleeve","Contour code connection 1":"DW","Connection 2":"Internal thread conical (NPT)","Main colour fitting":"Grey","Flange compression class (PN)":"PN 16","Material sealing":"Ethylene-propylene diene monomer rubber (EPDM)","With buffer stud":"Yes","High tensile strength":"Yes","Medium temperature (continuous)":"-40°C - 135°C","Medium temperature (continuous) (imperial)":"-40°F - 275°F","Max. operating pressure at 20 °C":"16bar","Max. operating pressure at 20 °C (imperial)":"232.22psi","With thermal insulation":"No","With sealing rings/gaskets":"No","Capped":"Yes","With connection indicator":"Yes","With drain valve":"No","With de-aerator":"No","FM quality mark":"Yes","LPCB quality mark":"No","ULC quality mark":"Yes","UL quality mark":"Yes","DIN-CERTCO certificate":"No","VdS quality mark":"No","With approval for TÜV":"No","DVGW quality mark for gas":"No","DVGW quality mark for water":"No","Certified according to NF 545":"No","KIWA certified":"No","Gastec QA mark":"No","KOMO certified":"No","Gastec QA - AR 214 (H2)":"No","Type approval according to BBR/EKS":"No"}
