Attributes
| Group Code | 407-2 |
|---|---|
| Brand Series | apollo-powerpress |
| Applications | heating, cooling, compressed air, sprinkler |
| Approvals | CRN, FM, IAPMO/ANSI/CAN Z1117, ICC LC1002, TSSA, UL, ULc |
| Solutions | fire protection, utility, industry |
Description
Apollo PowerPress® 407-2 is a 90° bend designed for thick wall steel pipe. By using Apollo PowerPress® system installation times are reduced significantly and a clean working environment is assured. The range consists of DW-profile press fittings and valves in sizes 1/2" up to and including 2".
- outstanding corrosion resistance due to ZnNi coating
- clear identification of materials and dimensions
- Visu-Control-ring and Leak Before Pressed-function
Variations (6)
PWR7480187
| size | 1/2" |
|---|---|
| dimensions | 2.60x3.35x1.30 " |
| weight | 0.4 lb |
| packaging | Carton (10 pce) |
| d1 | 0.84 |
| DN1 | - |
| l1 | 2.17 |
| z1 | 1.06 |
| d2 | 0.84 |
| DN2 | - |
| l2 | 2.70 |
| radius | 0.98 |
| angle | - |
PWR7480198
| size | 3/4" |
|---|---|
| dimensions | 3.03x3.70x1.50 " |
| weight | 0.55 lb |
| packaging | Carton (10 pce) |
| d1 | 1.05 |
| DN1 | - |
| l1 | 2.48 |
| z1 | 1.26 |
| d2 | 1.05 |
| DN2 | - |
| l2 | 2.95 |
| radius | 1.18 |
| angle | - |
PWR7480209
| size | 1" |
|---|---|
| dimensions | 3.66x4.45x1.81 " |
| weight | 0.89 lb |
| packaging | Carton (5 pce) |
| d1 | 1.32 |
| DN1 | - |
| l1 | 2.99 |
| z1 | 1.58 |
| d2 | 1.32 |
| DN2 | - |
| l2 | 3.56 |
| radius | 1.50 |
| angle | - |
PWR7480211
| size | 1 1/4" |
|---|---|
| dimensions | 4.65x5.31x2.20 " |
| weight | 1.34 lb |
| packaging | Carton (1 pce) |
| d1 | 1.66 |
| DN1 | - |
| l1 | 3.80 |
| z1 | 1.91 |
| d2 | 1.66 |
| DN2 | - |
| l2 | 4.27 |
| radius | 1.77 |
| angle | - |
PWR7480220
| size | 1 1/2" |
|---|---|
| dimensions | 5.43x5.51x2.44 " |
| weight | 1.77 lb |
| packaging | Carton (1 pce) |
| d1 | 1.90 |
| DN1 | - |
| l1 | 4.47 |
| z1 | 2.54 |
| d2 | 1.90 |
| DN2 | - |
| l2 | 4.49 |
| radius | 1.97 |
| angle | - |
PWR7480231
| size | 2" |
|---|---|
| dimensions | 5.98x6.97x2.91 " |
| weight | 2.72 lb |
| packaging | Carton (1 pce) |
| d1 | 2.37 |
| DN1 | - |
| l1 | 4.78 |
| z1 | 2.70 |
| d2 | 2.37 |
| DN2 | - |
| l2 | 5.49 |
| radius | 2.56 |
| angle | - |
Specifications
| article | Apollo PowerPress street elbow 90° (press x insert) |
|---|---|
| article number with gtin | 407-2 |
| manufacturer | Aalberts integrated piping systems B.V. (VSH) |
| weight | 2.72 lb |
| dimensions | 5.98x6.97x2.91 " |
| color | grey |
| materials | steel (St 35 (1.0308)) |
| finishing | zinc-nickel plated |
| shape | Bend, 90º |
| connection type | press (DW), tube end |
| pressure rating (PN) | PN 16 |
| sealing | EPDM |
| max operating pressure liquid | 232 psi |
| min. medium temperature | -40 °F |
| max medium temperature | 275 °F |
| peak medium temperature | 302 °F |
| product group | fittings |
| ETIM class | EC003024 Fitting with 2 connections |
| intrastat code | 73079980 |
| country of origin | Netherlands |
| brand | Apollo |
| series | PowerPress |
| product type | 407-2 |
| unsps | 40172802 |
| ETIM | {"etim-class":"EC003024 Fitting with 2 connections","Material connection 1":"Steel","Material quality connection 1":"St 35 (1.0308)","Surface protection connection 1":"Zinc/nickel","Material connection 2":"Steel","Material quality connection 2":"St 35 (1.0308)","Surface protection connection 2":"Zinc/nickel","Shape":"Bend","Model":"1-part","Bend angle":"90°","Reducing":"No","Eccentric":"No","System specific":"Yes","Connection 1":"Press sleeve","Contour code connection 1":"DW","Connection 2":"Soldered end","Main colour fitting":"Grey","Flange compression class (PN)":"PN 16","Material sealing":"Ethylene-propylene diene monomer rubber (EPDM)","With buffer stud":"Yes","High tensile strength":"Yes","Medium temperature (continuous)":"-40°C - 135°C","Medium temperature (continuous) (imperial)":"-40°F - 275°F","Max. operating pressure at 20 °C":"16bar","Max. operating pressure at 20 °C (imperial)":"232.22psi","With thermal insulation":"No","With sealing rings/gaskets":"No","Capped":"Yes","With connection indicator":"Yes","With drain valve":"No","With de-aerator":"No","FM quality mark":"Yes","LPCB quality mark":"No","ULC quality mark":"Yes","UL quality mark":"Yes","DIN-CERTCO certificate":"No","VdS quality mark":"No","With approval for TÜV":"No","DVGW quality mark for gas":"No","DVGW quality mark for water":"No","Certified according to NF 545":"No","KIWA certified":"No","Gastec QA mark":"No","KOMO certified":"No","Gastec QA - AR 214 (H2)":"No","Type approval according to BBR/EKS":"No"} |
