Attributes
| Group Code | 411 |
|---|---|
| Brand Series | apollo-powerpress |
| Applications | heating, cooling, compressed air, sprinkler |
| Approvals | CRN, FM, IAPMO/ANSI/CAN Z1117, ICC LC1002, TSSA, UL, ULc |
| Solutions | fire protection, utility, industry |
Description
Apollo PowerPress® 411 is a T-piece designed for thick wall steel pipe. By using Apollo PowerPress® system installation times are reduced significantly and a clean working environment is assured. The range consists of DW-profile press fittings and valves in sizes 1/2" up to and including 2".
- outstanding corrosion resistance due to ZnNi coating
- clear identification of materials and dimensions
- Visu-Control-ring and Leak Before Pressed-function
Variations (6)
PWR7480363
| size | 1/2" |
|---|---|
| dimensions | 2.72x4.13x1.26 " |
| weight | 0.57 lb |
| packaging | Bag (5 pce) |
| d1 | 0.84 |
| DN1 | - |
| l1 | 2.05 |
| z1 | 0.95 |
| d2 | 0.84 |
| DN2 | - |
| l2 | 2.09 |
| z2 | 0.98 |
| d3 | 0.84 |
| DN3 | - |
| l3 | 2.05 |
| z3 | 0.95 |
PWR7480374
| size | 3/4" |
|---|---|
| dimensions | 3.07x4.49x1.50 " |
| weight | 0.74 lb |
| packaging | Bag (5 pce) |
| d1 | 1.05 |
| DN1 | - |
| l1 | 2.24 |
| z1 | 1.02 |
| d2 | 1.05 |
| DN2 | - |
| l2 | 2.30 |
| z2 | 1.08 |
| d3 | 1.05 |
| DN3 | - |
| l3 | 2.24 |
| z3 | 1.02 |
PWR7480385
| size | 1" |
|---|---|
| dimensions | 3.54x5.20x1.81 " |
| weight | 1.14 lb |
| packaging | Bag (5 pce) |
| d1 | 1.32 |
| DN1 | - |
| l1 | 2.60 |
| z1 | 1.18 |
| d2 | 1.32 |
| DN2 | - |
| l2 | 2.66 |
| z2 | 1.24 |
| d3 | 1.32 |
| DN3 | - |
| l3 | 2.60 |
| z3 | 1.18 |
PWR7480396
| size | 1 1/4" |
|---|---|
| dimensions | 4.45x6.46x2.20 " |
| weight | 1.74 lb |
| packaging | Bag (1 pce) |
| d1 | 1.66 |
| DN1 | - |
| l1 | 3.23 |
| z1 | 1.34 |
| d2 | 1.66 |
| DN2 | - |
| l2 | 3.35 |
| z2 | 1.46 |
| d3 | 1.66 |
| DN3 | - |
| l3 | 3.23 |
| z3 | 1.34 |
PWR7480407
| size | 1 1/2" |
|---|---|
| dimensions | 4.72x7.01x2.44 " |
| weight | 2.33 lb |
| packaging | Bag (1 pce) |
| d1 | 1.90 |
| DN1 | - |
| l1 | 3.48 |
| z1 | 1.56 |
| d2 | 1.90 |
| DN2 | - |
| l2 | 3.50 |
| z2 | 1.58 |
| d3 | 1.90 |
| DN3 | - |
| l3 | 3.48 |
| z3 | 1.56 |
PWR7480418
| size | 2" |
|---|---|
| dimensions | 5.39x7.56x2.91 " |
| weight | 3.15 lb |
| packaging | Bag (1 pce) |
| d1 | 2.37 |
| DN1 | - |
| l1 | 3.78 |
| z1 | 1.69 |
| d2 | 2.37 |
| DN2 | - |
| l2 | 3.92 |
| z2 | 1.83 |
| d3 | 2.37 |
| DN3 | - |
| l3 | 3.78 |
| z3 | 1.69 |
Specifications
| article | Apollo PowerPress Tee (3 x press) |
|---|---|
| article number with gtin | 411 |
| manufacturer | Aalberts integrated piping systems B.V. (VSH) |
| weight | 3.15 lb |
| dimensions | 5.39x7.56x2.91 " |
| color | grey |
| materials | steel (St 35 (1.0308)) |
| finishing | zinc-nickel plated |
| shape | T-piece, 90º |
| connection type | press (DW) |
| pressure rating (PN) | PN 16 |
| sealing | EPDM |
| max operating pressure liquid | 232 psi |
| min. medium temperature | -40 °F |
| max medium temperature | 275 °F |
| peak medium temperature | 302 °F |
| product group | fittings |
| ETIM class | EC003025 Fitting with 3 connections |
| intrastat code | 73079980 |
| country of origin | Netherlands |
| brand | Apollo |
| series | PowerPress |
| product type | 411 |
| unsps | 40174602 |
| ETIM | {"etim-class":"EC003025 Fitting with 3 connections","Material connection 1":"Steel","Material quality connection 1":"St 35 (1.0308)","Surface protection connection 1":"Zinc/nickel","Material connection 2":"Steel","Material quality connection 2":"St 35 (1.0308)","Surface protection connection 2":"Zinc/nickel","Material connection 3":"Steel","Material quality connection 3":"St 35 (1.0308)","Surface protection connection 3":"Zinc/nickel","Model":"T-piece","Angle":"90°","Reducing":"No","Multi-part":"No","System specific":"Yes","Connection 1":"Press sleeve","Contour code connection 1":"DW","Connection 2":"Press sleeve","Contour code connection 2":"DW","Connection 3":"Press sleeve","Contour code connection 3":"DW","Flange compression class":"PN 16","Material sealing":"Ethylene-propylene diene monomer rubber (EPDM)","Main colour fitting":"Grey","High tensile strength":"Yes","Max. operating pressure at 20 °C":"16bar","Max. operating pressure at 20 °C (imperial)":"232.22psi","Medium temperature (continuous)":"-40°C - 135°C","Medium temperature (continuous) (imperial)":"-40°F - 275°F","With sealing rings/gaskets":"No","With drain valve":"No","With de-aerator":"No","With thermal insulation":"No","With buffer stud":"Yes","Capped":"Yes","With connection indicator":"Yes","FM quality mark":"Yes","LPCB quality mark":"No","ULC quality mark":"Yes","UL quality mark":"Yes","VdS quality mark":"No","DVGW quality mark for gas":"No","DVGW quality mark for water":"No","KIWA certified":"No","Gastec QA mark":"No","KOMO certified":"No","Gastec QA - AR 214 (H2)":"No"} |
