Attributes
| Group Code | 418 |
|---|---|
| Brand Series | apollo-powerpress |
| Applications | heating, cooling, compressed air, sprinkler |
| Approvals | CRN, FM, IAPMO/ANSI/CAN Z1117, ICC LC1002, TSSA, UL, ULc |
| Solutions | fire protection, utility, industry |
Description
Apollo PowerPress® 418 is a reducer, designed for thick wall steel pipe. By using Apollo PowerPress® system installation times are reduced significantly and a clean working environment is assured. The range consists of DW-profile press fittings and valves in sizes 1/2" up to and including 2".
- outstanding corrosion resistance due to ZnNi coating
- clear identification of materials and dimensions
- Visu-Control-ring and Leak Before Pressed-function
Variations (10)
PWR7480693
| size | Ø3/4” x 1/2” |
|---|---|
| dimensions | 2.52x1.26x1.26 " |
| weight | 0.29 lb |
| packaging | Carton (5 pce) |
| d1 | 1.06 |
| DN1 | - |
| l1 | 1.37 |
| d2 | 0.84 |
| DN2 | - |
| l2 | 1.15 |
| z2 | 0.04 |
PWR7480704
| size | Ø1” x 1/2” |
|---|---|
| dimensions | 2.72x1.34x1.34 " |
| weight | 0.4 lb |
| packaging | Carton (5 pce) |
| d1 | 1.32 |
| DN1 | - |
| l1 | 1.56 |
| d2 | 0.84 |
| DN2 | - |
| l2 | 1.15 |
| z2 | 0.04 |
PWR7480715
| size | Ø1” x 3/4” |
|---|---|
| dimensions | 2.72x1.50x1.50 " |
| weight | 0.41 lb |
| packaging | Carton (5 pce) |
| d1 | 1.32 |
| DN1 | - |
| l1 | 1.45 |
| d2 | 1.05 |
| DN2 | - |
| l2 | 1.26 |
| z2 | 0.04 |
PWR7480748
| size | Ø1 1/4” x 1” |
|---|---|
| dimensions | 3.35x1.81x1.81 " |
| weight | 0.75 lb |
| packaging | Carton (1 pce) |
| d1 | 1.67 |
| DN1 | - |
| l1 | 1.88 |
| d2 | 1.32 |
| DN2 | - |
| l2 | 1.46 |
| z2 | 0.04 |
PWR7480761
| size | Ø1 1/2” x 3/4” |
|---|---|
| dimensions | 4.29x1.93x1.93 " |
| weight | 0.76 lb |
| packaging | Carton (1 pce) |
| d1 | 1.90 |
| DN1 | - |
| l1 | 2.48 |
| d2 | 1.05 |
| DN2 | - |
| l2 | 1.80 |
| z2 | 0.58 |
PWR7480770
| size | Ø1 1/2” x 1” |
|---|---|
| dimensions | 3.43x1.93x1.93 " |
| weight | 0.88 lb |
| packaging | Carton (1 pce) |
| d1 | 1.90 |
| DN1 | - |
| l1 | 1.95 |
| d2 | 1.32 |
| DN2 | - |
| l2 | 1.46 |
| z2 | 0.04 |
PWR7480781
| size | Ø1 1/2” x 1 1/4” |
|---|---|
| dimensions | 3.82x2.20x2.20 " |
| weight | 0.95 lb |
| packaging | Carton (1 pce) |
| d1 | 1.90 |
| DN1 | - |
| l1 | 1.88 |
| d2 | 1.66 |
| DN2 | - |
| l2 | 1.93 |
| z2 | 0.04 |
PWR7480814
| size | Ø2” x 1” |
|---|---|
| dimensions | 4.69x2.40x2.40 " |
| weight | 1.13 lb |
| packaging | Carton (1 pce) |
| d1 | 2.37 |
| DN1 | - |
| l1 | 2.71 |
| d2 | 1.32 |
| DN2 | - |
| l2 | 1.98 |
| z2 | 0.56 |
PWR7480825
| size | Ø2” x 1 1/4” |
|---|---|
| dimensions | 3.94x2.40x2.40 " |
| weight | 1.37 lb |
| packaging | Carton (1 pce) |
| d1 | 2.37 |
| DN1 | - |
| l1 | 1.88 |
| d2 | 1.66 |
| DN2 | - |
| l2 | 1.93 |
| z2 | 0.04 |
PWR7480836
| size | Ø2” x 1 1/2” |
|---|---|
| dimensions | 3.94x2.44x2.44 " |
| weight | 1.32 lb |
| packaging | Carton (1 pce) |
| d1 | 2.37 |
| DN1 | - |
| l1 | 1.95 |
| d2 | 1.90 |
| DN2 | - |
| l2 | 1.97 |
| z2 | 0.04 |
Specifications
| article | Apollo PowerPress reducer (press x insert) |
|---|---|
| article number with gtin | 418 |
| manufacturer | Aalberts integrated piping systems B.V. (VSH) |
| weight | 1.32 lb |
| dimensions | 3.94x2.44x2.44 " |
| color | grey |
| materials | steel (St 35 (1.0308)) |
| finishing | zinc-nickel plated |
| shape | straight, reducer |
| connection type | tube end, press (DW) |
| pressure rating (PN) | PN 16 |
| sealing | EPDM |
| max operating pressure liquid | 232 psi |
| min. medium temperature | -40 °F |
| max medium temperature | 275 °F |
| peak medium temperature | 302 °F |
| product group | fittings |
| ETIM class | EC003024 Fitting with 2 connections |
| intrastat code | 73079980 |
| country of origin | Netherlands |
| brand | Apollo |
| series | PowerPress |
| product type | 418 |
| unsps | 40173602 |
| ETIM | {"etim-class":"EC003024 Fitting with 2 connections","Material connection 1":"Steel","Material quality connection 1":"St 35 (1.0308)","Surface protection connection 1":"Zinc/nickel","Material connection 2":"Steel","Material quality connection 2":"St 35 (1.0308)","Surface protection connection 2":"Zinc/nickel","Shape":"Straight","Model":"1-part","Reducing":"Yes","Eccentric":"No","System specific":"Yes","Connection 1":"Soldered end","Connection 2":"Press sleeve","Contour code connection 2":"DW","Main colour fitting":"Grey","Flange compression class (PN)":"PN 16","Material sealing":"Ethylene-propylene diene monomer rubber (EPDM)","With buffer stud":"Yes","High tensile strength":"Yes","Medium temperature (continuous)":"-40°C - 135°C","Medium temperature (continuous) (imperial)":"-40°F - 275°F","Max. operating pressure at 20 °C":"16bar","Max. operating pressure at 20 °C (imperial)":"232.22psi","With thermal insulation":"No","With sealing rings/gaskets":"No","Capped":"Yes","With connection indicator":"Yes","With drain valve":"No","With de-aerator":"No","FM quality mark":"Yes","LPCB quality mark":"No","ULC quality mark":"Yes","UL quality mark":"Yes","DIN-CERTCO certificate":"No","VdS quality mark":"No","With approval for TÜV":"No","DVGW quality mark for gas":"No","DVGW quality mark for water":"No","Certified according to NF 545":"No","KIWA certified":"No","Gastec QA mark":"No","KOMO certified":"No","Gastec QA - AR 214 (H2)":"No","Type approval according to BBR/EKS":"No"} |
