Attributes
| Group Code | 3314X01 |
|---|---|
| Product Type | globe-valve |
| Brand Series | apollo-33-series-globe-valves |
| Applications | heating, cooling, steam |
| Approvals | Build America Buy America (BABA) Act, Buy American Act (BAA), CRN, Made in USA |
| Solutions | utility |
Description
The Apollo® Model 120S (33 Series) Globe Valve provides a cost effective “Made in the USA” alternative to globally sourced multi-turn valves. These valves are cast, machined, assembled, and tested in South Carolina. The Apollo® Globe valve can reliably be installed in most plumbing and heating systems (or building service piping).
- Optimum Flow Capacity
- Adjustable Graphite Stem Packing
- Dezincification Resistant
- All Bronze Construction
- 100% Factory Tested
- Solder Connection
- Screw-in Bonnet
- Malleable Iron Rugged Hand Wheel
- Back Seat Protection
- 100% Machined and Assembled in USA
Variations (5)
3314301
| size | 1/2" |
|---|---|
| dimensions | 3.00x1.50x4.25 " |
| weight | 1.06 lb |
| packaging | Carton (1 pce) |
| DN1 | - |
| DN2 | - |
3314401
| size | 3/4" |
|---|---|
| dimensions | 3.75x2.00x5.50 " |
| weight | 1.91 lb |
| packaging | Carton (1 pce) |
| DN1 | - |
| DN2 | - |
3314601
| size | 1-1/4" |
|---|---|
| dimensions | - |
| weight | 7.32 lb |
| packaging | Carton (1 pce) |
| DN1 | - |
| DN2 | - |
3314701
| size | 1-1/2" |
|---|---|
| dimensions | 6.00x3.25x8.75 " |
| weight | 6.86 lb |
| packaging | Carton (1 pce) |
| DN1 | - |
| DN2 | - |
3314801
| size | 2" |
|---|---|
| dimensions | 7.25x4.00x10.00 " |
| weight | 10.63 lb |
| packaging | Carton (1 pce) |
| DN1 | - |
| DN2 | - |
Specifications
| article | Apollo Class 125 Bronze Globe Valve (2 x Solder) |
|---|---|
| article number with gtin | 3314X01 |
| manufacturer | Aalberts integrated piping systems Americas, Inc. (Apollo) |
| weight | 10.63 lb |
| dimensions | 7.25x4.00x10.00 " |
| color | yellow |
| materials | bronze (ASTM B62) |
| finishing | none |
| connection type | solder |
| product group | valves (globe valves) |
| ETIM class | EC010120 Globe valve |
| country of origin | United States |
| brand | Apollo |
| series | 33 Series Globe Valves |
| product type | 3314X01 |
| unsps | 40141611 |
| ETIM | {"etim-class":"EC010120 Globe valve","Housing material":"Bronze","Connection 1":"Soldered sleeve","Connection 2":"Soldered sleeve","Surface protection":"Untreated","Operation":"Hand wheel","Suitable for liquids":"Yes","Suitable for gases":"No","Suitable for steam":"Yes","VdS quality mark":"No","KIWA certified":"No","Gastec QA mark":"No","Gastec QA - AR 214 (H2)":"No"} |
