Attributes
| Group Code | 3374X01 |
|---|---|
| Product Type | globe-valve |
| Brand Series | apollo-33-series-globe-valves |
| Applications | heating, cooling, steam |
| Approvals | Build America Buy America (BABA) Act, Buy American Act (BAA), CRN, Made in USA |
| Solutions | utility |
Description
The Apollo® Model 128T (33-74 Series) Globe Valve with SS disc and seat ring provides a cost effective “Made in the USA” alternative to globally sourced multi-turn valves. These heavy duty valves are cast, machined, assembled, and tested in South Carolina. Apollo® globe valves are ideal for steam and liquid service and can reliably be installed in most plumbing and heating systems including building service piping and OEM applications.
- Hardened Stainless Steel Disc & Seat Ring
- Adjustable Graphite Stem Packing
- NPT Connections
- Union Bonnet
- Rising Stem
- Back Seat Protection
- Dezincification Resistant Bronze Construction
- Rugged Malleable Iron Hand Wheel
- Optimum Flow Capacity
- 100% Factory Tested to MSS SP-80
- 100% Machined and Assembled in USA
- ARRA Compliant
Variations (3)
3374301
| size | 1/2" |
|---|---|
| dimensions | - |
| weight | 1.82 lb |
| packaging | Carton (1 pce) |
| DN1 | - |
| DN2 | - |
3374401
| size | 3/4" |
|---|---|
| dimensions | - |
| weight | 2.28 lb |
| packaging | Carton (1 pce) |
| DN1 | - |
| DN2 | - |
3374801
| size | 2" |
|---|---|
| dimensions | 10.00x4.00x6.00 " |
| weight | 15.13 lb |
| packaging | Carton (1 pce) |
| DN1 | - |
| DN2 | - |
Specifications
| article | Apollo Class 300 Bronze Globe Valve (2 x FNPT) |
|---|---|
| article number with gtin | 3374X01 |
| manufacturer | Aalberts integrated piping systems Americas, Inc. (Apollo) |
| weight | 15.13 lb |
| dimensions | 10.00x4.00x6.00 " |
| color | yellow |
| materials | bronze (ASTM B61) |
| finishing | none |
| connection type | FPT - female thread conical (NPT) |
| product group | valves (globe valves) |
| ETIM class | EC010120 Globe valve |
| country of origin | United States |
| brand | Apollo |
| series | 33 Series Globe Valves |
| product type | 3374X01 |
| unsps | 40141611 |
| ETIM | {"etim-class":"EC010120 Globe valve","Housing material":"Bronze","Connection 1":"Internal thread conical (NPT)","Connection 2":"Internal thread conical (NPT)","Surface protection":"Untreated","Operation":"Hand wheel","Suitable for liquids":"Yes","Suitable for gases":"No","Suitable for steam":"Yes","VdS quality mark":"No","KIWA certified":"No","Gastec QA mark":"No","Gastec QA - AR 214 (H2)":"No"} |
