Attributes
| Group Code | CSJL024A |
|---|---|
| Product Type | kogelafsluiters |
| Brand Series | apollo-cs-top-entry-ball-valves |
Description
Apollo's Top Entry Ball Valves deliver additional premiums; a broader choice of material for both internal and external components, more optional features to choose from, and selectable seal material combinations all resulting in an expanded serviceable application range.
• Self-Adjusting Seats Compensate for Wear & Temperature Fluctuations
• Spring-Loaded, Low-Pressure Seals
• Pressure Activated Seating
• Built-In Antistatic Feature
Variations (5)
CSJL324A
| size | 1/2" |
|---|---|
| dimensions | - |
| weight | 7.5 lb |
| packaging | Carton (1 pce) |
| DN1 | - |
| DN2 | - |
CSJL424A
| size | 3/4" |
|---|---|
| dimensions | - |
| weight | 7.5 lb |
| packaging | Carton (1 pce) |
| DN1 | - |
| DN2 | - |
CSJL524A
| size | 1" |
|---|---|
| dimensions | - |
| weight | 7.5 lb |
| packaging | Carton (1 pce) |
| DN1 | - |
| DN2 | - |
CSJL724A
| size | 1-1/2" |
|---|---|
| dimensions | - |
| weight | 13.5 lb |
| packaging | Carton (1 pce) |
| DN1 | - |
| DN2 | - |
CSJL824A
| size | 2" |
|---|---|
| dimensions | - |
| weight | 23.3 lb |
| packaging | Carton (1 pce) |
| DN1 | - |
| DN2 | - |
Specifications
| article | Apollo Carbon Steel Class 600 Standard Port Top Entry Ball Valve with 316L SS Trim, Multi-Seal TFM Seats, Graphite Packing, Spiral Wound Graphite Gasket (2 x Socket Weld) |
|---|---|
| article number with gtin | CSJL024A |
| manufacturer | Aalberts integrated piping systems Americas, Inc. (Apollo) |
| weight | 23.3 lb |
| color | black |
| materials | steel (ASTM A216 WCB) |
| finishing | none |
| connection type | weld |
| product group | valves (ball valves) |
| ETIM class | EC011343 Ball valve |
| country of origin | United States |
| brand | Apollo |
| series | CS Top Entry Ball Valves |
| product type | CSJL024A |
| unsps | 40141607 |
| ETIM | {"etim-class":"EC011343 Ball valve","Housing material":"Steel","Surface protection housing":"None","Material ball":"Stainless steel","Material spindle":"Stainless steel","Connection 1":"Welded end","Connection 2":"Welded end","With filter":"No","FM quality mark":"No","UL quality mark":"No","ULC quality mark":"No","LPCB quality mark":"No","Medically clean":"No","Grease-free":"No","Full bore":"No","VdS quality mark":"No","DVGW quality mark for gas":"No","DVGW quality mark for water":"No","KIWA certified":"No"} |
PDF Documents
[Datasheet] CSSW Submittal Sheet
Open PDF
