Attributes
| Group Code | 83A64X01 |
|---|---|
| Product Type | kogelafsluiters |
| Brand Series | apollo-83a-series-ball-valves |
| Applications | heating, cooling, steam, compressed air, vacuum |
| Approvals | CRN, PED 2014/68/EU – Module H |
| Solutions | utility, industry |
Description
The 83A-640 Carbon Steel 3 Piece Full Port Ball Valve exemplifies a combination of durability and high performance. It boasts a 3-piece construction with enclosed fasteners and a full port for maximizing flow efficiency. Key features encompass a swing-out center section, a pressure balanced solid ball, and compression controlled RPTFE gaskets.
• 3-piece construction w/ enclosed fasteners
• full port
• stainless steel trim & hardware
• swing-out center section
• pressure balanced solid ball
• compression controlled RPTFE gaskets
• anti-blowout one piece bottom entry stem
• two-position locking
• adjustable multi-piece PTFE “V” style packing
• fully machined ISO 5211 mounting
• cast bosses on the center-section and end caps for bleed & drain ports
• vacuum service to 29 in of Hg.
• 150 psi saturated steam
Variations (5)
83A64301
| size | 1/2" |
|---|---|
| dimensions | 8.75x2.75x6.00 " |
| weight | 2.3 lb |
| packaging | Carton (1 pce) |
| DN1 | - |
| DN2 | - |
83A64401
| size | 3/4" |
|---|---|
| dimensions | 8.75x2.75x6.00 " |
| weight | 3.6 lb |
| packaging | Carton (1 pce) |
| DN1 | - |
| DN2 | - |
83A64501
| size | 1" |
|---|---|
| dimensions | 8.75x2.75x6.00 " |
| weight | 5.7 lb |
| packaging | Carton (1 pce) |
| DN1 | - |
| DN2 | - |
83A64701
| size | 1-1/2" |
|---|---|
| dimensions | 8.75x2.75x6.00 " |
| weight | 14.38 lb |
| packaging | Carton (1 pce) |
| DN1 | - |
| DN2 | - |
83A64801
| size | 2" |
|---|---|
| dimensions | 8.75x2.75x6.00 " |
| weight | 27.6 lb |
| packaging | Carton (1 pce) |
| DN1 | - |
| DN2 | - |
Specifications
| article | Apollo Carbon Steel 3 Piece Full Port Ball Valve with Standard Configuration (2 x Sch 80 Butt Weld) |
|---|---|
| article number with gtin | 83A64X01 |
| manufacturer | Aalberts integrated piping systems Americas, Inc. (Apollo) |
| weight | 27.6 lb |
| dimensions | 8.75x2.75x6.00 " |
| color | black |
| materials | steel (ASTM A216 WCB) |
| finishing | none |
| shape | straight |
| connection type | butt Weld |
| product group | valves (ball valves) |
| ETIM class | EC011343 Ball valve |
| country of origin | United States |
| brand | Apollo |
| series | 83A Series Ball Valves |
| product type | 83A64X01 |
| unsps | 40141607 |
| ETIM | {"etim-class":"EC011343 Ball valve","Housing material":"Steel","Surface protection housing":"None","Material ball":"Stainless steel","Material spindle":"Stainless steel","With filter":"No","FM quality mark":"No","UL quality mark":"No","ULC quality mark":"No","LPCB quality mark":"No","Medically clean":"No","Grease-free":"No","Housing construction":"3-part","Full bore":"Yes","VdS quality mark":"No","DVGW quality mark for gas":"No","DVGW quality mark for water":"No","KIWA certified":"No"} |
