Attributes
| Group Code | 76F10X1446GSA |
|---|---|
| Product Type | kogelafsluiters |
| Brand Series | apollo-76f-series-ball-valves |
| Approvals | American Iron & Steel (AIS), Build America Buy America (BABA) Act, Buy American Act (BAA), CRN, Made in USA |
Description
The Apollo Valves 76F Series is a two piece full port stainless steel ball valve.
- 316 SS Investment Cast Components
- RPTFE Seats
- Two-Piece Body
- Blowout-Proof Stem Design
- Adjustable Packing Gland
- Meets NACE MR-01-75-2000
- SS Lever & Nut
- Proudly Made in USA
Variations (3)
76F1031446GSA
| size | 1/2" |
|---|---|
| dimensions | - |
| weight | 0.57 lb |
| packaging | - |
76F1041446GSA
| size | 3/4" |
|---|---|
| dimensions | - |
| weight | 0.91 lb |
| packaging | - |
76F1071446GSA
| size | 1-1/2" |
|---|---|
| dimensions | - |
| weight | 4.69 lb |
| packaging | - |
Specifications
| article | Apollo 2 Piece Full Port Stainless Steel Ball Valve with Side Vented Ball, Latch Lock Lever-Locked in Closed Position Only, CSA CGA 3.16 Compliant Approved (2 x FNPT) |
|---|---|
| article number with gtin | 76F10X1446GSA |
| manufacturer | Aalberts integrated piping systems Americas, Inc. (Apollo) |
| weight | 4.69 lb |
| materials | stainless steel |
| connection type | FPT - female thread conical (NPT) |
| Bore | 38.1 mm (No) |
| product group | valves (ball valves) |
| ETIM class | EC011343 Ball valve |
| brand | Apollo |
| series | 76F Series Ball Valves |
| product type | 76F10X1446GSA |
| ETIM | {"etim-class":"EC011343 Ball valve","Housing material":"Stainless steel","Connection 1":"Internal thread conical (NPT)","Connection 2":"Internal thread conical (NPT)","With filter":"No","UL quality mark":"No","ULC quality mark":"No","FM quality mark":"No","LPCB quality mark":"No","Medically clean":"No","Grease-free":"No","Housing construction":"2-part","VdS quality mark":"No","DVGW quality mark for gas":"No","DVGW quality mark for water":"No","KIWA certified":"No"} |
