Attributes
| Group Code | 86C20X0424TR |
|---|---|
| Product Type | kogelafsluiters |
| Brand Series | apollo-86c-series-ball-valves |
| Approvals | CRN |
Description
The 86C-200 Stainless Steel, Alloy 20, 3 Piece Full Port Ball Valve is a reliable and versatile solution for demanding applications. Its 3-piece construction with enclosed fasteners ensures durability, while the full port and swing-out center section allow for optimal fluid flow. Featuring a pressure balanced solid ball, compression controlled spiral wound gaskets, and anti-blowout one-piece bottom entry stem, this valve provides enhanced safety and performance.
• 3-piece construction w/ enclosed fasteners
• full port
• stainless steel trim & hardware
• swing-out center section
• pressure balanced solid ball
• compression controlled spiral wound gaskets
• anti-blowout one piece bottom entry stem
• statically grounded ball, stem, & body
• two-position locking
• adjustable multi-piece PTFE “V” style packing
• fully machined ISO5211 mounting
• cast bosses on the center-section and end caps for bleed & drain ports
• fire safe “by design” (requires -24 suffix)
• vacuum service to 29 in of Hg.
• CE Marking, 1-1/4” and larger (add “-CE” suffix)
• 250 psi saturated steam
Variations (1)
86C2080424TR
| size | 2" |
|---|---|
| dimensions | - |
| weight | 27.6 lb |
| packaging | - |
Specifications
| article | Apollo Stainless Steel, Alloy 20, 3 Piece Full Port Ball Valve with 2-1/4" Stem Extension, Graphite Packing, Spiral Wound Graphite Body Seal, PTFE/PEEK Bearing, Hydrostatic Tested with Certification & MTR (2 x Socket Weld) |
|---|---|
| article number with gtin | 86C20X0424TR (00191988014629) |
| manufacturer | Aalberts integrated piping systems Americas, Inc. (Apollo) |
| size | 2" |
| weight | 27.6 lb |
| materials | stainless steel |
| connection type | weld |
| product group | valves (ball valves) |
| ETIM class | EC011343 Ball valve |
| brand | Apollo |
| series | 86C Series Ball Valves |
| product type | 86C20X0424TR |
| ETIM | {"etim-class":"EC011343 Ball valve","Housing material":"Stainless steel","Connection 1":"Welded end","Connection 2":"Welded end","With filter":"No","FM quality mark":"No","UL quality mark":"No","ULC quality mark":"No","LPCB quality mark":"No","Medically clean":"No","Grease-free":"No","Housing construction":"3-part","VdS quality mark":"No","DVGW quality mark for gas":"No","DVGW quality mark for water":"No","KIWA certified":"No"} |
