Attributes
| Group Code | 83R74X01 |
|---|---|
| Product Type | kogelafsluiters |
| Brand Series | apollo-83r-series-ball-valves |
| Solutions | utility, industry |
Description
The 83R-740 Carbon Steel 3 Piece Full Port Ball Valve with Actuator Ready ISO Mounting Pad stands out with its advanced design and robust functionality. It integrates an ISO5211 mounting pad, blowout-proof stem design, and in-line repairability for exceptional performance and safety. Reinforced seats, seals, and a full port configuration ensure optimal fluid flow.
• multi-piece packing set
• ISO 5211 mounting pad
• blowout-proof stem design
• in-line repairable
• adjustable packing gland
• investment cast components
• reinforced seat sand seals
• full port configuration
Variations (1)
83R74801
| size | 2" |
|---|---|
| dimensions | 10.65x2.67x5.69 " |
| weight | 12.51 lb |
| packaging | Carton (1 pce) |
Specifications
| article | Apollo Carbon Steel 3 Piece Full Port Ball Valve with Actuator Ready ISO Mounting Pad, Standard Configuration (2 x Sch 40 Butt-Weld) |
|---|---|
| article number with gtin | 83R74X01 (00670750253867) |
| manufacturer | Aalberts integrated piping systems Americas, Inc. (Apollo) |
| size | 2" |
| weight | 12.51 lb |
| dimensions | 10.65x2.67x5.69 " |
| materials | steel |
| shape | straight |
| connection type | butt Weld |
| product group | valves (ball valves) |
| ETIM class | EC011343 Ball valve |
| country of origin | United States |
| brand | Apollo |
| series | 83R Series Ball Valves |
| product type | 83R74X01 |
| unsps | 40141607 |
| ETIM | {"etim-class":"EC011343 Ball valve","Housing material":"Steel","With filter":"No","FM quality mark":"No","UL quality mark":"No","ULC quality mark":"No","LPCB quality mark":"No","Medically clean":"No","Grease-free":"No","Housing construction":"3-part","VdS quality mark":"No","DVGW quality mark for gas":"No","DVGW quality mark for water":"No","KIWA certified":"No"} |
PDF Documents
[Datasheet] 83R-700 Submittal Sheet
Open PDF
