Attributes
| Group Code | 3210X02 |
|---|---|
| Product Type | kogelafsluiters |
| Brand Series | apollo-32-series-ball-valves |
| Applications | heating, cooling, steam |
| Approvals | Build America Buy America (BABA) Act, Buy American Act (BAA), CRN, Made in USA |
| Solutions | utility |
Description
The Apollo Valves 32-100 Series is an economy NPT threaded regular port bronze ball valve featuring a proven ASTM grade cast bronze body for durability and superior corrosion resistance.
- Adjustable Packing Gland
- Blow-Out Proof Stem Design
- PTFE Seats and RPTFE Stem Packing
- Chromium Plated Ball
- 100% Factory Tested
Variations (1)
3210202
| size | 3/8" |
|---|---|
| dimensions | - |
| weight | 0.27 lb |
| packaging | Carton (1 pce) |
| DN1 | - |
| DN2 | - |
Specifications
| article | Apollo Standard Regular Port Threaded Bronze Ball Valve with Stem Grounded (2 x FNPT) |
|---|---|
| article number with gtin | 3210X02 (00670750560118) |
| manufacturer | Aalberts integrated piping systems Americas, Inc. (Apollo) |
| size | 3/8" |
| weight | 0.27 lb |
| color | bronze, yellow |
| materials | bronze (ASTM B584-C84400) |
| finishing | none |
| shape | straight |
| connection type | FPT - female thread conical (NPT) |
| max operating pressure liquid | 400 psi |
| product group | valves (ball valves) |
| ETIM class | EC011343 Ball valve |
| country of origin | United States |
| brand | Apollo |
| series | 32 Series Ball Valves |
| product type | 3210X02 |
| unsps | 40141607 |
| ETIM | {"etim-class":"EC011343 Ball valve","Housing material":"Bronze","Surface protection housing":"None","Material ball":"Brass","Material spindle":"Brass","Material primary spindle seal":"Polytetrafluoroethylene (PTFE)","Nominal diameter connection 1":"DN 10","Connection 1":"Internal thread conical (NPT)","Nominal diameter connection 2":"DN 10","Connection 2":"Internal thread conical (NPT)","With filter":"No","FM quality mark":"No","UL quality mark":"No","ULC quality mark":"No","LPCB quality mark":"No","Medically clean":"No","Grease-free":"No","Housing construction":"2-part","Full bore":"No","VdS quality mark":"No","DVGW quality mark for gas":"No","DVGW quality mark for water":"No","KIWA certified":"No"} |
