Attributes
| Group Code | 86G60X01 |
|---|---|
| Product Type | kogelafsluiters |
| Brand Series | apollo-86g-series-ball-valves |
| Approvals | CRN |
Description
The 86G-600 Stainless Steel 3 Piece Full Port Class 600 Ball Valve is a robust and versatile solution, designed for effective fluid control. Its architecture boasts a swing-out center section and a pressure balanced solid ball, thereby ensuring exceptional performance. Safety and reliability are emphasized with features like compression controlled RPTFE gaskets and an anti-blowout one piece bottom entry stem.
• 3-piece construction w/ enclosed fasteners
• Full port
• Stainless steel trim & hardware
• Swing-out center section
• Pressure balanced solid ball
• Compression controlled RPTFE gaskets
• Anti-blowout one piece bottom entry stem
• Two-position locking
• Adjustable multi-piece PTFE “V” style packing
• Fully machined ISO5211 mounting
• Cast bosses on the center-section and end caps for bleed & drain ports
• Vacuum service to 29 in of Hg.
• 150 psi saturated steam
Variations (1)
86G60301
| size | 1/2" |
|---|---|
| dimensions | - |
| weight | 2.3 lb |
| packaging | - |
Specifications
| article | Apollo Stainless Steel 3 Piece Full Port Class 600 Ball Valve with Standard Configuration (2 x Sch 80 Butt Weld) |
|---|---|
| article number with gtin | 86G60X01 (00191988118037) |
| manufacturer | Aalberts integrated piping systems Americas, Inc. (Apollo) |
| size | 1/2" |
| weight | 2.3 lb |
| materials | stainless steel |
| connection type | butt Weld |
| product group | valves (ball valves) |
| ETIM class | EC011343 Ball valve |
| brand | Apollo |
| series | 86G Series Ball Valves |
| product type | 86G60X01 |
| ETIM | {"etim-class":"EC011343 Ball valve","Housing material":"Stainless steel","With filter":"No","FM quality mark":"No","UL quality mark":"No","ULC quality mark":"No","LPCB quality mark":"No","Medically clean":"No","Grease-free":"No","Housing construction":"3-part","VdS quality mark":"No","DVGW quality mark for gas":"No","DVGW quality mark for water":"No","KIWA certified":"No"} |
