Attributes
| Group Code | 86J20X01 |
|---|---|
| Product Type | kogelafsluiters |
| Brand Series | apollo-86j-series-ball-valves |
| Approvals | CRN |
Description
The 86J-200 Duplex Stainless Steel 3 Piece Full Port Ball Valve is a powerful solution designed for effective fluid flow control. The design incorporates a swing-out center section and a pressure balanced solid ball, contributing to superior performance. Safety and functionality are further increased by features such as compression controlled spiral wound gaskets and an anti-blowout one piece bottom entry stem, with the addition of static grounding for the ball, stem, and body.
• 3-piece construction w/ enclosed fasteners
• Full port
• Stainless steeltrim & hardware
• Swing-out center section
• Pressure balanced solid ball
• Compression controlled spiral wound gaskets
• Anti-blowout one piece bottom entry stem
• Statically grounded ball, stem, & body
• Two-position locking
• Adjustable multi-piece PTFE “V” style packing
• Fully machined ISO5211 mounting
• Cast bosses on the center-section and end caps for bleed & drain ports
• Fire safe “by design” (requires -24 suffix)
• Vacuum service to 29 in of Hg.
• CE Marking, 1-1/4” and larger (add “-CE” suffix)
• 250 psi saturated steam (with “-24” option)
Variations (5)
86J20301
| size | 1/2" |
|---|---|
| dimensions | - |
| weight | 2.3 lb |
| packaging | - |
86J20401
| size | 3/4" |
|---|---|
| dimensions | - |
| weight | 4 lb |
| packaging | - |
86J20501
| size | 1" |
|---|---|
| dimensions | - |
| weight | 5.7 lb |
| packaging | - |
86J20701
| size | 1-1/2" |
|---|---|
| dimensions | - |
| weight | 14.4 lb |
| packaging | - |
86J20801
| size | 2" |
|---|---|
| dimensions | - |
| weight | 24.35 lb |
| packaging | - |
Specifications
| article | Apollo Duplex Stainless Steel 3 Piece Full Port Ball Valve with Standard Configuration (2 x Socket Weld) |
|---|---|
| article number with gtin | 86J20X01 |
| manufacturer | Aalberts integrated piping systems Americas, Inc. (Apollo) |
| weight | 24.35 lb |
| materials | stainless steel |
| connection type | weld |
| product group | valves (ball valves) |
| ETIM class | EC011343 Ball valve |
| brand | Apollo |
| series | 86J Series Ball Valves |
| product type | 86J20X01 |
| ETIM | {"etim-class":"EC011343 Ball valve","Housing material":"Stainless steel","Connection 1":"Welded end","Connection 2":"Welded end","With filter":"No","FM quality mark":"No","UL quality mark":"No","ULC quality mark":"No","LPCB quality mark":"No","Medically clean":"No","Grease-free":"No","Housing construction":"3-part","VdS quality mark":"No","DVGW quality mark for gas":"No","DVGW quality mark for water":"No","KIWA certified":"No"} |
