Apollo SmartPress straight union EPDM (2 x press)

Scraped SKU: 5733E-Apollo 2026-06-05 04:24:34

Attributes

Group Code5733E-Apollo
Product Typemeerdelig
Brand Seriesapollo-smartpress
Applicationspotable water, heating, cooling, steam, compressed air, sprinkler, vacuum
ApprovalsASTM F3226/F3226M, CRN, FM, IAPMO/ANSI/CAN Z1117, NSF/ANSI 372, NSF/ANSI 61, UL, ULc
Solutionsfire protection, utility, industry

Description

Apollo SmartPress is an innovative press connection system designed for joining ½”-2” IPS ASTM A312 schedule 5/10s stainless steel pipe (approved for use with both AISI type 304/304L and 316/316L stainless). The Apollo SmartPress product range consists of V-profile (type ASP) press fittings and valves produced from AISI 316L stainless steel alloy that are fitted with patented sealing elements for a guaranteed safe, leak-tight and lasting connection. The Apollo SmartPress system offers end-users a complete solution with maximum coverage of commercial and industrial applications requiring HNBR, EPDM, or FKM sealing elements.
  • complete range of AISI 316 fittings and valves
  • 500 psi operating pressure
  • color-coded Visu-control® foil for material/dimensions identification and visual press indication
  • patented sealing element design with Leak Before Press® technology for added safety and optimized installation
    clear identification of sealing element and dimensions
  • quick installation thanks to pre-marked insertion depth

Variations (6)

123457022

size1/2"
dimensions6.50x1.77x1.61 "
weight3.09 lb
packagingBag (5 pce)
d10.84
DN1-
l13.16
z12.09
slw11.614
d20.84
DN2-
l23.32
z22.25
slw21.102

123457023

size3/4"
dimensions6.85x2.05x1.81 "
weight3.75 lb
packagingBag (5 pce)
d11.06
DN1-
l13.37
z12.31
slw11.811
d21.06
DN2-
l23.45
z22.39
slw21.417

123457024

size1"
dimensions7.36x2.36x2.17 "
weight4.41 lb
packagingBag (2 pce)
d11.33
DN1-
l13.56
z12.38
slw12.165
d21.33
DN2-
l23.80
z22.61
slw21.614

123460805

size1 1/4"
dimensions8.03x3.31x2.95 "
weight3.48 lb
packagingBag (1 pce)
d11.90
DN1-
l13.91
z12.53
slw12.953
d21.90
DN2-
l24.11
z22.73
slw22.362

123457025

size1 1/2"
dimensions8.03x3.31x2.95 "
weight3.48 lb
packagingBag (1 pce)
d11.90
DN1-
l13.91
z12.53
slw12.953
d21.90
DN2-
l24.11
z22.73
slw22.362

123457026

size2"
dimensions8.15x4.09x3.66 "
weight5.17 lb
packagingBag (1 pce)
d12.37
DN1-
l14.02
z12.41
slw13.661
d22.37
DN2-
l24.10
z22.48
slw22.913

Specifications

articleApollo SmartPress straight union EPDM (2 x press)
article number with gtin5733E-Apollo
manufacturerAalberts integrated piping systems B.V. (VSH)
weight5.17 lb
dimensions8.15x4.09x3.66 "
colorsilver
materialsstainless steel (Stainless steel 316L (1.4404))
finishingnone
shapestraight
connection typepress (V)
sealingEPDM
max operating pressure liquid500 psi
min. medium temperature-31 °F
max medium temperature275 °F
peak medium temperature302 °F
product groupfittings (unions)
ETIM classEC003024 Fitting with 2 connections
intrastat code73072980
country of originNetherlands
brandApollo
seriesSmartPress
product type5733E
unsps40174907
ETIM
{"etim-class":"EC003024 Fitting with 2 connections","Material connection 1":"Stainless steel","Material quality connection 1":"Stainless steel 316 L (1.4404)","Surface protection connection 1":"Untreated","Surface treatment connection 1":"Untreated","Material connection 2":"Stainless steel","Material quality connection 2":"Stainless steel 316 L (1.4404)","Surface protection connection 2":"Untreated","Surface treatment connection 2":"Untreated","Shape":"Straight","Reducing":"No","Eccentric":"No","System specific":"Yes","Connection 1":"Press sleeve","Contour code connection 1":"V","Connection 2":"Press sleeve","Contour code connection 2":"V","Main colour fitting":"Grey","Material sealing":"Ethylene-propylene diene monomer rubber (EPDM)","With buffer stud":"Yes","Medium temperature (continuous)":"-35°C - 135°C","Medium temperature (continuous) (imperial)":"-31°F - 275°F","Max. operating pressure at 20 °C":"34.47bar","Max. operating pressure at 20 °C (imperial)":"500psi","With sealing rings/gaskets":"No","Capped":"No","With connection indicator":"Yes","With drain valve":"No","With de-aerator":"No","FM quality mark":"Yes","LPCB quality mark":"No","ULC quality mark":"Yes","UL quality mark":"Yes","VdS quality mark":"No","DVGW quality mark for gas":"No","DVGW quality mark for water":"No","KIWA certified":"No","Gastec QA mark":"No","KOMO certified":"No","Gastec QA - AR 214 (H2)":"No"}
