Apollo SmartPress van stone class 150 FKM (1 x press)

Scraped SKU: 5772F-Apollo 2026-06-05 04:24:34

Attributes

Group Code5772F-Apollo
Brand Seriesapollo-smartpress
Applicationsheating, cooling, compressed air, vacuum
ApprovalsASTM F3226/F3226M, CRN, IAPMO/ANSI/CAN Z1117
Solutionsutility, industry

Description

Apollo SmartPress is an innovative press connection system designed for joining ½”-2” IPS ASTM A312 schedule 5/10s stainless steel pipe (approved for use with both AISI type 304/304L and 316/316L stainless). The Apollo SmartPress product range consists of V-profile (type ASP) press fittings and valves produced from AISI 316L stainless steel alloy that are fitted with patented sealing elements for a guaranteed safe, leak-tight and lasting connection. The Apollo SmartPress system offers end-users a complete solution with maximum coverage of commercial and industrial applications requiring HNBR, EPDM, or FKM sealing elements.
  • complete range of AISI 316 fittings and valves
  • 500 psi operating pressure
  • color-coded Visu-control® foil for material/dimensions identification and visual press indication
  • patented sealing element design with Leak Before Press® technology for added safety and optimized installation
    clear identification of sealing element and dimensions
  • quick installation thanks to pre-marked insertion depth

Variations (6)

123457130

size1/2"
dimensions3.54x3.54x3.35 "
weight1.19 lb
packagingBag (1 pce)
d10.84
DN1-
l13.33
z12.27
d20.84
DN2-
n2-
k22.38
d2-20.63
D23.5

123457131

size3/4"
dimensions3.94x3.94x3.35 "
weight1.66 lb
packagingBag (1 pce)
d11.06
DN1-
l13.33
z12.27
d21.06
DN2-
n2-
k23.25
d2-20.63
D24.61

123457132

size1"
dimensions4.33x4.33x3.50 "
weight2.36 lb
packagingBag (1 pce)
d11.33
DN1-
l13.50
z12.32
d21.33
DN2-
n2-
k23.12
d2-20.62
D24.25

123460828

size1 1/4"
dimensions4.92x4.92x3.70 "
weight3.64 lb
packagingBag (1 pce)
d11.90
DN1-
l12.83
z11.45
d21.90
DN2-
n2-
k23.88
d2-20.62
D25

123457133

size1 1/2"
dimensions4.92x4.92x3.70 "
weight3.64 lb
packagingBag (1 pce)
d11.90
DN1-
l13.68
z12.30
d21.90
DN2-
n2-
k23.88
d2-20.62
D25

123457134

size2"
dimensions5.91x5.91x4.41 "
weight6.05 lb
packagingBag (1 pce)
d12.37
DN1-
l14.42
z12.81
d22.37
DN2-
n2-
k24.75
d2-20.75
D26

Specifications

articleApollo SmartPress van stone class 150 FKM (1 x press)
article number with gtin5772F-Apollo
manufacturerAalberts integrated piping systems B.V. (VSH)
weight6.05 lb
dimensions5.91x5.91x4.41 "
colorsilver
materialsstainless steel (Stainless steel 316L (1.4404))
finishingnone, primer/paint
shapestraight
connection typepress (V), flange
sealingFKM
max operating pressure liquid500 psi
min. medium temperature-4 °F
max medium temperature392 °F
peak medium temperature446 °F
product groupfittings
ETIM classEC003024 Fitting with 2 connections
intrastat code73072980
country of originNetherlands
brandApollo
seriesSmartPress
product type5772F
unsps40174006
ETIM
{"etim-class":"EC003024 Fitting with 2 connections","Material connection 1":"Stainless steel","Material quality connection 1":"Stainless steel 316 L (1.4404)","Surface protection connection 1":"Untreated","Surface treatment connection 1":"Untreated","Material connection 2":"Steel","Shape":"Straight","Reducing":"No","Eccentric":"No","System specific":"Yes","Connection 1":"Press sleeve","Contour code connection 1":"V","Connection 2":"Flange","Main colour fitting":"Grey","Material sealing":"Fluorelastomer rubber (FPM/FKM)","With buffer stud":"Yes","Medium temperature (continuous)":"-20°C - 200°C","Medium temperature (continuous) (imperial)":"-4°F - 392°F","Max. operating pressure at 20 °C":"34.47bar","Max. operating pressure at 20 °C (imperial)":"500psi","With sealing rings/gaskets":"No","Capped":"No","With connection indicator":"Yes","With drain valve":"No","With de-aerator":"No","FM quality mark":"No","LPCB quality mark":"No","ULC quality mark":"No","UL quality mark":"No","VdS quality mark":"No","DVGW quality mark for gas":"No","DVGW quality mark for water":"No","KIWA certified":"No","Gastec QA mark":"No","KOMO certified":"No","Gastec QA - AR 214 (H2)":"No"}
