Attributes
| Group Code | 57 |
|---|---|
| Product Type | demontabel |
| Brand Series | vsh-shurjoint |
| Approvals | CRN |
Description
The VSH Shurjoint Model 57 nipple allows for a direct connection with grooved couplings.
Variations (13)
SJT571254B
| size | 1 1/4"x4L black |
|---|---|
| dimensions | 4.02x1.66x1.66 " |
| weight | 0.68 lb |
| packaging | - |
| d1 | 1.66 |
| DN1 | - |
| l1 | 2.01 |
| d2 | 1.66 |
| DN2 | - |
| l2 | 2.01 |
SJT57154B
| size | 1 1/2"x4L black |
|---|---|
| dimensions | 4.02x1.90x1.90 " |
| weight | 0.82 lb |
| packaging | - |
| d1 | 1.90 |
| DN1 | - |
| l1 | 2.01 |
| d2 | 1.90 |
| DN2 | - |
| l2 | 2.01 |
SJT57156B
| size | 1 1/2"x6L black |
|---|---|
| dimensions | 5.98x1.90x1.90 " |
| weight | 1.37 lb |
| packaging | - |
| d1 | 1.90 |
| DN1 | - |
| l1 | 2.99 |
| d2 | 1.90 |
| DN2 | - |
| l2 | 2.99 |
SJT5724B
| size | 2"x4L black |
|---|---|
| dimensions | 4.02x2.37x2.37 " |
| weight | 1.1 lb |
| packaging | - |
| d1 | 2.37 |
| DN1 | - |
| l1 | 2.01 |
| d2 | 2.37 |
| DN2 | - |
| l2 | 2.01 |
SJT5726B
| size | 2"x6L black |
|---|---|
| dimensions | 5.98x2.37x2.37 " |
| weight | 1.98 lb |
| packaging | - |
| d1 | 2.37 |
| DN1 | - |
| l1 | 2.99 |
| d2 | 2.37 |
| DN2 | - |
| l2 | 2.99 |
SJT57254B
| size | 2 1/2"x4L black |
|---|---|
| dimensions | 4.02x2.87x2.87 " |
| weight | 1.76 lb |
| packaging | - |
| d1 | 2.87 |
| DN1 | - |
| l1 | 2.01 |
| d2 | 2.87 |
| DN2 | - |
| l2 | 2.01 |
SJT57256B
| size | 2 1/2"x6L black |
|---|---|
| dimensions | 5.98x2.87x2.87 " |
| weight | 2.98 lb |
| packaging | - |
| d1 | 2.87 |
| DN1 | - |
| l1 | 2.99 |
| d2 | 2.87 |
| DN2 | - |
| l2 | 2.99 |
SJT5734B
| size | 3"x4L black |
|---|---|
| dimensions | 4.02x3.50x3.50 " |
| weight | 2.43 lb |
| packaging | - |
| d1 | 3.50 |
| DN1 | - |
| l1 | 2.01 |
| d2 | 3.50 |
| DN2 | - |
| l2 | 2.01 |
SJT5736B
| size | 3"x6L black |
|---|---|
| dimensions | 5.98x3.50x3.50 " |
| weight | 3.97 lb |
| packaging | - |
| d1 | 3.50 |
| DN1 | - |
| l1 | 2.99 |
| d2 | 3.50 |
| DN2 | - |
| l2 | 2.99 |
SJT5746B
| size | 4"x6L black |
|---|---|
| dimensions | 5.98x4.50x4.50 " |
| weight | 5.18 lb |
| packaging | - |
| d1 | 4.50 |
| DN1 | - |
| l1 | 2.99 |
| d2 | 4.50 |
| DN2 | - |
| l2 | 2.99 |
SJT5756B
| size | 5"x6L black |
|---|---|
| dimensions | 5.98x5.56x5.56 " |
| weight | 7.28 lb |
| packaging | - |
| d1 | 5.56 |
| DN1 | - |
| l1 | 2.99 |
| d2 | 5.56 |
| DN2 | - |
| l2 | 2.99 |
SJT5766B
| size | 6"x6L black |
|---|---|
| dimensions | 5.98x6.63x6.63 " |
| weight | 9.92 lb |
| packaging | - |
| d1 | 6.63 |
| DN1 | - |
| l1 | 2.99 |
| d2 | 6.63 |
| DN2 | - |
| l2 | 2.99 |
SJT5786B
| size | 8"x6L black |
|---|---|
| dimensions | 5.98x8.63x8.63 " |
| weight | 13.32 lb |
| packaging | - |
| d1 | 8.63 |
| DN1 | - |
| l1 | 2.99 |
| d2 | 8.63 |
| DN2 | - |
| l2 | 2.99 |
Specifications
| article | VSH Shurjoint nipple (2 x groove) |
|---|---|
| article number with gtin | 57 |
| manufacturer | Shurjoint |
| weight | 13.32 lb |
| dimensions | 5.98x8.63x8.63 " |
| color | black |
| materials | steel (ASTM A53 Grade B) |
| finishing | none |
| connection type | groove (fitting) |
| product group | fittings (demountable) |
| ETIM class | EC003024 Fitting with 2 connections |
| country of origin | Taiwan |
| brand | VSH |
| series | Shurjoint |
| product type | 57 |
| ETIM | {"etim-class":"EC003024 Fitting with 2 connections","Material connection 1":"Steel","Material quality connection 1":"Other","Surface protection connection 1":"Untreated","Surface treatment connection 1":"Untreated","Material connection 2":"Steel","Material quality connection 2":"Other","Surface protection connection 2":"Untreated","Surface treatment connection 2":"Untreated","Shape":"Straight","Reducing":"No","Eccentric":"No","System specific":"No","Connection 1":"Groove","Connection 2":"Groove","Main colour fitting":"Black","With buffer stud":"No","With sealing rings/gaskets":"No","Capped":"No","With connection indicator":"No","With drain valve":"No","With de-aerator":"No","FM quality mark":"No","LPCB quality mark":"No","ULC quality mark":"No","UL quality mark":"No","VdS quality mark":"No","DVGW quality mark for gas":"No","DVGW quality mark for water":"No","Certified according to NF 545":"No","KIWA certified":"No","Gastec QA mark":"No","KOMO certified":"No","Gastec QA - AR 214 (H2)":"No"} |
