Attributes
| Group Code | 59 |
|---|---|
| Product Type | demontabel |
| Brand Series | vsh-shurjoint |
| Applications | heating, cooling, compressed air |
| Approvals | CRN |
| Solutions | utility, industry |
Description
The VSH Shurjoint Model 59 nipple allows for a direct connection threaded connections and grooved couplings.
Variations (18)
SJT591254B
| size | 1 1/4"xMNPT1 1/4" black |
|---|---|
| dimensions | 1.66x1.66x4.02 " |
| weight | 0.68 lb |
| packaging | - |
| d1 | 1.66 |
| DN1 | - |
| l1 | 2.01 |
| z1 | 2.01 |
| d2 | 1.66 |
| DN2 | - |
| l2 | 2.01 |
SJT591256B
| size | 1 1/4"xMNPT1 1/4" black |
|---|---|
| dimensions | 1.66x1.66x5.98 " |
| weight | 0.99 lb |
| packaging | - |
| d1 | 1.66 |
| DN1 | - |
| l1 | 2.01 |
| z1 | 2.01 |
| d2 | 1.66 |
| DN2 | - |
| l2 | 2.01 |
SJT59154B
| size | 1 1/2"xMNPT1 1/2" black |
|---|---|
| dimensions | 1.90x1.90x4.02 " |
| weight | 0.77 lb |
| packaging | - |
| d1 | 1.90 |
| DN1 | - |
| l1 | 2.01 |
| z1 | 2.01 |
| d2 | 1.90 |
| DN2 | - |
| l2 | 2.01 |
SJT59156B
| size | 1 1/2"xMNPT1 1/2" black |
|---|---|
| dimensions | 1.90x1.90x5.98 " |
| weight | 1.32 lb |
| packaging | - |
| d1 | 1.90 |
| DN1 | - |
| l1 | 2.01 |
| z1 | 2.01 |
| d2 | 1.90 |
| DN2 | - |
| l2 | 2.01 |
SJT5923B
| size | 2"xMNPT2 black |
|---|---|
| dimensions | 2.37x2.37x2.99 " |
| weight | 0.75 lb |
| packaging | - |
| d1 | 2.37 |
| DN1 | - |
| l1 | 2.01 |
| z1 | 2.01 |
| d2 | 2.37 |
| DN2 | - |
| l2 | 2.01 |
SJT5923G
| size | 2"xMNPT2" galvanized |
|---|---|
| dimensions | 2.37x2.37x2.99 " |
| weight | 0.75 lb |
| packaging | - |
| d1 | 2.37 |
| DN1 | - |
| l1 | 2.01 |
| z1 | 2.01 |
| d2 | 2.37 |
| DN2 | - |
| l2 | 2.01 |
SJT5924B
| size | 2"xMNPT2 black |
|---|---|
| dimensions | 2.37x2.37x4.02 " |
| weight | 1.06 lb |
| packaging | - |
| d1 | 2.37 |
| DN1 | - |
| l1 | 2.01 |
| z1 | 2.01 |
| d2 | 2.37 |
| DN2 | - |
| l2 | 2.01 |
SJT5926B
| size | 2"xMNPT2 black |
|---|---|
| dimensions | 2.37x2.37x5.98 " |
| weight | 1.74 lb |
| packaging | - |
| d1 | 2.37 |
| DN1 | - |
| l1 | 2.01 |
| z1 | 2.01 |
| d2 | 2.37 |
| DN2 | - |
| l2 | 2.01 |
SJT59253G
| size | 2 1/2"xMNPT2 1/2" galvanized |
|---|---|
| dimensions | 2.87x2.87x2.99 " |
| weight | 1.1 lb |
| packaging | - |
| d1 | 2.87 |
| DN1 | - |
| l1 | 2.01 |
| z1 | 2.01 |
| d2 | 2.87 |
| DN2 | - |
| l2 | 2.01 |
SJT59254B
| size | 2 1/2"xMNPT2 1/2" black |
|---|---|
| dimensions | 2.87x2.87x4.02 " |
| weight | 1.59 lb |
| packaging | - |
| d1 | 2.87 |
| DN1 | - |
| l1 | 2.01 |
| z1 | 2.01 |
| d2 | 2.87 |
| DN2 | - |
| l2 | 2.01 |
SJT59256B
| size | 2 1/2"xMNPT2 1/2" black |
|---|---|
| dimensions | 2.87x2.87x5.98 " |
| weight | 2.6 lb |
| packaging | - |
| d1 | 2.87 |
| DN1 | - |
| l1 | 2.01 |
| z1 | 2.01 |
| d2 | 2.87 |
| DN2 | - |
| l2 | 2.01 |
SJT5933B
| size | 3"xMNPT3 black |
|---|---|
| dimensions | 3.50x3.50x2.99 " |
| weight | 1.39 lb |
| packaging | - |
| d1 | 3.50 |
| DN1 | - |
| l1 | 2.01 |
| z1 | 2.01 |
| d2 | 3.50 |
| DN2 | - |
| l2 | 2.01 |
SJT5934B
| size | 3"xMNPT3 black |
|---|---|
| dimensions | 3.50x3.50x4.02 " |
| weight | 2.34 lb |
| packaging | - |
| d1 | 3.50 |
| DN1 | - |
| l1 | 2.01 |
| z1 | 2.01 |
| d2 | 3.50 |
| DN2 | - |
| l2 | 2.01 |
SJT5936B
| size | 3"xMNPT3 black |
|---|---|
| dimensions | 3.50x3.50x5.98 " |
| weight | 3.86 lb |
| packaging | - |
| d1 | 3.50 |
| DN1 | - |
| l1 | 2.01 |
| z1 | 2.01 |
| d2 | 3.50 |
| DN2 | - |
| l2 | 2.01 |
SJT5946B
| size | 4"xMNPT4 black |
|---|---|
| dimensions | 4.50x4.50x5.98 " |
| weight | 5.07 lb |
| packaging | - |
| d1 | 4.50 |
| DN1 | - |
| l1 | 2.99 |
| z1 | 2.99 |
| d2 | 4.50 |
| DN2 | - |
| l2 | 2.99 |
SJT5956B
| size | 5"xMNPT5 black |
|---|---|
| dimensions | 5.56x5.56x5.98 " |
| weight | 6.61 lb |
| packaging | - |
| d1 | 5.56 |
| DN1 | - |
| l1 | 2.99 |
| z1 | 2.99 |
| d2 | 5.56 |
| DN2 | - |
| l2 | 2.99 |
SJT5966B
| size | 6"xMNPT6 black |
|---|---|
| dimensions | 6.63x6.63x5.98 " |
| weight | 8.18 lb |
| packaging | - |
| d1 | 6.63 |
| DN1 | - |
| l1 | 2.99 |
| z1 | 2.99 |
| d2 | 6.63 |
| DN2 | - |
| l2 | 2.99 |
SJT5986B
| size | 8"xMNPT8 black |
|---|---|
| dimensions | 8.63x8.63x5.98 " |
| weight | 14.07 lb |
| packaging | - |
| d1 | 8.63 |
| DN1 | - |
| l1 | 2.99 |
| z1 | 2.99 |
| d2 | 8.63 |
| DN2 | - |
| l2 | 2.99 |
Specifications
| article | VSH Shurjoint nipple (groove x male thread) |
|---|---|
| article number with gtin | 59 |
| manufacturer | Shurjoint |
| weight | 14.07 lb |
| dimensions | 8.63x8.63x5.98 " |
| color | black, silver |
| materials | steel (ASTM A53 Grade B) |
| finishing | none |
| shape | straight |
| connection type | groove (fitting), MPT - male thread conical (NPT) |
| product group | fittings (demountable) |
| ETIM class | EC003024 Fitting with 2 connections |
| country of origin | Taiwan |
| brand | VSH |
| series | Shurjoint |
| product type | 59 |
| ETIM | {"etim-class":"EC003024 Fitting with 2 connections","Material connection 1":"Steel","Material quality connection 1":"Other","Surface protection connection 1":"Untreated","Surface treatment connection 1":"Untreated","Material connection 2":"Steel","Material quality connection 2":"Other","Surface protection connection 2":"Untreated","Surface treatment connection 2":"Untreated","Shape":"Straight","Model":"1-part","Reducing":"No","Eccentric":"No","System specific":"No","Connection 1":"Groove","Connection 2":"External thread conical (NPT)","With buffer stud":"No","High tensile strength":"Yes","With sealing rings/gaskets":"No","Capped":"No","With connection indicator":"No","With drain valve":"No","With de-aerator":"No","FM quality mark":"No","LPCB quality mark":"No","ULC quality mark":"No","UL quality mark":"No","VdS quality mark":"No","DVGW quality mark for gas":"No","DVGW quality mark for water":"No","Certified according to NF 545":"No","KIWA certified":"No","Gastec QA mark":"No","KOMO certified":"No","Gastec QA - AR 214 (H2)":"No"} |
