Attributes
| Group Code | 7043E |
|---|---|
| Product Type | demontabel |
| Brand Series | vsh-shurjoint |
| Approvals | FM, UL, ULc |
| Solutions | datacenters, utility, industry |
Description
7043E is the designation for model 7043 with a Grade E EPDM gasket. The VSH Shurjoint Model 7043 flange adapter allows for a direct connection with ANSI Class 300 flanges. The specially designed gasket enables the transition from a grooved system to a flanged system or component with this single flange. 2” through 8” Model 7043 flange adapters are supplied hinged as a single assembly, while larger sizes are supplied with separate segments. The Model 7043 flange adapters are comprised of two identical ductile iron segments complete with an EPDM gasket and two pairs of bolts and nuts. The flange segments are painted black.The Model 7043 flange adapter has been designed with small projections on the outside face of the flange for mating with 1.6 mm raised face flanges. For mating with flat-face flanges these projections must be removed, this can be accomplished with a grinder or other tool.
Variations (9)
SJT70432PE
| size | 2" A300 black |
|---|---|
| dimensions | 0.94x6.50x6.50 " |
| weight | 5.18 lb |
| packaging | - |
| d1 | 2.37 |
| DN1 | - |
| l1 | 0.95 |
| d2 | 2.37 |
| DN2 | - |
| n2 | - |
| k2 | 5 |
| d2-2 | 0.75 |
| D2 | 6.5 |
SJT704325PE
| size | 2 1/2" A300 black |
|---|---|
| dimensions | 1.06x7.52x7.52 " |
| weight | 7.87 lb |
| packaging | - |
| d1 | 2.87 |
| DN1 | - |
| l1 | 1.06 |
| d2 | 2.87 |
| DN2 | - |
| n2 | - |
| k2 | 5.88 |
| d2-2 | 0.88 |
| D2 | 7.5 |
SJT70433PE
| size | 3" A300 black |
|---|---|
| dimensions | 1.18x8.27x8.27 " |
| weight | 10.03 lb |
| packaging | - |
| d1 | 3.50 |
| DN1 | - |
| l1 | 1.18 |
| d2 | 3.50 |
| DN2 | - |
| n2 | - |
| k2 | 6.62 |
| d2-2 | 0.88 |
| D2 | 8.25 |
SJT70434PE
| size | 4" A300 black |
|---|---|
| dimensions | 1.30x10.00x10.00 " |
| weight | 17.28 lb |
| packaging | - |
| d1 | 4.50 |
| DN1 | - |
| l1 | 1.30 |
| d2 | 4.50 |
| DN2 | - |
| n2 | - |
| k2 | 7.88 |
| d2-2 | 0.88 |
| D2 | 10 |
SJT70435PE
| size | 5" A300 black |
|---|---|
| dimensions | 1.46x10.98x10.98 " |
| weight | 21.32 lb |
| packaging | - |
| d1 | 5.56 |
| DN1 | - |
| l1 | 1.46 |
| d2 | 5.56 |
| DN2 | - |
| n2 | - |
| k2 | 8.5 |
| d2-2 | 0.87 |
| D2 | 9.25 |
SJT70436PE
| size | 6" A300 black |
|---|---|
| dimensions | 1.50x12.52x12.52 " |
| weight | 26.92 lb |
| packaging | - |
| d1 | 6.63 |
| DN1 | - |
| l1 | 1.50 |
| d2 | 6.63 |
| DN2 | - |
| n2 | - |
| k2 | 10.62 |
| d2-2 | 0.88 |
| D2 | 12.5 |
SJT70438PE
| size | 8" A300 black |
|---|---|
| dimensions | 1.61x15.00x15.00 " |
| weight | 36.2 lb |
| packaging | - |
| d1 | 8.63 |
| DN1 | - |
| l1 | 1.61 |
| d2 | 8.63 |
| DN2 | - |
| n2 | - |
| k2 | 13 |
| d2-2 | 1 |
| D2 | 15 |
SJT704310PE
| size | 10" A300 black |
|---|---|
| dimensions | 1.89x17.68x17.68 " |
| weight | 56.88 lb |
| packaging | - |
| d1 | 10.75 |
| DN1 | - |
| l1 | 1.89 |
| d2 | 10.75 |
| DN2 | - |
| n2 | - |
| k2 | 15.25 |
| d2-2 | 1.13 |
| D2 | 17.5 |
SJT704312PE
| size | 12" A300 black |
|---|---|
| dimensions | 1.93x20.51x20.51 " |
| weight | 77.69 lb |
| packaging | - |
| d1 | 12.75 |
| DN1 | - |
| l1 | 1.93 |
| d2 | 12.75 |
| DN2 | - |
| n2 | - |
| k2 | 17.75 |
| d2-2 | 1.25 |
| D2 | 20.5 |
Specifications
| article | VSH Shurjoint A300 flange adapter, EPDM gasket |
|---|---|
| article number with gtin | 7043E |
| manufacturer | Shurjoint |
| weight | 77.69 lb |
| dimensions | 1.93x20.51x20.51 " |
| color | black |
| materials | cast iron (ASTM A536 65-45-12) |
| finishing | varnished |
| shape | straight |
| connection type | groove (coupling), flange |
| sealing | EPDM |
| min. medium temperature | -29 °F |
| max medium temperature | 230 °F |
| product group | fittings (demountable) |
| ETIM class | EC003024 Fitting with 2 connections |
| country of origin | Taiwan |
| brand | VSH |
| series | Shurjoint |
| product type | 7043E |
| ETIM | {"etim-class":"EC003024 Fitting with 2 connections","Material connection 1":"Cast iron","Material quality connection 1":"ASTM A536 Grade 65-45-12","Surface protection connection 1":"Lacquered","Surface treatment connection 1":"Other","Material connection 2":"Cast iron","Material quality connection 2":"ASTM A536 Grade 65-45-12","Surface protection connection 2":"Lacquered","Surface treatment connection 2":"Other","Shape":"Straight","Model":"2-part","Reducing":"No","Eccentric":"No","System specific":"No","Connection 1":"Ribbing groove (groove coupling)","Connection 2":"Flange","Main colour fitting":"Black","Material sealing":"Ethylene-propylene diene monomer rubber (EPDM)","With buffer stud":"No","Medium temperature (continuous)":"-34°C - 110°C","Medium temperature (continuous) (imperial)":"-29.2°F - 230°F","With sealing rings/gaskets":"No","Capped":"No","With connection indicator":"No","With drain valve":"No","With de-aerator":"No","FM quality mark":"Yes","LPCB quality mark":"No","ULC quality mark":"Yes","UL quality mark":"Yes","VdS quality mark":"No","DVGW quality mark for gas":"No","DVGW quality mark for water":"No","Certified according to NF 545":"No","KIWA certified":"No","Gastec QA mark":"No","KOMO certified":"No","Gastec QA - AR 214 (H2)":"No"} |
