Attributes
| Group Code | 7110DR |
|---|---|
| Product Type | demontabel |
| Brand Series | vsh-shurjoint |
| Approvals | CRN, FM, UL, ULc |
Description
The VSH Shurjoint Model 7110DR is a grooved-end ductile iron cast elbow with an integral 1” NPT or BSP drain. The 7110DR was primarily designed for, but not limited to, use on fire protection standpipes.
Variations (8)
SJT7110DR2P
| size | 2" w/ 1" FNPT orange |
|---|---|
| dimensions | 4.45x2.37x4.45 " |
| weight | 2.18 lb |
| packaging | - |
| d1 | 2.37 |
| DN1 | - |
| l1 | 3.27 |
| d2 | 2.37 |
| DN2 | - |
| l2 | 3.27 |
| angle | - |
SJT7110DR25P
| size | 2 1/2" w/ 1" FNPT orange |
|---|---|
| dimensions | 5.18x2.87x5.18 " |
| weight | 2.87 lb |
| packaging | - |
| d1 | 2.87 |
| DN1 | - |
| l1 | 3.74 |
| d2 | 2.87 |
| DN2 | - |
| l2 | 3.74 |
| angle | - |
SJT7110DR3P
| size | 3" w/ 1" FNPT orange |
|---|---|
| dimensions | 6.00x3.50x6.00 " |
| weight | 4.63 lb |
| packaging | - |
| d1 | 3.50 |
| DN1 | - |
| l1 | 4.25 |
| d2 | 3.50 |
| DN2 | - |
| l2 | 4.25 |
| angle | - |
SJT7110DR3G
| size | 3" w/ 1" FNPT galvanized |
|---|---|
| dimensions | 6.00x3.50x6.00 " |
| weight | 4.63 lb |
| packaging | - |
| d1 | 3.50 |
| DN1 | - |
| l1 | 4.25 |
| d2 | 3.50 |
| DN2 | - |
| l2 | 4.25 |
| angle | - |
SJT7110DR4P
| size | 4" w/ 1" FNPT orange |
|---|---|
| dimensions | 7.25x4.50x7.25 " |
| weight | 6.61 lb |
| packaging | - |
| d1 | 4.50 |
| DN1 | - |
| l1 | 5.00 |
| d2 | 4.50 |
| DN2 | - |
| l2 | 5.00 |
| angle | - |
SJT7110DR4G
| size | 4" w/ 1" FNPT galvanized |
|---|---|
| dimensions | 7.25x4.50x7.25 " |
| weight | 6.61 lb |
| packaging | - |
| d1 | 4.50 |
| DN1 | - |
| l1 | 5.00 |
| d2 | 4.50 |
| DN2 | - |
| l2 | 5.00 |
| angle | - |
SJT7110DR6P
| size | 6" w/ 1" FNPT orange |
|---|---|
| dimensions | 9.81x6.63x9.81 " |
| weight | 13.36 lb |
| packaging | - |
| d1 | 6.63 |
| DN1 | - |
| l1 | 6.50 |
| d2 | 6.63 |
| DN2 | - |
| l2 | 6.50 |
| angle | - |
SJT7110DR8P
| size | 8" w/ 1" FNPT orange |
|---|---|
| dimensions | 12.07x8.63x12.07 " |
| weight | 25.57 lb |
| packaging | - |
| d1 | 8.63 |
| DN1 | - |
| l1 | 7.76 |
| d2 | 8.63 |
| DN2 | - |
| l2 | 7.76 |
| angle | - |
Specifications
| article | VSH Shurjoint drain elbow (2 x groove) |
|---|---|
| article number with gtin | 7110DR |
| manufacturer | Shurjoint |
| weight | 25.57 lb |
| dimensions | 12.07x8.63x12.07 " |
| color | orange, silver |
| materials | cast iron (ASTM A536 65-45-12) |
| finishing | varnished, hot dip galvanized |
| shape | Elbow, 90º |
| connection type | groove (fitting) |
| product group | fittings (demountable) |
| ETIM class | EC003024 Fitting with 2 connections |
| country of origin | Taiwan |
| brand | VSH |
| series | Shurjoint |
| product type | 7110DR |
| ETIM | {"etim-class":"EC003024 Fitting with 2 connections","Material connection 1":"Cast iron","Material quality connection 1":"ASTM A536 Grade 65-45-12","Material connection 2":"Cast iron","Material quality connection 2":"ASTM A536 Grade 65-45-12","Shape":"Bend","Bend angle":"90°","Reducing":"No","Eccentric":"No","System specific":"No","Connection 1":"Groove","Connection 2":"Groove","With buffer stud":"No","With sealing rings/gaskets":"No","Capped":"No","With connection indicator":"No","With drain valve":"Yes","With de-aerator":"No","LPCB quality mark":"No","VdS quality mark":"No","DVGW quality mark for gas":"No","DVGW quality mark for water":"No","Certified according to NF 545":"No","KIWA certified":"No","Gastec QA mark":"No","KOMO certified":"No","Gastec QA - AR 214 (H2)":"No"} |
