VSH Shurjoint true-Y (3 x groove)

Scraped SKU: 7137 2026-06-05 04:24:53

Attributes

Group Code7137
Product Typedemontabel
Brand Seriesvsh-shurjoint

Description

Shurjoint grooved-end fittings are made of ductile iron per ASTM A536 Gr. 65-45-12. C-E dimensions are manufacturer’s standard.

Shurjoint standard fitting pressure ratings conform to the ratings of Model 7707 couplings.

Variations (13)

SJT71372P

size2" orange
dimensions6.30x2.37x6.42 "
weight2.43 lb
packaging-
d12.37
DN1-
l13.27
d22.37
DN2-
l22.76
d32.37
DN3-
l33.27

SJT71372G

size2" orange
dimensions6.30x2.37x6.42 "
weight2.43 lb
packaging-
d12.37
DN1-
l13.27
d22.37
DN2-
l22.76
d32.37
DN3-
l33.27

SJT713725G

size2 1/2" orange
dimensions7.32x2.87x7.40 "
weight3.75 lb
packaging-
d12.87
DN1-
l13.74
d22.87
DN2-
l22.99
d32.87
DN3-
l33.74

SJT713725P

size2 1/2" orange
dimensions7.32x2.87x7.40 "
weight3.75 lb
packaging-
d12.87
DN1-
l13.74
d22.87
DN2-
l22.99
d32.87
DN3-
l33.74

SJT71373P

size3" orange
dimensions6.36x3.50x8.50 "
weight5.51 lb
packaging-
d13.50
DN1-
l14.25
d23.50
DN2-
l23.27
d33.50
DN3-
l34.25

SJT71374P

size4" orange
dimensions10.25x4.50x10.13 "
weight8.05 lb
packaging-
d14.50
DN1-
l15.00
d24.50
DN2-
l23.74
d34.50
DN3-
l35.00

SJT71374G

size4" galvanized
dimensions10.25x4.50x10.13 "
weight8.05 lb
packaging-
d14.50
DN1-
l15.00
d24.50
DN2-
l23.74
d34.50
DN3-
l35.00

SJT71375P

size5" orange
dimensions11.74x5.56x11.38 "
weight11.6 lb
packaging-
d15.56
DN1-
l15.51
d25.56
DN2-
l24.02
d35.56
DN3-
l35.51

SJT71376P

size6" orange
dimensions13.87x6.63x13.43 "
weight19.62 lb
packaging-
d16.63
DN1-
l16.50
d26.63
DN2-
l24.49
d36.63
DN3-
l36.50

SJT71376G

size6" galvanized
dimensions13.87x6.63x13.43 "
weight19.62 lb
packaging-
d16.63
DN1-
l16.50
d26.63
DN2-
l24.49
d36.63
DN3-
l36.50

SJT71378P

size8" orange
dimensions17.07x8.63x16.29 "
weight34.33 lb
packaging-
d18.63
DN1-
l17.76
d28.63
DN2-
l25.98
d38.63
DN3-
l37.76

SJT713710P

size10" orange
dimensions20.35x10.75x19.19 "
weight56.22 lb
packaging-
d110.75
DN1-
l19.02
d210.75
DN2-
l26.50
d310.75
DN3-
l39.02

SJT713712P

size12" orange
dimensions23.16x12.75x21.58 "
weight79.37 lb
packaging-
d112.75
DN1-
l110.00
d212.75
DN2-
l27.01
d312.75
DN3-
l310.00

Specifications

articleVSH Shurjoint true-Y (3 x groove)
article number with gtin7137
manufacturerShurjoint
weight79.37 lb
dimensions23.16x12.75x21.58 "
colororange, silver
materialssteel, cast iron (ASTM A53 Grade B, ASTM A536 65-45-12)
finishingvarnished, hot dip galvanized
shapeY-piece 45 degrees
connection typegroove (fitting)
product groupfittings (demountable)
ETIM classEC003025 Fitting with 3 connections
country of originTaiwan
brandVSH
seriesShurjoint
product type7137
ETIM
{"etim-class":"EC003025 Fitting with 3 connections","Model":"Y-piece","Reducing":"No","Multi-part":"No","System specific":"No","Connection 1":"Groove","Connection 2":"Groove","Connection 3":"Groove","With sealing rings/gaskets":"No","With drain valve":"No","With de-aerator":"No","With buffer stud":"No","Capped":"No","With connection indicator":"No","FM quality mark":"No","LPCB quality mark":"No","ULC quality mark":"No","UL quality mark":"No","VdS quality mark":"No","DVGW quality mark for gas":"No","DVGW quality mark for water":"No","KIWA certified":"No","Gastec QA mark":"No","KOMO certified":"No","Gastec QA - AR 214 (H2)":"No"}
