VSH Shurjoint A150 flange nipple (groove x flange)

Scraped SKU: 7170 2026-06-05 04:24:53

Attributes

Group Code7170
Product Typedemontabel
Brand Seriesvsh-shurjoint
Applicationsheating, cooling, compressed air
Solutionsutility, industry

Description

The ductile iron Model 7170 Flange Adapter provides a rigid transition between ANSI class 125/150 flanged components and a grooved system.

Shurjoint standard fitting pressure ratings conform to the ratings of Model 7707 couplings.

Variations (8)

SJT717015P

size1 1/2" orange, fab.
dimensions4.02x5.00x5.00 "
weight3.88 lb
packaging-
d11.90
DN1-
l13.33
d25.00
DN2-
l20.63
n2-
k23.88
d2-20.62
D25

SJT717010P

size10" A150 orange
dimensions5.00x15.98x15.98 "
weight48.5 lb
packaging-
d110.75
DN1-
l13.82
d215.98
DN2-
l21.18
n2-
k214.25
d2-21
D216

SJT717012P

size12" A150 orange
dimensions5.00x19.02x19.02 "
weight61.73 lb
packaging-
d112.75
DN1-
l13.74
d219.02
DN2-
l21.26
n2-
k217
d2-21
D219

SJT717014P

size14" A150 orange
dimensions5.00x20.98x20.98 "
weight109.13 lb
packaging-
d114.00
DN1-
l13.62
d220.98
DN2-
l21.38
n2-
k218.74
d2-21.14
D220.98

SJT717016P

size16" A150 orange
dimensions5.00x23.50x23.50 "
weight110.23 lb
packaging-
d116.00
DN1-
l13.54
d223.50
DN2-
l21.46
n2-
k221.24
d2-21.14
D223.5

SJT717018P

size18" A150 orange
dimensions5.51x25.00x25.00 "
weight137.79 lb
packaging-
d118.00
DN1-
l13.94
d225.00
DN2-
l21.58
n2-
k222.76
d2-21.26
D225

SJT717020P

size20" A150 orange
dimensions5.71x27.52x27.52 "
weight158.73 lb
packaging-
d120.00
DN1-
l14.02
d227.52
DN2-
l21.69
n2-
k225
d2-21.26
D227.48

SJT717024P

size24" A150 orange
dimensions5.98x32.05x32.05 "
weight219.36 lb
packaging-
d124.00
DN1-
l14.09
d232.05
DN2-
l21.89
n2-
k229.51
d2-21.38
D232.01

Specifications

articleVSH Shurjoint A150 flange nipple (groove x flange)
article number with gtin7170
manufacturerShurjoint
weight219.36 lb
dimensions5.98x32.05x32.05 "
colororange
materialscast iron, steel (ASTM A536 65-45-12, ASTM A53 Grade B)
finishingvarnished
connection typegroove (fitting), flange
product groupfittings (demountable)
ETIM classEC003024 Fitting with 2 connections
country of originTaiwan
brandVSH
seriesShurjoint
product type7170
ETIM
{"etim-class":"EC003024 Fitting with 2 connections","Surface protection connection 1":"Lacquered","Surface treatment connection 1":"Other","Surface protection connection 2":"Lacquered","Surface treatment connection 2":"Other","Shape":"Straight","Reducing":"No","Eccentric":"No","System specific":"No","Connection 1":"Groove","Connection 2":"Flange","Main colour fitting":"Orange","With buffer stud":"No","High tensile strength":"Yes","With sealing rings/gaskets":"No","Capped":"No","With connection indicator":"No","With drain valve":"No","With de-aerator":"No","FM quality mark":"No","LPCB quality mark":"No","ULC quality mark":"No","UL quality mark":"No","VdS quality mark":"No","DVGW quality mark for gas":"No","DVGW quality mark for water":"No","Certified according to NF 545":"No","KIWA certified":"No","Gastec QA mark":"No","KOMO certified":"No","Gastec QA - AR 214 (H2)":"No"}
