Attributes
| Group Code | 725G |
|---|---|
| Product Type | demontabel |
| Brand Series | vsh-shurjoint |
| Applications | heating, cooling |
| Solutions | utility, industry |
Description
VSH Shurjoint grooved pipe systems consist of a wide range of groove couplings, fittings and valves for heating, compressed air and industry. VSH Shurjoint is less labor intensive, safer, cleaner and delivers consistent connection quality.
- VSH Shurjoint can be perfectly combined with other VSH systems such as VSH XPress, VSH SudoPress and VSH PowerPress
- the 'Aalberts integrated piping systems' range covers a fully integrated system from ¼" to 104"
Variations (7)
SJT725GA2525
| size | 2 1/2" orange |
|---|---|
| dimensions | 5.79x8.82x5.24 " |
| weight | 8.82 lb |
| packaging | - |
| d1 | 2.87 |
| DN1 | - |
| l1 | 3.74 |
| d2 | 2.87 |
| DN2 | - |
| l2 | 5.00 |
| V | 2.05 |
| U | 5.51 |
| a | - |
| z1 | - |
| es1 | - |
| z2 | - |
| es2 | - |
SJT725GA33
| size | 3" orange |
|---|---|
| dimensions | 6.93x10.43x7.42 " |
| weight | 13.23 lb |
| packaging | - |
| d1 | 3.50 |
| DN1 | - |
| l1 | 5.51 |
| d2 | 3.50 |
| DN2 | - |
| l2 | 6.30 |
| V | 2.76 |
| U | 6.54 |
| a | - |
| z1 | - |
| es1 | - |
| z2 | - |
| es2 | - |
SJT725GA44
| size | 4" orange |
|---|---|
| dimensions | 8.58x12.28x7.25 " |
| weight | 20.59 lb |
| packaging | - |
| d1 | 4.50 |
| DN1 | - |
| l1 | 5.00 |
| d2 | 4.50 |
| DN2 | - |
| l2 | 7.36 |
| V | 3.15 |
| U | 8.11 |
| a | - |
| z1 | - |
| es1 | - |
| z2 | - |
| es2 | - |
SJT725G66
| size | 6" orange |
|---|---|
| dimensions | 9.76x15.16x9.81 " |
| weight | 43.52 lb |
| packaging | - |
| d1 | 6.63 |
| DN1 | - |
| l1 | 6.50 |
| d2 | 6.63 |
| DN2 | - |
| l2 | 9.02 |
| V | 4.33 |
| U | 10.67 |
| a | - |
| z1 | - |
| es1 | - |
| z2 | - |
| es2 | - |
SJT725G88
| size | 8" orange |
|---|---|
| dimensions | 12.60x18.27x13.33 " |
| weight | 75.53 lb |
| packaging | - |
| d1 | 8.63 |
| DN1 | - |
| l1 | 9.02 |
| d2 | 8.63 |
| DN2 | - |
| l2 | 10.24 |
| V | 5.51 |
| U | 13.46 |
| a | - |
| z1 | - |
| es1 | - |
| z2 | - |
| es2 | - |
SJT725G1010
| size | 10" orange |
|---|---|
| dimensions | 16.14x22.13x14.39 " |
| weight | 123.46 lb |
| packaging | - |
| d1 | 10.75 |
| DN1 | - |
| l1 | 9.02 |
| d2 | 10.75 |
| DN2 | - |
| l2 | 12.40 |
| V | 6.58 |
| U | 15.59 |
| a | - |
| z1 | - |
| es1 | - |
| z2 | - |
| es2 | - |
SJT725G1212
| size | 12" orange ISO |
|---|---|
| dimensions | 19.29x26.30x16.37 " |
| weight | 168.43 lb |
| packaging | - |
| d1 | 12.75 |
| DN1 | - |
| l1 | 10.00 |
| d2 | 12.75 |
| DN2 | - |
| l2 | 15.43 |
| V | 7.64 |
| U | 17.80 |
| a | - |
| z1 | 10.00 |
| es1 | 1.22 |
| z2 | 15.43 |
| es2 | 1.22 |
Specifications
| article | VSH Shurjoint suction diffuser (2 x groove) |
|---|---|
| article number with gtin | 725G |
| manufacturer | Shurjoint |
| weight | 168.43 lb |
| dimensions | 19.29x26.30x16.37 " |
| color | orange |
| materials | cast iron (ASTM A536 65-45-12) |
| finishing | varnished |
| shape | Elbow |
| connection type | groove (fitting) |
| min. medium temperature | -29 °F |
| max medium temperature | 230 °F |
| product group | valves (demountable) |
| ETIM class | EC010151 Pipeline strainer |
| intrastat code | 73071910 |
| country of origin | Taiwan |
| brand | VSH |
| series | Shurjoint |
| product type | 725G |
| ETIM | {"etim-class":"EC010151 Pipeline strainer","Surface protection":"Lacquered","Connection":"Groove","With coupling":"No","Medium temperature (continuous)":"-34°C - 110°C","Medium temperature (continuous) (imperial)":"-29.2°F - 230°F","With drain possibility (connection)":"Yes","KIWA certified":"No","Gastec QA mark":"No","Gastec QA - AR 214 (H2)":"No"} |
