Attributes
| Group Code | BH22C |
|---|---|
| Product Type | check-valve |
| Brand Series | vsh-shurjoint |
| Applications | heating, cooling, compressed air |
| Solutions | utility, industry |
Description
VSH Shurjoint grooved pipe systems consist of a wide range of groove couplings, fittings and valves for heating, compressed air and industry. VSH Shurjoint is less labor intensive, safer, cleaner and delivers consistent connection quality.
- VSH Shurjoint can be perfectly combined with other VSH systems such as VSH XPress, VSH SudoPress and VSH PowerPress
- the 'Aalberts integrated piping systems' range covers a fully integrated system from ¼" to 104"
Variations (4)
SJTBH22C2
| size | 2" |
|---|---|
| dimensions | 3.27x3.27x5.71 " |
| weight | 3.59 lb |
| packaging | - |
| d1 | 2.37 |
| DN1 | - |
| l1 | 2.87 |
| d2 | 2.37 |
| DN2 | - |
| l2 | 2.87 |
SJTBH22C25
| size | 2 1/2" |
|---|---|
| dimensions | 4.21x4.21x6.50 " |
| weight | 6.75 lb |
| packaging | - |
| d1 | 2.87 |
| DN1 | - |
| l1 | 3.27 |
| d2 | 2.87 |
| DN2 | - |
| l2 | 3.27 |
SJTBH22C3
| size | 3" |
|---|---|
| dimensions | 4.88x4.88x7.64 " |
| weight | 9.88 lb |
| packaging | - |
| d1 | 3.50 |
| DN1 | - |
| l1 | 3.82 |
| d2 | 3.50 |
| DN2 | - |
| l2 | 3.82 |
SJTBH22C4
| size | 4" |
|---|---|
| dimensions | 5.59x5.59x7.95 " |
| weight | 11.93 lb |
| packaging | - |
| d1 | 4.50 |
| DN1 | - |
| l1 | 3.98 |
| d2 | 4.50 |
| DN2 | - |
| l2 | 3.98 |
Specifications
| article | VSH Shurjoint brass swing check valve (2 x groove) |
|---|---|
| article number with gtin | BH22C |
| manufacturer | Shurjoint |
| weight | 11.93 lb |
| dimensions | 5.59x5.59x7.95 " |
| color | black, brass |
| materials | brass |
| finishing | varnished |
| shape | straight |
| connection type | groove (fitting) |
| sealing | EPDM |
| max operating pressure liquid | 247 psi |
| min. medium temperature | -29 °F |
| max medium temperature | 230 °F |
| product group | valves (check valves) |
| ETIM class | EC011469 Check valve |
| country of origin | Taiwan |
| brand | VSH |
| series | Shurjoint |
| product type | BH22C |
| ETIM | {"etim-class":"EC011469 Check valve","Surface protection":"Coated","Connections":"Groove","Sealing":"Ethylene-propylene diene monomer rubber (EPDM)","Backflow safeguard according to EN 1717":"EB","Medium temperature (continuous)":"-34°C - 110°C","Medium temperature (continuous) (imperial)":"-29.2°F - 230°F","Max. operating pressure at 20 °C":"17bar","Max. operating pressure at 20 °C (imperial)":"246.56psi","FM quality mark":"No","UL quality mark":"No","ULC quality mark":"No","LPCB quality mark":"No","Suitable for central heating water":"Yes","Certified according to SVGW for water":"No","Certified according to SVGW for gas":"No","VdS quality mark":"No","DVGW quality mark for gas":"No","DVGW quality mark for water":"No","KIWA certified":"No"} |
