Attributes
| Group Code | SJ-200 |
|---|---|
| Product Type | vlinderklep |
| Brand Series | vsh-shurjoint |
| Applications | heating, cooling, compressed air |
| Solutions | utility, industry |
Description
The VSH Shurjoint Model SJ-200 Butterfly Valve is a low profile, grooved-end butterfly valve for oil & gas and or mining services. Working pressure is rated up to 16 bar and service temperatures up to +82°C (Nitrile body liner). The Model SJ-200 features a fully rubber lined body with 316 stainless steel disc. The end-to-end dimensions conform to MSS SP-67. The lever handle is equipped with a tamper resistant locking device.
Variations (6)
SJT2002T
| size | 2" |
|---|---|
| dimensions | 7.11x3.19x4.13 " |
| weight | 1.92 lb |
| packaging | - |
| d1 | 2.37 |
| DN1 | - |
| l1 | 1.61 |
| d2 | 2.37 |
| DN2 | - |
| l2 | 1.61 |
| M1 | 0.87 |
| M2 | 5.51 |
| E | 0.24 |
| Y | 1.02 |
| V | 2.09 |
| U | 1.28 |
| a | - |
SJT20025T
| size | 2 1/2" |
|---|---|
| dimensions | 9.39x3.82x4.76 " |
| weight | 3.35 lb |
| packaging | - |
| d1 | 2.87 |
| DN1 | - |
| l1 | 1.93 |
| d2 | 2.87 |
| DN2 | - |
| l2 | 1.93 |
| M1 | 1.10 |
| M2 | 7.48 |
| E | 0.24 |
| Y | 1.30 |
| V | 2.36 |
| U | 1.57 |
| a | - |
SJT2003T
| size | 3" |
|---|---|
| dimensions | 9.39x3.82x5.39 " |
| weight | 4.14 lb |
| packaging | - |
| d1 | 3.50 |
| DN1 | - |
| l1 | 1.93 |
| d2 | 3.50 |
| DN2 | - |
| l2 | 1.93 |
| M1 | 1.10 |
| M2 | 7.48 |
| E | 0.24 |
| Y | 1.30 |
| V | 2.68 |
| U | 1.57 |
| a | - |
SJT2004T
| size | 4" |
|---|---|
| dimensions | 13.07x4.57x6.81 " |
| weight | 8.49 lb |
| packaging | - |
| d1 | 4.50 |
| DN1 | - |
| l1 | 2.28 |
| d2 | 4.50 |
| DN2 | - |
| l2 | 2.28 |
| M1 | 1.77 |
| M2 | 10.79 |
| E | 0.24 |
| Y | 2.05 |
| V | 3.94 |
| U | 2.05 |
| a | - |
SJT2006T
| size | 6" |
|---|---|
| dimensions | 13.70x5.83x8.66 " |
| weight | 22.27 lb |
| packaging | - |
| d1 | 6.63 |
| DN1 | - |
| l1 | 2.91 |
| d2 | 6.63 |
| DN2 | - |
| l2 | 2.91 |
| M1 | 1.77 |
| M2 | 10.79 |
| E | 0.24 |
| Y | 2.05 |
| V | 5.12 |
| U | 2.50 |
| a | - |
SJT2008T
| size | 8" |
|---|---|
| dimensions | 13.41x5.24x11.50 " |
| weight | 30.86 lb |
| packaging | - |
| d1 | 8.63 |
| DN1 | - |
| l1 | 2.64 |
| d2 | 8.63 |
| DN2 | - |
| l2 | 2.64 |
| M1 | 1.77 |
| M2 | 10.79 |
| E | 0.24 |
| Y | 2.05 |
| V | 6.46 |
| U | 2.50 |
| a | - |
Specifications
| article | VSH Shurjoint low-profile butterfly valve (2 x groove) |
|---|---|
| article number with gtin | SJ-200 |
| manufacturer | Shurjoint |
| weight | 30.86 lb |
| dimensions | 13.41x5.24x11.50 " |
| color | black |
| materials | cast iron (ASTM A536 65-45-12) |
| finishing | varnished |
| shape | straight |
| connection type | groove (fitting) |
| pressure rating (PN) | PN 16 |
| sealing | NBR (Nitrile) |
| max operating pressure liquid | 232 psi |
| min. medium temperature | -20 °F |
| max medium temperature | 180 °F |
| product group | valves (butterfly valves) |
| ETIM class | EC010910 Butterfly valve |
| country of origin | Taiwan |
| brand | VSH |
| series | Shurjoint |
| product type | SJ-200 |
| unsps | 40141620 |
| ETIM | {"etim-class":"EC010910 Butterfly valve","Housing material":"Cast iron","Surface protection":"Coated","Material valve butterfly":"Stainless steel","Connections":"Groove","Article compression class":"PN 16","Flange compression class":"PN 16","Operation":"Lever handle","Sealing":"NBR (nitrile rubber)","Material spindle":"Stainless steel","Angle of the valve":"","Spindle angle":"90°","Spindle angle (imperial)":"3.54\"","Medium temperature (continuous)":"-29°C - 82°C","Medium temperature (continuous) (imperial)":"-20.2°F - 179.6°F","UL quality mark":"No","ULC quality mark":"No","FM quality mark":"No","LPCB quality mark":"No","VdS quality mark":"No","KIWA certified":"No","Gastec QA mark":"No","Gastec QA - AR 214 (H2)":"No"} |
