VSH Shurjoint butterfly valve (gearbox) (2 x groove)

Scraped SKU: SJ-300F 2026-06-05 04:24:53

Attributes

Group CodeSJ-300F
Product Typevlinderklep
Brand Seriesvsh-shurjoint
Applicationsheating, cooling, compressed air
Solutionsutility, industry

Description

VSH Shurjoint grooved pipe systems consist of a wide range of groove couplings, fittings and valves for heating, compressed air and industry. VSH Shurjoint is less labor intensive, safer, cleaner and delivers consistent connection quality.
  • VSH Shurjoint can be perfectly combined with other VSH systems such as VSH XPress, VSH SudoPress and VSH PowerPress
  • the 'Aalberts integrated piping systems' range covers a fully integrated system from ¼" to 104"

Variations (9)

SJT300F2E

size2"
dimensions7.70x2.56x11.50 "
weight16.76 lb
packaging-
d12.37
DN1-
d22.37
DN2-

SJT300F25E

size2 1/2"
dimensions7.99x3.15x11.89 "
weight18.3 lb
packaging-
d12.87
DN1-
d22.87
DN2-

SJT300F3E

size3"
dimensions8.23x3.62x12.80 "
weight18.96 lb
packagingBag (1 pce)
d13.50
DN1-
d23.50
DN2-

SJT300F4E

size4"
dimensions8.70x4.65x13.66 "
weight21.83 lb
packaging-
d14.50
DN1-
d24.50
DN2-

SJT300F5E

size5"
dimensions9.27x5.71x15.47 "
weight26.9 lb
packaging-
d15.56
DN1-
d25.56
DN2-

SJT300F6E

size6"
dimensions9.80x6.77x16.57 "
weight30.2 lb
packaging-
d16.63
DN1-
d26.63
DN2-

SJT300F8E

size8"
dimensions10.79x8.74x18.54 "
weight38.8 lb
packaging-
d18.63
DN1-
d28.63
DN2-

SJT300F10E

size10"
dimensions11.85x10.87x20.79 "
weight59.26 lb
packaging-
d110.75
DN1-
d210.75
DN2-

SJT300F12E

size12"
dimensions12.85x12.87x23.15 "
weight84.9 lb
packaging-
d112.75
DN1-
d212.75
DN2-

Specifications

articleVSH Shurjoint butterfly valve (gearbox) (2 x groove)
article number with gtinSJ-300F
manufacturerShurjoint
weight84.9 lb
dimensions12.85x12.87x23.15 "
colorblack
materialscast iron (ASTM A536 65-45-12)
finishingvarnished
shapestraight
connection typegroove (fitting)
sealingEPDM
max operating pressure liquid290 psi
min. medium temperature-29 °F
max medium temperature230 °F
product groupvalves (butterfly valves)
ETIM classEC010910 Butterfly valve
intrastat code84818085
country of originTaiwan
brandVSH
seriesShurjoint
product typeSJ-300F
ETIM
{"etim-class":"EC010910 Butterfly valve","Surface protection":"Coated","Connections":"Groove","Sealing":"Ethylene-propylene diene monomer rubber (EPDM)","Medium temperature (continuous)":"-34°C - 110°C","Medium temperature (continuous) (imperial)":"-29.2°F - 230°F","UL quality mark":"No","ULC quality mark":"No","FM quality mark":"No","LPCB quality mark":"No","VdS quality mark":"No","KIWA certified":"No","Gastec QA mark":"No","Gastec QA - AR 214 (H2)":"No"}

PDF Documents

[Datasheet] Datasheet Open PDF
