Attributes
| Group Code | SJ-500L |
|---|---|
| Product Type | kogelafsluiters |
| Brand Series | vsh-shurjoint |
| Applications | heating, cooling, compressed air |
| Approvals | CRN |
| Solutions | utility, industry |
Description
VSH Shurjoint grooved pipe systems consist of a wide range of groove couplings, fittings and valves for heating, compressed air and industry. VSH Shurjoint is less labor intensive, safer, cleaner and delivers consistent connection quality.
- VSH Shurjoint can be perfectly combined with other VSH systems such as VSH XPress, VSH SudoPress and VSH PowerPress
- the 'Aalberts integrated piping systems' range covers a fully integrated system from ¼" to 104"
Variations (6)
SJT5002SS
| size | 2" |
|---|---|
| dimensions | 5.51x9.76x4.96 " |
| weight | 6.44 lb |
| packaging | - |
| d1 | 2.37 |
| DN1 | - |
| l1 | 3.07 |
| z1 | 3.07 |
| d2 | 2.37 |
| DN2 | - |
| l2 | 3.07 |
| z2 | 3.07 |
| H1 | 3.74 |
| M1 | 1.12 |
| M2 | 7.60 |
| E | 1.14 |
| H | 3.74 |
| h2 | - |
| Y | 1.75 |
| V | 2.21 |
| U | 2.05 |
| a | - |
SJT50025SS
| size | 2 1/2" |
|---|---|
| dimensions | 6.26x13.56x6.63 " |
| weight | 9.7 lb |
| packaging | - |
| d1 | 2.87 |
| DN1 | - |
| l1 | 3.54 |
| z1 | 3.54 |
| d2 | 2.87 |
| DN2 | - |
| l2 | 3.54 |
| z2 | 3.54 |
| H1 | 5.197 |
| M1 | 1.12 |
| M2 | 9.84 |
| E | 1.14 |
| H | 5.20 |
| h2 | - |
| Y | 1.76 |
| V | 2.52 |
| U | 2.05 |
| a | - |
SJT5003SS
| size | 3" |
|---|---|
| dimensions | 6.57x13.74x7.40 " |
| weight | 17.28 lb |
| packaging | - |
| d1 | 3.50 |
| DN1 | - |
| l1 | 4.21 |
| z1 | 4.21 |
| d2 | 3.50 |
| DN2 | - |
| l2 | 4.21 |
| z2 | 4.21 |
| H1 | 5.63 |
| M1 | 1.64 |
| M2 | 9.84 |
| E | 1.56 |
| H | 5.63 |
| h2 | - |
| Y | 2.63 |
| V | 3.15 |
| U | 2.68 |
| a | - |
SJT5004SS
| size | 4" |
|---|---|
| dimensions | 9.45x15.16x8.71 " |
| weight | 32.41 lb |
| packaging | - |
| d1 | 4.50 |
| DN1 | - |
| l1 | 4.72 |
| z1 | 4.72 |
| d2 | 4.50 |
| DN2 | - |
| l2 | 4.72 |
| z2 | 4.72 |
| H1 | 5.315 |
| M1 | 1.84 |
| M2 | 11.42 |
| E | 1.00 |
| H | 5.32 |
| h2 | - |
| Y | 2.01 |
| V | 4.02 |
| U | 2.76 |
| a | - |
SJT5006
| size | 6" |
|---|---|
| dimensions | 10.16x28.70x12.01 " |
| weight | 88.47 lb |
| packaging | - |
| d1 | 6.63 |
| DN1 | - |
| l1 | 5.08 |
| z1 | 5.08 |
| d2 | 6.63 |
| DN2 | - |
| l2 | 5.08 |
| z2 | 5.08 |
| H1 | 8.701 |
| M1 | 1.84 |
| M2 | 11.42 |
| E | 1.00 |
| H | 8.70 |
| h2 | - |
| Y | 3.03 |
| V | 6.50 |
| U | 5.51 |
| a | - |
SJT5006SS
| size | 6" |
|---|---|
| dimensions | 10.16x28.70x12.01 " |
| weight | 88.47 lb |
| packaging | - |
| d1 | 6.63 |
| DN1 | - |
| l1 | 5.08 |
| z1 | 5.08 |
| d2 | 6.63 |
| DN2 | - |
| l2 | 5.08 |
| z2 | 5.08 |
| H1 | 8.701 |
| M1 | 1.84 |
| M2 | 11.42 |
| E | 1.00 |
| H | 8.70 |
| h2 | - |
| Y | 3.03 |
| V | 6.50 |
| U | 5.51 |
| a | - |
Specifications
| article | VSH Shurjoint ball valve lever-operated (2 x groove) |
|---|---|
| article number with gtin | SJ-500L |
| manufacturer | Shurjoint |
| weight | 88.47 lb |
| dimensions | 10.16x28.70x12.01 " |
| color | black |
| materials | cast iron (ASTM A536 65-45-12) |
| finishing | varnished |
| shape | straight |
| connection type | groove (fitting) |
| sealing | EPDM |
| min. medium temperature | -29 °F |
| max medium temperature | 230 °F |
| product group | valves (ball valves) |
| ETIM class | EC011343 Ball valve |
| country of origin | Taiwan |
| brand | VSH |
| series | Shurjoint |
| product type | SJ-500L |
| unsps | 40141607 |
| ETIM | {"etim-class":"EC011343 Ball valve","Housing material":"Cast iron","Surface protection housing":"Coated","Material ball":"Stainless steel","Material primary spindle seal":"Ethylene-propylene diene monomer rubber (EPDM)","Connection 1":"Groove","With coupling connection 1":"No","Connection 2":"Groove","With coupling connection 2":"No","Sealing":"Ethylene-propylene diene monomer rubber (EPDM)","With drain valve":"No","With drain possibility (connection)":"No","With non-return valve":"No","With filter":"No","With thermometer":"No","Model":"Straight","With insulation shell":"No","FM quality mark":"No","UL quality mark":"No","ULC quality mark":"No","LPCB quality mark":"No","Medium temperature (continuous)":"-34°C - 110°C","Medium temperature (continuous) (imperial)":"-29.2°F - 230°F","Medically clean":"No","Grease-free":"No","Operation":"Lever handle","Housing construction":"1-part","Full bore":"Yes","Angle of the valve":"","VdS quality mark":"No","DVGW quality mark for gas":"No","DVGW quality mark for water":"No","KIWA certified":"No"} |
