Attributes
| Group Code | SJ-900 |
|---|---|
| Product Type | check-valve |
| Brand Series | vsh-shurjoint |
| Applications | heating, cooling, compressed air |
| Approvals | CRN |
| Solutions | utility, industry |
Description
VSH Shurjoint grooved pipe systems consist of a wide range of groove couplings, fittings and valves for heating, compressed air and industry. VSH Shurjoint is less labor intensive, safer, cleaner and delivers consistent connection quality.
- VSH Shurjoint can be perfectly combined with other VSH systems such as VSH XPress, VSH SudoPress and VSH PowerPress
- the 'Aalberts integrated piping systems' range covers a fully integrated system from ¼" to 104"
Variations (9)
SJT90025E
| size | 2 1/2" |
|---|---|
| dimensions | 7.48x4.49x6.26 " |
| weight | 10.71 lb |
| packaging | - |
| d1 | 2.87 |
| DN1 | - |
| l1 | 3.47 |
| d2 | 2.87 |
| DN2 | - |
| l2 | 4.02 |
| V | 3.74 |
| U | 2.87 |
SJT9003E
| size | 3" |
|---|---|
| dimensions | 7.01x4.49x6.26 " |
| weight | 10.47 lb |
| packaging | - |
| d1 | 3.50 |
| DN1 | - |
| l1 | 2.99 |
| d2 | 3.50 |
| DN2 | - |
| l2 | 4.02 |
| V | 3.74 |
| U | 2.87 |
SJT9004E
| size | 4" |
|---|---|
| dimensions | 8.50x5.75x7.76 " |
| weight | 18.39 lb |
| packaging | - |
| d1 | 4.50 |
| DN1 | - |
| l1 | 3.50 |
| d2 | 4.50 |
| DN2 | - |
| l2 | 5.00 |
| V | 4.61 |
| U | 3.15 |
SJT9005E
| size | 5" |
|---|---|
| dimensions | 12.99x8.58x11.50 " |
| weight | 51.76 lb |
| packaging | - |
| d1 | 5.56 |
| DN1 | - |
| l1 | 5.35 |
| d2 | 5.56 |
| DN2 | - |
| l2 | 7.64 |
| V | 7.01 |
| U | 3.66 |
SJT9006E
| size | 6" |
|---|---|
| dimensions | 12.01x8.27x11.50 " |
| weight | 51.81 lb |
| packaging | - |
| d1 | 6.63 |
| DN1 | - |
| l1 | 5.00 |
| d2 | 6.63 |
| DN2 | - |
| l2 | 7.01 |
| V | 7.01 |
| U | 4.49 |
SJT9006T
| size | 6" |
|---|---|
| dimensions | 12.01x8.27x11.50 " |
| weight | 51.81 lb |
| packaging | - |
| d1 | 6.63 |
| DN1 | - |
| l1 | 5.00 |
| d2 | 6.63 |
| DN2 | - |
| l2 | 7.01 |
| V | 7.01 |
| U | 4.49 |
SJT9008E
| size | 8" |
|---|---|
| dimensions | 14.37x10.47x14.06 " |
| weight | 99.78 lb |
| packaging | - |
| d1 | 8.63 |
| DN1 | - |
| l1 | 4.37 |
| d2 | 8.63 |
| DN2 | - |
| l2 | 10.00 |
| V | 8.54 |
| U | 5.94 |
SJT90010E
| size | 10" |
|---|---|
| dimensions | 20.00x14.37x17.99 " |
| weight | 218.26 lb |
| packaging | - |
| d1 | 10.75 |
| DN1 | - |
| l1 | 10.00 |
| d2 | 10.75 |
| DN2 | - |
| l2 | 10.00 |
| V | 10.75 |
| U | 10.71 |
SJT90012E
| size | 12" |
|---|---|
| dimensions | 24.02x15.51x21.42 " |
| weight | 343.04 lb |
| packaging | - |
| d1 | 12.75 |
| DN1 | - |
| l1 | 12.01 |
| d2 | 12.75 |
| DN2 | - |
| l2 | 12.01 |
| V | 12.87 |
| U | 12.28 |
Specifications
| article | VSH Shurjoint swing check valve (2 x groove) |
|---|---|
| article number with gtin | SJ-900 |
| manufacturer | Shurjoint |
| weight | 343.04 lb |
| dimensions | 24.02x15.51x21.42 " |
| color | black |
| materials | cast iron (ASTM A536 65-45-12) |
| finishing | varnished |
| shape | straight |
| connection type | groove (fitting) |
| pressure rating (PN) | PN 20 |
| sealing | EPDM, NBR (Nitrile) |
| max operating pressure liquid | 290 psi |
| product group | valves (check valves) |
| ETIM class | EC011469 Check valve |
| country of origin | Taiwan |
| brand | VSH |
| series | Shurjoint |
| product type | SJ-900 |
| unsps | 40141634 |
| ETIM | {"etim-class":"EC011469 Check valve","Surface protection":"Coated","Connections":"Groove","Article compression class":"PN 20","Backflow safeguard according to EN 1717":"EB","Angle of non-return valve":"","Max. operating pressure at 20 °C":"20bar","Max. operating pressure at 20 °C (imperial)":"290.08psi","FM quality mark":"No","UL quality mark":"No","ULC quality mark":"No","LPCB quality mark":"No","Suitable for central heating water":"Yes","Certified according to SVGW for water":"No","Certified according to SVGW for gas":"No","VdS quality mark":"No","DVGW quality mark for gas":"No","DVGW quality mark for water":"No","KIWA certified":"No"} |
