Attributes
| Group Code | SJ-915 |
|---|---|
| Product Type | check-valve |
| Brand Series | vsh-shurjoint |
| Applications | heating, cooling, compressed air |
| Solutions | utility, industry |
Description
VSH Shurjoint grooved pipe systems consist of a wide range of groove couplings, fittings and valves for heating, compressed air and industry. VSH Shurjoint is less labor intensive, safer, cleaner and delivers consistent connection quality.
- VSH Shurjoint can be perfectly combined with other VSH systems such as VSH XPress, VSH SudoPress and VSH PowerPress
- the 'Aalberts integrated piping systems' range covers a fully integrated system from ¼" to 104"
Variations (4)
SJT9153E
| size | 3" |
|---|---|
| dimensions | 4.92x4.92x5.31 " |
| weight | 5.51 lb |
| packaging | Carton (1 pce) |
| d1 | 3.50 |
| DN1 | - |
| l1 | 2.68 |
| z1 | 2.68 |
| d2 | 3.50 |
| DN2 | - |
| l2 | 2.68 |
| z2 | 2.68 |
SJT9154E
| size | 4" |
|---|---|
| dimensions | 5.98x5.98x5.39 " |
| weight | 8.42 lb |
| packaging | - |
| d1 | 4.50 |
| DN1 | - |
| l1 | 2.72 |
| z1 | 2.72 |
| d2 | 4.50 |
| DN2 | - |
| l2 | 2.72 |
| z2 | 2.72 |
SJT9156E
| size | 6" |
|---|---|
| dimensions | 8.03x8.03x5.98 " |
| weight | 16.76 lb |
| packaging | - |
| d1 | 6.63 |
| DN1 | - |
| l1 | 2.99 |
| z1 | 2.99 |
| d2 | 6.63 |
| DN2 | - |
| l2 | 2.99 |
| z2 | 2.99 |
SJT9158E
| size | 8" |
|---|---|
| dimensions | 10.08x10.08x6.73 " |
| weight | 27.36 lb |
| packaging | - |
| d1 | 8.63 |
| DN1 | - |
| l1 | 3.39 |
| z1 | 3.39 |
| d2 | 8.63 |
| DN2 | - |
| l2 | 3.39 |
| z2 | 3.39 |
Specifications
| article | VSH Shurjoint dual disc check valve (2 x groove) |
|---|---|
| article number with gtin | SJ-915 |
| manufacturer | Shurjoint |
| weight | 27.36 lb |
| dimensions | 10.08x10.08x6.73 " |
| color | black |
| materials | cast iron (ASTM A536 65-45-12) |
| finishing | varnished |
| shape | straight |
| connection type | groove (fitting) |
| sealing | EPDM |
| max operating pressure liquid | 290 psi |
| min. medium temperature | -29 °F |
| max medium temperature | 230 °F |
| product group | valves (check valves) |
| ETIM class | EC011469 Check valve |
| intrastat code | 84813091 |
| country of origin | Taiwan |
| brand | VSH |
| series | Shurjoint |
| product type | SJ-915 |
| ETIM | {"etim-class":"EC011469 Check valve","Surface protection":"Coated","Connections":"Groove","Sealing":"Ethylene-propylene diene monomer rubber (EPDM)","Backflow safeguard according to EN 1717":"EB","Medium temperature (continuous)":"-34°C - 110°C","Medium temperature (continuous) (imperial)":"-29.2°F - 230°F","Max. operating pressure at 20 °C":"20bar","Max. operating pressure at 20 °C (imperial)":"290.08psi","FM quality mark":"No","UL quality mark":"No","ULC quality mark":"No","LPCB quality mark":"No","Suitable for central heating water":"Yes","Certified according to SVGW for water":"No","Certified according to SVGW for gas":"No","VdS quality mark":"No","DVGW quality mark for gas":"No","DVGW quality mark for water":"No","KIWA certified":"No"} |
