| ETIM | {"etim-class":"EC003024 Fitting with 2 connections","Material connection 1":"Steel","Material quality connection 1":"Other","Surface protection connection 1":"Lacquered","Surface treatment connection 1":"Other","Material connection 2":"Steel","Material quality connection 2":"Other","Surface protection connection 2":"Lacquered","Surface treatment connection 2":"Other","Shape":"Straight","Reducing":"No","Eccentric":"No","System specific":"No","Nominal diameter connection 1":"DN 350","Outer pipe diameter connection 1":"355.6mm","Outer pipe diameter connection 1 (imperial)":"14\"","Connection 1":"Groove","Nominal diameter connection 2":"DN 250","Outer pipe diameter connection 2":"273mm","Outer pipe diameter connection 2 (imperial)":"10.75\"","Connection 2":"Groove","With buffer stud":"No","High tensile strength":"Yes","Length":"355.6mm","Length (imperial)":"14\"","Length of connection 1":"165mm","Length of connection 1 (imperial)":"6.5\"","Working length connection 1":"165mm","Working length connection 1 (imperial)":"6.5\"","Length of connection 2":"165mm","Length of connection 2 (imperial)":"6.5\"","Working length connection 2":"165mm","Working length connection 2 (imperial)":"6.5\"","With sealing rings/gaskets":"No","Capped":"No","With connection indicator":"No","With drain valve":"No","With de-aerator":"No","FM quality mark":"No","LPCB quality mark":"No","ULC quality mark":"No","UL quality mark":"No","VdS quality mark":"No","DVGW quality mark for gas":"No","DVGW quality mark for water":"No","Certified according to NF 545":"No","KIWA certified":"No","Gastec QA mark":"No","KOMO certified":"No","Gastec QA - AR 214 (H2)":"No"} |
|---|
