| ETIM | {"etim-class":"EC003024 Fitting with 2 connections","Material connection 1":"Cast iron","Material quality connection 1":"ASTM A536 Grade 65-45-12","Surface protection connection 1":"Hot-dip galvanised","Material connection 2":"Cast iron","Material quality connection 2":"ASTM A536 Grade 65-45-12","Surface protection connection 2":"Hot-dip galvanised","Shape":"Straight","Model":"2-part","Reducing":"No","Eccentric":"No","System specific":"No","Nominal diameter connection 1":"DN 250","Outer pipe diameter connection 1":"273mm","Outer pipe diameter connection 1 (imperial)":"10.75\"","Connection 1":"Ribbing groove (groove coupling)","Nominal diameter connection 2":"DN 250","Outer pipe diameter connection 2":"273mm","Outer pipe diameter connection 2 (imperial)":"10.75\"","Connection 2":"Ribbing groove (groove coupling)","Main colour fitting":"Grey","Material sealing":"Ethylene-propylene diene monomer rubber (EPDM)","With buffer stud":"No","High tensile strength":"Yes","Length":"75mm","Length (imperial)":"2.95\"","Length of connection 1":"37.5mm","Length of connection 1 (imperial)":"1.48\"","Working length connection 1":"3.2mm","Working length connection 1 (imperial)":"0.13\"","Length of connection 2":"37.5mm","Length of connection 2 (imperial)":"1.48\"","Working length connection 2":"3.2mm","Working length connection 2 (imperial)":"0.13\"","Medium temperature (continuous)":"-34°C - 110°C","Medium temperature (continuous) (imperial)":"-29.2°F - 230°F","Max. operating pressure at 20 °C":"55bar","Max. operating pressure at 20 °C (imperial)":"797.71psi","With sealing rings/gaskets":"No","Capped":"No","With connection indicator":"No","With drain valve":"No","With de-aerator":"No","FM quality mark":"Yes","LPCB quality mark":"No","ULC quality mark":"No","UL quality mark":"No","VdS quality mark":"No","DVGW quality mark for gas":"No","DVGW quality mark for water":"No","Certified according to NF 545":"No","KIWA certified":"No","Gastec QA mark":"No","KOMO certified":"No","Gastec QA - AR 214 (H2)":"No"} |
|---|
