Attributes
| Group Code | SJ-400L |
|---|---|
| Product Type | vlinderklep |
| Brand Series | vsh-shurjoint-stainless-steel |
| Applications | potable water, heating, cooling, compressed air |
| Approvals | CRN, NSF |
| Solutions | utility, industry |
Description
VSH Shurjoint grooved pipe systems consist of a wide range of groove couplings, fittings and valves for heating, compressed air and industry. VSH Shurjoint is less labor intensive, safer, cleaner and delivers consistent connection quality.
- VSH Shurjoint can be perfectly combined with other VSH systems such as VSH XPress, VSH SudoPress and VSH PowerPress
- the 'Aalberts integrated piping systems' range covers a fully integrated system from ¼" to 104"
Variations (7)
SJT400L26
| size | 2" w/Lever |
|---|---|
| dimensions | 9.15x2.52x6.65 " |
| weight | 5.07 lb |
| packaging | - |
| d1 | 2.37 |
| DN1 | - |
| l1 | 1.61 |
| d2 | 2.37 |
| DN2 | - |
| l2 | 1.61 |
| M1 | 0.83 |
| M2 | 7.56 |
| Y | 1.38 |
| V | 4.17 |
| U | 1.13 |
SJT400L256
| size | 2 1/2" w/Lever |
|---|---|
| dimensions | 9.47x3.11x7.05 " |
| weight | 7.05 lb |
| packaging | - |
| d1 | 2.87 |
| DN1 | - |
| l1 | 1.93 |
| d2 | 2.87 |
| DN2 | - |
| l2 | 1.93 |
| M1 | 0.83 |
| M2 | 7.56 |
| Y | 1.38 |
| V | 4.37 |
| U | 1.25 |
SJT400L256T
| size | 2 1/2" NBR w/Lever |
|---|---|
| dimensions | 9.47x3.11x7.05 " |
| weight | 7.05 lb |
| packaging | - |
| d1 | 2.87 |
| DN1 | - |
| l1 | 1.93 |
| d2 | 2.87 |
| DN2 | - |
| l2 | 1.93 |
| M1 | 0.83 |
| M2 | 7.56 |
| Y | 1.38 |
| V | 4.37 |
| U | 1.25 |
SJT400L36
| size | 3" w/Lever |
|---|---|
| dimensions | 9.47x3.62x7.95 " |
| weight | 7.72 lb |
| packaging | - |
| d1 | 3.50 |
| DN1 | - |
| l1 | 1.93 |
| d2 | 3.50 |
| DN2 | - |
| l2 | 1.93 |
| M1 | 0.83 |
| M2 | 7.56 |
| Y | 1.38 |
| V | 4.96 |
| U | 1.25 |
SJT400L46
| size | 4" w/Lever |
|---|---|
| dimensions | 12.52x4.65x8.82 " |
| weight | 11.02 lb |
| packaging | - |
| d1 | 4.50 |
| DN1 | - |
| l1 | 2.28 |
| d2 | 4.50 |
| DN2 | - |
| l2 | 2.28 |
| M1 | 0.83 |
| M2 | 9.92 |
| Y | 1.38 |
| V | 5.32 |
| U | 1.42 |
SJT400L66
| size | 6" w/Lever |
|---|---|
| dimensions | 12.83x6.77x11.73 " |
| weight | 20.28 lb |
| packaging | - |
| d1 | 6.63 |
| DN1 | - |
| l1 | 2.91 |
| d2 | 6.63 |
| DN2 | - |
| l2 | 2.91 |
| M1 | 0.83 |
| M2 | 7.24 |
| Y | 1.38 |
| V | 7.24 |
| U | 1.42 |
SJT400L86
| size | 8" w/Lever |
|---|---|
| dimensions | 12.54x8.74x13.70 " |
| weight | 26.9 lb |
| packaging | - |
| d1 | 8.63 |
| DN1 | - |
| l1 | 2.64 |
| d2 | 8.63 |
| DN2 | - |
| l2 | 2.64 |
| M1 | 0.83 |
| M2 | 8.19 |
| Y | 1.38 |
| V | 8.19 |
| U | 1.73 |
Specifications
| article | VSH Shurjoint stainless steel butterfly valve lever-operated (2 x groove) |
|---|---|
| article number with gtin | SJ-400L |
| manufacturer | Shurjoint |
| weight | 26.9 lb |
| dimensions | 12.54x8.74x13.70 " |
| color | silver |
| materials | stainless steel (Stainless steel 316 (1.4401)) |
| finishing | none |
| shape | straight |
| connection type | groove (fitting) |
| pressure rating (PN) | PN 20 |
| sealing | EPDM, NBR (Nitrile) |
| max operating pressure liquid | 290 psi |
| product group | valves (butterfly valves) |
| ETIM class | EC010910 Butterfly valve |
| country of origin | Taiwan |
| brand | VSH |
| series | Shurjoint Stainless Steel |
| product type | SJ-400L |
| ETIM | {"etim-class":"EC010910 Butterfly valve","Material quality":"Stainless steel 316 (1.4401)","Surface protection":"Untreated","Material quality valve butterfly":"Stainless steel 316 (1.4401)","Connections":"Groove","Operation":"Lever handle","Height operating element":"35mm","Height operating element (imperial)":"1.38\"","UL quality mark":"No","ULC quality mark":"No","FM quality mark":"No","LPCB quality mark":"No","VdS quality mark":"No","KIWA certified":"No","Gastec QA mark":"No","Gastec QA - AR 214 (H2)":"No"} |
