Attributes
| Group Code | SS-726 |
|---|---|
| Product Type | strainer |
| Brand Series | vsh-shurjoint-stainless-steel |
| Applications | heating, cooling, compressed air |
| Solutions | utility, industry |
Description
VSH Shurjoint grooved pipe systems consist of a wide range of groove couplings, fittings and valves for heating, compressed air and industry. VSH Shurjoint is less labor intensive, safer, cleaner and delivers consistent connection quality.
- VSH Shurjoint can be perfectly combined with other VSH systems such as VSH XPress, VSH SudoPress and VSH PowerPress
- the 'Aalberts integrated piping systems' range covers a fully integrated system from ¼" to 104"
Variations (4)
SJTSS726256E
| size | 2 1/2" 316 |
|---|---|
| dimensions | 2.87x9.27x10.75 " |
| weight | 16.76 lb |
| packaging | - |
| d1 | 2.87 |
| DN1 | - |
| l1 | 5.39 |
| z1 | 5.39 |
| d2 | 2.87 |
| DN2 | - |
| l2 | 5.39 |
| z2 | 5.39 |
| V | 7.56 |
| U | 5.51 |
| a | - |
| angle | - |
SJTSS72636E
| size | 3" 316 |
|---|---|
| dimensions | 3.50x10.45x11.77 " |
| weight | 20.72 lb |
| packaging | - |
| d1 | 3.50 |
| DN1 | - |
| l1 | 5.91 |
| z1 | 5.91 |
| d2 | 3.50 |
| DN2 | - |
| l2 | 5.91 |
| z2 | 5.91 |
| V | 8.15 |
| U | 6.54 |
| a | - |
| angle | - |
SJTSS72646E
| size | 4" 316 |
|---|---|
| dimensions | 4.50x12.84x14.25 " |
| weight | 37.65 lb |
| packaging | - |
| d1 | 4.50 |
| DN1 | - |
| l1 | 7.13 |
| z1 | 7.13 |
| d2 | 4.50 |
| DN2 | - |
| l2 | 7.13 |
| z2 | 7.13 |
| V | 10.55 |
| U | 8.11 |
| a | - |
| angle | - |
SJTSS72666E
| size | 6" 316 |
|---|---|
| dimensions | 6.63x17.37x18.50 " |
| weight | 85.98 lb |
| packaging | - |
| d1 | 6.63 |
| DN1 | - |
| l1 | 9.25 |
| z1 | 9.25 |
| d2 | 6.63 |
| DN2 | - |
| l2 | 9.25 |
| z2 | 9.25 |
| V | 13.90 |
| U | 10.67 |
| a | - |
| angle | - |
Specifications
| article | VSH Shurjoint stainless steel Y-strainer (2 x groove) |
|---|---|
| article number with gtin | SS-726 |
| manufacturer | Shurjoint |
| weight | 85.98 lb |
| dimensions | 6.63x17.37x18.50 " |
| color | silver |
| materials | stainless steel (Stainless steel 316 (1.4401)) |
| finishing | none |
| shape | straight |
| connection type | groove (fitting) |
| pressure rating (PN) | PN 20 |
| sealing | EPDM |
| max operating pressure liquid | 290 psi |
| min. medium temperature | -29 °F |
| max medium temperature | 230 °F |
| product group | valves (strainers) |
| ETIM class | EC010151 Pipeline strainer |
| intrastat code | 73071910 |
| country of origin | Taiwan |
| brand | VSH |
| series | Shurjoint Stainless Steel |
| product type | SS-726 |
| unsps | 40142505 |
| ETIM | {"etim-class":"EC010151 Pipeline strainer","Shape":"Pipeline strainer","Material quality":"Stainless steel 316 (1.4401)","Surface protection":"Untreated","Material sealing":"Ethylene-propylene diene monomer rubber (EPDM)","Connection":"Groove","With coupling":"No","Article compression class":"PN 20","Max. operating pressure":"20bar","Max. operating pressure (imperial)":"290.08psi","Medium temperature (continuous)":"-34°C - 110°C","Medium temperature (continuous) (imperial)":"-29.2°F - 230°F","With drain possibility (connection)":"Yes","KIWA certified":"No","Gastec QA mark":"No","Gastec QA - AR 214 (H2)":"No"} |
