Attributes
| Group Code | 38LF30X02 |
|---|---|
| Product Type | backflow-preventer |
| Brand Series | apollo-38-series-vacuum-relief-valves |
| Applications | potable water, heating, cooling |
| Approvals | NSF |
| Solutions | utility |
Description
The Apollo® Models HBV2 LF, HBVAF2 LF, HBDUC, and HBDUC LF Hose Connection Vacuum Breakers are designed to prevent cross-connection caused by back-siphonage. The Apollo® Model HBDUC Hose Bibb Dual Check Backflow Preventer also prevents backflow due to low head back-pressure.
- Corrosion Resistant Body and Checks
- Low Head Loss
- Easy to Install with Break-Away Set Screw
- Made in USA
- Lead Free
Variations (1)
38LF30402
| size | 3/4" |
|---|---|
| dimensions | - |
| weight | 0.69 lb |
| packaging | Carton (1 pce) |
Specifications
| article | Apollo Brass Hose Bibb Dual Check Backflow Preventer with Standard Configuration (Hose Connection) |
|---|---|
| article number with gtin | 38LF30X02 (00670750061165) |
| manufacturer | Aalberts integrated piping systems Americas, Inc. (Apollo) |
| size | 3/4" |
| weight | 0.69 lb |
| color | yellow, bronze |
| materials | bronze (C89836 (lead-free)) |
| finishing | none |
| connection type | hose connector |
| max operating pressure liquid | 150 psi |
| product group | valves (backflow preventers) |
| ETIM class | EC011469 Check valve |
| country of origin | United States |
| brand | Apollo |
| series | 38 Series Vacuum Relief Valves |
| product type | 38LF30X03 |
| unsps | 40141749 |
| ETIM | {"etim-class":"EC011469 Check valve","Housing material":"Bronze","Surface protection":"Untreated","Height":"","Height (imperial)":"","Max. operating pressure at 20 °C":"10.34bar","Max. operating pressure at 20 °C (imperial)":"150psi","FM quality mark":"No","UL quality mark":"No","ULC quality mark":"No","LPCB quality mark":"No","Suitable for central heating water":"Yes","Certified according to SVGW for water":"No","Certified according to SVGW for gas":"No","VdS quality mark":"No","DVGW quality mark for gas":"No","DVGW quality mark for water":"No","KIWA certified":"No"} |
