Attributes
| Group Code | 8210X0463 |
|---|---|
| Product Type | kogelafsluiters |
| Brand Series | apollo-82-series-ball-valves |
| Applications | heating, cooling, steam, vacuum |
| Approvals | Build America Buy America (BABA) Act, Buy American Act (BAA), CRN, Made in USA |
| Solutions | utility, industry |
Description
The Apollo 82-100 Series is designed as an in-line serviceable full port bronze ball valve. SAE grade body bolts and RPTFE seals are standard.
- Dezincification Resistant Bronze Body
- Adjustable Packing Gland
- Blowout Proof Stem Design
- Premium RPTFE Seats and Seals
- Full Port Ball Configuration in All Sizes
- 100% Factory Tested
- Made in USA
Variations (4)
821030463
| size | 1/2" |
|---|---|
| dimensions | 5.52x2.21x3.73 " |
| weight | 1.55 lb |
| packaging | Carton (1 pce) |
| d1 | 0.84 |
| DN1 | - |
| d2 | 0.63 |
| DN2 | - |
821040463
| size | 3/4" |
|---|---|
| dimensions | 5.52x2.21x3.73 " |
| weight | 2.27 lb |
| packaging | Carton (1 pce) |
| d1 | 1.05 |
| DN1 | - |
| d2 | 0.88 |
| DN2 | - |
821070463
| size | 1-1/2" |
|---|---|
| dimensions | 5.52x2.21x3.73 " |
| weight | 8.07 lb |
| packaging | Carton (1 pce) |
| d1 | 1.90 |
| DN1 | - |
| d2 | 1.63 |
| DN2 | - |
821080463
| size | 2" |
|---|---|
| dimensions | 5.52x2.21x3.73 " |
| weight | 14.85 lb |
| packaging | Carton (1 pce) |
| d1 | 2.38 |
| DN1 | - |
| d2 | 2.13 |
| DN2 | - |
Specifications
| article | Apollo 3-Piece Full Port Bronze Ball Valves with 2-1/4" Stem Extension (FNPT x Solder) |
|---|---|
| article number with gtin | 8210X0463 |
| manufacturer | Aalberts integrated piping systems Americas, Inc. (Apollo) |
| weight | 14.85 lb |
| dimensions | 5.52x2.21x3.73 " |
| color | yellow, bronze |
| materials | bronze (ASTM B584-C84400) |
| finishing | none |
| shape | straight |
| connection type | FPT - female thread conical (NPT), solder |
| product group | valves (ball valves) |
| ETIM class | EC011343 Ball valve |
| country of origin | United States |
| brand | Apollo |
| series | 82 Series Ball Valves |
| product type | 8210X0463 |
| unsps | 40141607 |
| ETIM | {"etim-class":"EC011343 Ball valve","Housing material":"Bronze","Surface protection housing":"None","Material ball":"Brass","Material spindle":"Brass","Connection 1":"Internal thread conical (NPT)","Connection 2":"Soldered sleeve","With filter":"No","FM quality mark":"No","UL quality mark":"No","ULC quality mark":"No","LPCB quality mark":"No","Medically clean":"No","Grease-free":"No","Housing construction":"3-part","Full bore":"Yes","VdS quality mark":"No","DVGW quality mark for gas":"No","DVGW quality mark for water":"No","KIWA certified":"No"} |
